5C – 2ICLUTCH
DAEWOO V–121 BL4
SPECIAL TOOLS
SPECIAL TOOLS TABLE
J–42474
Clutch Arbor
DIAGNOSIS
CLUTCH OPERATION
Intermittent Clutch Operation
ChecksAction
Check for the driver improperly operating the vehicle.Correct the driver’s operation of the vehicle as necessary.
Check for the improper clutch pedal play.Adjust the clutch pedal play.
Check for the insufficient oil or the leak at oil pressure line.Repair the leak or add the oil.
Check for a warped or worn clutch disc.Replace the clutch disc.
Check for worn splines on the input shaft.Repair or Replace the splines on the input shaft.
Check for a weak diaphragm spring.Replace the pressure plate.
Clutch Slipping
ChecksAction
Check for a stuck concentric slave cylinder.Replace the concentric slave cylinder.
Check for improper return of clutch oil.Perform the air bleeding.
Check for a worn clutch disc or oil contamination.Replace the clutch disc.
Check for a warped pressure plate.Replace the pressure plate.
Page 1890 of 2643
CLUTCH 5C – 3
DAEWOO V–121 BL4
Clutch Vibration
ChecksAction
Check for a contaminated or warped flywheel.Repair or replace the flywheel.
Check for a weak diaphragm spring.Replace the pressure plate.
Check for a oily contamination of clutch disc.Replace the clutch disc.
Check for worn splines on the input shaft.Replace the splines on the input shaft.
Check for a warped pressure plate or flywheel.Replace the pressure plate or flywheel.
Hard Pedal Effort
ChecksAction
Check for bad lubrication of clutch pedal shaft.Apply the grease or repair it.
Check for a clogged pipe.Inspect or replace the clogged pipe.
Check for a stuck concentric slave cylinder.Replace the concentric slave cylinder.
Noise in Clutch Pedal
ChecksAction
Check for insufficient lubrication of clutch pedal bushing.Lubricate the clutch pedal bushing.
Check for interference of clutch pedal return spring.Remove and reinstall the clutch pedal return spring.
Page 1891 of 2643
5C – 4ICLUTCH
DAEWOO V–121 BL4
COMPONENT LOCATOR
CLUTCH COMPONENTS
1. Clutch Pedal
2. Bolt
3. Nut
4. Lock Nut
5. Clutch Pedal Buffer
6. Nut
7. Clutch Pedal Brace8. E–Ring
9. Pin
10. E–Ring
11. Clutch Master Cylinder
12. Clutch Pedal Shaft
13. Turn–over Spring
Page 1892 of 2643
CLUTCH 5C – 5
DAEWOO V–121 BL4
1. Clutch Master Cylinder
2. Nut
3. Gasket
4. Clip
5. Reservoir Hose
6. Clutch Master Cylinder Pipe
7. Clip
8. Clip
9. Bracket10. Bolt
11. Concentric Slave Cylinder
12. Concentric Slave Cylinder Pipe
13. Bolt
14. Clip
15. Hose
16. Pressure Plate
17. Clutch Disc
18. Bolt
Page 1893 of 2643
5C – 6ICLUTCH
DAEWOO V–121 BL4
MAINTENANCE AND REPAIR
ON–VEHICLE SERVICE
CLUTCH PEDAL
Removal Procedure
1. Disconnect the negative battery cable.
2. Disconnect the return spring from the clutch pedal.
3. Remove the clip and the pedal mounting shaft.
4. Remove the locking clip and push rod fixing pin.
5. Remove the push rod from the clutch pedal.
6. Remove the clutch pedal.
Installation Procedure
1. Install the clutch pedal.
2. Coat the push rod with multi–purpose grease.
3. Install the push rod to the clutch pedal.
4. Install the locking clip and push rod fixing pin.
Page 1894 of 2643

CLUTCH 5C – 7
DAEWOO V–121 BL4
5. Coat the pedal mounting shaft with multi–purpose
grease.
6. Install the clip and the pedal mounting shaft.
7. Connect the return spring to the clutch pedal.
8. Adjust the clutch pedal play. Refer to ”Clutch Pedal
Adjustment” in this section.
9. Connect the negative battery cable.
CLUTCH PEDAL ADJUSTMENT
Adjustment Procedure
1. Determine the clutch pedal play. Depress the clutch
pedal lightly with your hand and measure the dis-
tance when you feel resistance.
2. Adjust the clutch pedal play. Loosen the locknut
and turn the pushrod. Clutch pedal play should
measure 6 to 12 mm (0.2 to 0.5 inch). Tighten the
locknut after adjustment.
3. Measure the clutch pedal travel. Press the clutch
pedal all the way to the floor. Measure from the
starting position to the ending position.
4. Adjust the clutch pedal travel. Loosen the locknut
and turn the bolt. Clutch pedal travel should mea-
sure 130 to 140 mm (5.1 to 5.5 inches). Tighten the
locknut after adjustment.
Page 1895 of 2643

5C – 8ICLUTCH
DAEWOO V–121 BL4
CLUTCH RELEASE POINT
ADJUSTMENT
Adjustment Procedure
1. Apply the parking brake.
2. Run the engine at idle speed.
3. While you move the shift lever into the reverse
position, depress the clutch pedal slowly and mea-
sure the distance between the point when gear
noise is not heard and the point the clutch pedal is
completely depressed. The distance should be 30
to 40 mm (1.2 to 1.6 inches).
4. If the distance is not within the specified value,
check the following:
S Clutch pedal height
S Clutch pedal play
S Air in the system
S Clutch cover and disc pressure plate
AIR BLEEDING
Bleed the hydraulic system to remove the air which en-
tered when the pipes were disconnected for repairs. The
clutch/brake fluid in the clutch/brake reservoir must be
maintained at the MIN level or higher during air bleeding.
1. Attach a vinyl hose to the bleeder plug. Place the
other end of the vinyl tube in a glass container half–
filled with brake fluid.
2. Slowly pump the clutch pedal several times.
3. While you press the clutch pedal, loosen the bleed-
er screw until the fluid starts to run out. Close the
bleeder screw.
4. Repeat Step 3 until there are no air bubbles in the
fluid.
5. Fill the reservoir with brake fluid up to the proper
level.
PRESSURE PLATE AND CLUTCH
DISC
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the transaxle from the vehicle. Refer to
Section 5B, Five–Speed Manual Transaxle.
3. Remove the pressure plate bolts and the pressure
plate.
Important : Support the pressure plate when you remove
the last bolt.
Page 1896 of 2643
CLUTCH 5C – 9
DAEWOO V–121 BL4
4. Remove the clutch disc from the flywheel.
Inspection Procedure Clutch Disc
1. Visual Inspection
S Inspect the worn or oily contamination on the
clutch surface.
S Inspect the damaged or weakened torsion
spring.
S Inspect the a warped or bent clutch disc. After
inspection, replace new clutch disc, if necessary.
2. Clutch Disc Inspection
S Measure the rivet head depth from the clutch
disc surface.
S Replace the clutch disc if the measured value is
below the limit.
S Rivet Head Depth (Limit) : 0.3 mm (0.012 in)
Inspection Procedure Pressure Plate
1. Check for a worn diaphragm spring finger.
2. Check for a worn or cracked pressure plate sur-
face.
3. Check for the polluted face by the oil. After inspec-
tion, replace the pressure plate if necessary.
