DAEWOO NUBIRA 2004 Service Repair Manual SECTION : 8B
SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in

SECTION : 8B
SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition mujst be also be in LOCK unless otherwise noted
TABLE OF CONTENTS
SPECIFICATIONS8B–3 . . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications 8B–3. . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 8B–3. . . . . . . . . . .
SPECIAL TOOLS8B–3 . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOLS TABLE 8B–3. . . . . . . . . . . . . . . . . . .
SCHEMATIC AND ROUTING DIAGRAMS8B–4 . . . . .
Supplemental Inflatable Restraints(SIR)
Electronical Schematic 8B–4. . . . . . . . . . . . . . . . . . . .
SIR Component Locator 8B–5. . . . . . . . . . . . . . . . . . . .
DIAGNOSIS8B–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Trouble Code (DTC) 8B–6. . . . . . . . . . . . . .
Scan Tool Diagnostics 8B–7. . . . . . . . . . . . . . . . . . . . . .
SIR Diagnostic System Check 8B–8. . . . . . . . . . . . . . .
Sensing and Diagnostic Module (SDM) Integrity
check 8B–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC 1 Driver Airbag Deployment Loop Resistance
Is High 8B–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC 2 Driver Airbag Deployment Loop Resistance
Is Low 8B–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC 3 Driver Airbag Deployment Loop Is Shorted
To Ground 8B–16. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC 4 Driver Airbag Deployment Loop Is Shorted
To Power 8B–18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC 5 Passenger Airbag Deployment Loop
Resistance Is High 8B–20. . . . . . . . . . . . . . . . . . . . . .
DTC 6 Passenger Airbag Deployment Loop
Resistance Is Low 8B–22. . . . . . . . . . . . . . . . . . . . . .
DTC 7 Passenger Airbag Deployment Loop Is
Shorted To Ground 8B–24. . . . . . . . . . . . . . . . . . . . . .
DTC 8 Passenger Airbag Deployment Loop Is
Shorted To Power 8B–26. . . . . . . . . . . . . . . . . . . . . . .
DTC 9 Driver Belt Pretensioner Deployment
Loop Resistance Is High 8B–28. . . . . . . . . . . . . . . . .
DTC 10 Driver Belt Pretensioner Deployment
Loop Resistance Is Low 8B–30. . . . . . . . . . . . . . . . . .
DTC 11 Driver Belt Pretensioner Deployment
Loop Is Shorted To Ground 8B–32. . . . . . . . . . . . . . . DTC 12 Driver Belt Pretensioner Deployment
Loop Is Shorted To Power 8B–34. . . . . . . . . . . . . . . .
DTC 13 Passenger Belt Pretensioner Deployment
Loop Resistance Is High 8B–36. . . . . . . . . . . . . . . . .
DTC 14 Passenger Belt Pretensioner Deployment
Loop Resistance Is Low 8B–38. . . . . . . . . . . . . . . . . .
DTC 15 Passenger Belt Pretensioner Deployment
Loop Is Shorted To Ground 8B–40. . . . . . . . . . . . . . .
DTC 16 Passenger Belt Pretensioner Deployment
Loop Is Shorted To Power 8B–42. . . . . . . . . . . . . . . .
DTC 23 Battery Voltage high 8B–44. . . . . . . . . . . . . . .
DTC 24 Battery Voltage Low 8B–46. . . . . . . . . . . . . . .
DTC 25 Airbag Warning Lamp Failure 8B–48. . . . . . .
DTC 31 Internal Sensing Diagnostic Module
(SDM) Failure 8B–50. . . . . . . . . . . . . . . . . . . . . . . . . .
DTC 32 Airbag Inflation Record By Frontal
Collision 8B–51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC 33 Driver Side Airbag Inflation Record By
Side Impact 8B–52. . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC 34 Passenger Side Airbag Inflation Record
By Side Impact 8B–53. . . . . . . . . . . . . . . . . . . . . . . . .
DTC 35 Belt Pretensioner Explosion Record 8B–54. .
DTC 38 Side Airbag And Belt Pretensioner
Explosion Count Over 5 8B–55. . . . . . . . . . . . . . . . . .
DTC 52 Driver Side Airbag Deployment Loop
Resistance Is High 8B–56. . . . . . . . . . . . . . . . . . . . . .
DTC 53 Driver Side Airbag Deployment Loop
Resistance Is Low 8B–58. . . . . . . . . . . . . . . . . . . . . .
DTC 54 Driver Side Airbag Deployment Loop Is
Shorted To Ground 8B–60. . . . . . . . . . . . . . . . . . . . . .
DTC 55 Driver Side Airbag Deployment Loop Is
Shorted To Power 8B–62. . . . . . . . . . . . . . . . . . . . . . .
DTC 56 Passenger Side Airbag Deployment Loop
Resistance Is High 8B–64. . . . . . . . . . . . . . . . . . . . . .
DTC 57 Passenger Side Airbag Deployment Loop
Resistance Is Low 8B–66. . . . . . . . . . . . . . . . . . . . . .
DTC 58 Passenger Side Airbag Deployment Loop
Is Shorted To Ground 8B–68. . . . . . . . . . . . . . . . . . . .
DTC 59 Passenger Side Airbag Deployment Loop
Is Shorted To Power 8B–70. . . . . . . . . . . . . . . . . . . . .

Page 2106 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 8B – 2ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
DTC 80 Driver Side Airbag Sensor Loop Is
Shorted To Power 8B–72. . . . . . . . . . . . . . . . . . . . . . .
DTC 81 Driver Side

8B – 2ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
DTC 80 Driver Side Airbag Sensor Loop Is
Shorted To Power 8B–72. . . . . . . . . . . . . . . . . . . . . . .
DTC 81 Driver Side Airbag Sensor Loop Is
Shorted To Ground 8B–74. . . . . . . . . . . . . . . . . . . . . .
DTC 82 Driver Side Airbag Sensor Communication
Error 8B–76. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC 83 Driver Side Airbag Sensor Failure 8B–78. . .
DTC 84 Passenger Side Airbag Sensor Loop Is
Shorted To Power 8B–80. . . . . . . . . . . . . . . . . . . . . . .
DTC 85 Passenger Side Airbag Sensor Loop Is
Shorted To Ground 8B–82. . . . . . . . . . . . . . . . . . . . . .
DTC 86 Passenger Side Airbag Sensor
Communication Error 8B–84. . . . . . . . . . . . . . . . . . . .
DTC 87 Passenger Side Airbag Sensor Failure 8B–86
MAINTENANCE AND REPAIR8B–88 . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 8B–88. . . . . . . . . . . . . . . . . . . .
Disabling the Supplemental Inflatable
Restraints(SIR) 8B–88. . . . . . . . . . . . . . . . . . . . . . . . .
Enabling the Supplemental Inflatable
Restraints(SIR) 8B–88. . . . . . . . . . . . . . . . . . . . . . . . .
Handling, Installation and Diagnosis 8B–89. . . . . . . . .
Repairs and Inspections Required After an
Accident 8B–89. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accident With Deployment Components
Replacements 8B–90. . . . . . . . . . . . . . . . . . . . . . . . . . Accident Without Deployment Component
Inspection 8B–90. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sensing and Diagnostic Module (SDM) 8B–90. . . . . .
Driver Airbag Module 8B–91. . . . . . . . . . . . . . . . . . . . . .
Clock Spring 8B–92. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock Spring Alignment 8B–93. . . . . . . . . . . . . . . . . . . .
Passenger Airbag Module 8B–94. . . . . . . . . . . . . . . . . .
Side Airbag Sensor 8B–95. . . . . . . . . . . . . . . . . . . . . . .
Front Seat Belt Pretensioner 8B–95. . . . . . . . . . . . . . .
Airbag Module Deployment (Inside of Vehicle) 8B–95
Airbag Module Deployment (Outside of Vehicle) 8B–97
Deployed Airbag Module Disposal Procedure 8B–98.
SIR Wiring Repair 8B–99. . . . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION8B–100 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supplemental Inflatable Restraints(SIR) 8B–100. . . .
Airbag Modules 8B–100. . . . . . . . . . . . . . . . . . . . . . . . . .
Front Seat Belt Pretensioners 8B–101. . . . . . . . . . . . .
Sensing and Diagnostic Module (SDM) 8B–101. . . . .
Airbag Warning Lamp 8B–101. . . . . . . . . . . . . . . . . . . .
Clock Spring 8B–101. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring Harness Connectors 8B–102. . . . . . . . . . . . . . .

Page 2107 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B – 3
DAEWOO V–121 BL4
SPECIFICATIONS
GENERAL SPECIFICATIONS
ApplicationDescription
Airbag System Deployment Time<20ms
Detection Time<5ms
Operating Tempe

Page 2108 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 8B – 4ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
SCHEMATIC AND ROUTING DIAGRAMS
SUPPLEMENTAL INFLATABLE RESTRAINTS(SIR)
ELECTRONICAL SCHEMATIC

Page 2109 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B – 5
DAEWOO V–121 BL4
SIR COMPONENT LOCATOR
1. Driver Airbag Module
2. Clock Spring
3. Sensing And Diagnostic Module(SDM)4. Passenger Airbag Module
5

Page 2110 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 8B – 6ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
DIAGNOSIS
DIAGNOSTIC TROUBLE CODE (DTC)
When the sensing and diagnostic module (SDM) detects
any problem it illuminates the airbag

8B – 6ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
DIAGNOSIS
DIAGNOSTIC TROUBLE CODE (DTC)
When the sensing and diagnostic module (SDM) detects
any problem it illuminates the airbag warning indicator and
stores the diagnostic trouble codes (DTCs).
The supplemental inflatable restraints (SIR) diagnostic
system check must be always the starting point for any
SIR diagnosis. The diagnostic system check reveals diag-
nostic trouble codes (DTCs) through the use of scan tool.
It also checks for proper airbag warning lamp operation.
The two types of DTCs that may be recorded are as fol-lows :
1. Active DTCs represent malfunction being detected
during the current ignition cycle. Active DTCs are
stored in random access memory (RAM).
2. Historic DTCs represent malfunctions detected sin-
cethe last time the historic memory was cleared.
Historic DTCs are stored in the electrically erasable
programmable read–only memory (EPROM).
Diagnostic Trouble Code Table
DTCDescription
1Driver Airbag Deployment Loop Resistance Is High
2Driver Airbag Deployment Loop Resistance Is Low
3Driver Airbag Deployment Loop Is Shorted To Ground
4Driver Airbag Deployment Loop Is Shorted To Power
5Passenger Airbag Deployment Loop Resistance Is High
6Passenger Airbag Deployment Loop Resistance Is Low
7Passenger Airbag Deployment Loop Is Shorted To Ground
8 Passenger Airbag Deployment Loop Is Shorted To Power
9Driver Belt Pretensioner Deployment Loop Resistance Is High
10Driver Belt Pretensioner Deployment Loop Resistance Is Low
11Driver Belt Pretensioner Deployment Loop Is Shorted To Ground
12 Driver Belt Pretensioner Deployment Loop Is Shorted To Power
13Passenger Belt Pretensioner Deployment Loop Resistance Is High
14Passenger Belt Pretensioner Deployment Loop Resistance Is Low
15Passenger Belt Pretensioner Deployment Loop Is Shorted To Ground
16Passenger Belt Pretensioner Deployment Loop Is Shorted To Power
23Battery Voltage High
24 Battery Voltage Low
25 Airbag Warning Lamp Failure
31Internal Sensing Diagnostic Module(SDM) Failure
32 Airbag Inflation Record By Frontal Collision
33 Driver Side Airbag Inflation Record By Side Impact
34Passenger Side Airbag Inflation Record By Side Impact
35Belt Pretensioner Explosion Record
38Side Airbag And Belt Pretensioner Explosion Count Over 5
52 Driver Side Airbag Deployment Loop Resistance Is High
53Driver Side Airbag Deployment Loop Resistance Is Low
54Driver Side Airbag Deployment Loop Is Shorted To Ground
55 Driver Side Airbag Deployment Loop Is Shorted To Power
56Passenger Side Airbag Deployment Loop Resistance Is High

Page 2111 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B – 7
DAEWOO V–121 BL4
DTC Description
57Passenger Side Airbag Deployment Loop Resistance Is Low
58Passenger Side Airbag Deployment Loop Is Shorted To Gr

Page 2112 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 8B – 8ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
SIR DIAGNOSTIC SYSTEM CHECK
Notice : If the vehicle interior has been exposed to exten-
sive water intrusion such as water leaks, d

8B – 8ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
SIR DIAGNOSTIC SYSTEM CHECK
Notice : If the vehicle interior has been exposed to exten-
sive water intrusion such as water leaks, driving through
high water, flooding, or other causes, the sensing and
diagnostic module(SDM) and SDM connector may need
to be replaced. With ignition OFF, inspect the area around
the SDM, including the carpet. If any significant soaking or
evidence of previous soaking is detected, the water must
be removed, water damage repaired, and the SDM and
the SDM connector must be replaced. Before attempting
any of these repairs, the supplemental inflatable re-
straints(SIR) must be disabled. Refer to ”Disabling the
SIR” and ”Sensing and Diagnostic Module(SDM)” in this
section for instructions on how to disable the SIR and re-
place the SDM.
The SIR Diagnostic System Check must always be the
starting point for any SIR diagnosis. The Diagnostic Sys-
tem Check reveals diagnostic trouble codes(DTCs)
through the use of scan tool. The diagnostic procedures
used in this section are designed to find any repair SIR
conditions. To get the best results, it is important to use the
diagnostic charts and follow the sequence listed below.
1. Perform the SIR Diagnostic System Check, which
reveal diagnostic trouble codes(DTCs) through theuse of scan tool.. It also checks for proper airbag
indicator operation.
2. Refer to the proper diagnostic chart as directed by
SIR Diagnostic System Check. Bypassing these
procedures may result in extended diagnostic time,
incorrect diagnosis, and incorrect parts replace-
ment.
3. Repeat the SIR Diagnostic System Check after any
repair or diagnostic procedures have been per-
formed to ensure that the repair has been made
correctly and that no other malfunction exists.
Circiut Description
When the ignition switch is first turned to ON, ignition volt-
age is supplied from airbag fuse to find the SDM at input
terminal A1. The SDM responds by flashing the airbag in-
dicator seven times and then turning it off while the SDM
performs tests on the SIR.
Diagnostic Aids
The order in which DTCs are diagnosed is very important.
Failure to diagnose the DTCs in the order specified may
result in extended diagnostic time, incorrect diagnosis,
and incorrect parts replacement.
SIR Diagnostic System Check
CAUTION : The sensing and the diagnosis module
(SDM) can maintain surfficient voltage to deploy the
airbags and pretensioners for 1 minute after the igni-
tion is OFF and the fuse has been removed. If the air-
bags and pretensioners are not disconnected, do not
begin service until one minute has been passed after
disconnecting power to the SDM. Otherwise, injury
could result.
CAUTION : During service procedure, be very careful
when handling the SDM. Never strike or jar the SDM.Never power the supplemental inflatable re-
straints(SIR) when the SDM is not rigidly attached to
the vehicle. All SDM mounting bolts must be carefully
tightened , and the arrow on the SDM must be point
toward the front of the vehicle to ensure proper op-
eration of the SIR. The SDM could be activated if it is
powered when it is not rigidly attached to the vehicle,
resulting in unexpected deployment and possible in-
jury.
Step
ActionValue(s)YesNo
11. Turn the ignition switch ON.
2. Observe the airbag indicator as the ignition is
being turned ON. Does the indicator flash
seven times?–System OKGo to Step 2
21. Turn the ignition to LOCK and remove the key.
2. Connect the scan tool to the data link connec-
tor(DLC). Follow the directions given in the
scan tool manual.
3. Are any DTCs displayed on the scan tool?–Go to the
DTC check
procedureGo to Step 3
3Check the fuse F1 in the interior fuse box.
Is the fuse F1 blown?–Go to Step 4Go to Step 5
4Replace the fuse F1.–––
51. Disconnect the connector C207.
2. Check the wiring shortage between the fuse F1
and the terminal 1 of the connector C207.
3. Is the wiring shorted? Then, repair the wiring.––Go to Step 6

Load next 8 pages

Page: < prev 1-10 ... 2073-2080 2081-2088 2089-2096 2097-2104 2105-2112 2113-2120 2121-2128 2129-2136 2137-2144 ... 2648 next >

reset oil filter cooling CD player brake rotor lane assist
