Page 2057 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 7D – 2IAUTOMATIC TEMPERATURE CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM
DAEWOO V–121 BL4
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNSmLb–FtLb–In
Blower Motor

Page 2058 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AUTOMATIC TEMPERATURE CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM 7D – 3
DAEWOO V–121 BL4
SCHEMATIC AND ROUTING DIAGRAMS
A/C SENSORS/DEFOGGERS AND A/C COMPRESSOR
CONTROLS DIAGRAM

Page 2059 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 7D – 4IAUTOMATIC TEMPERATURE CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM
DAEWOO V–121 BL4
A/C BLOWER AND MOTOR CONTROLS DIAGRAM

Page 2060 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AUTOMATIC TEMPERATURE CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM 7D – 5
DAEWOO V–121 BL4
DIAGNOSIS
GENERAL A/C DIAGNOSTICS
Refer to Section 7B, Manual Control Heating, Ventilation,

Page 2061 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 7D – 6IAUTOMATIC TEMPERATURE CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM
DAEWOO V–121 BL4
AUTOMATIC TEMPERATURE CONTROLLER DOES NOT
OPERATE WHEN IGNITION IS ON
StepActionValue(s)YesN

Page 2062 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AUTOMATIC TEMPERATURE CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM 7D – 7
DAEWOO V–121 BL4
CONTROLLER DOES NOT ILLUMINATE WHEN LIGHT
SWITCH IS ON
StepActionValue(s)YesNo
1Check other

Page 2063 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 7D – 8IAUTOMATIC TEMPERATURE CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM
DAEWOO V–121 BL4
NO HOT AIR FROM BLOWER
StepActionValue(s)YesNo
1Check the coolant level.
Is the coolant leve

7D – 8IAUTOMATIC TEMPERATURE CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM
DAEWOO V–121 BL4
NO HOT AIR FROM BLOWER
StepActionValue(s)YesNo
1Check the coolant level.
Is the coolant level correct?–Go to Step 3Go to Step 2
2Add coolant as needed.
Is the heater operating?–System OKGo to Step 3
31. Turn the ignition to ON.
2. Observe the temperature indication screen of
the controller.
Does the digit flash on and off?–Go to Step 4Go to Step 5
4Run a self–diagnosis circuit check.
Does the display indicate a defect code?–Go to the table
for the code
that flashesGo to Step 7
5Observe the blower motor operation.
Is the blower motor functioning at all?–Go to Step 6Go to ”Blower
Motor Does
Not Run at All”
6Use the blower push switch to cycle the blower
through its different speeds.
Does the motor function at different speeds?–Go to Step 7Go to ”Code 6
– Power Tran-
sistor Error”
71. Run the blower and operate the MODE push
switch manually.
2. Check for airflow out the various outlets.
Does the air flow from the different outlets as it
should?–Go to Step 9Go to Step 8
81. Remove the heater outlet and check for ob-
structions.
2. Remove any obstructions found.
Is the heater operating?–System OKGo to Step 9
9Observe the air mix door (AMD) motor while chang-
ing the temperature setting from 18 to 32°C (64 to
90°F) and then from 32 to 18°C (90 to 64°F).
Is the AMD motor functioning properly?–Go to Step 10Go to”Code 4 –
Air Mix Door
Error”
10Check the coolant hoses for leaks or kinks.
Are the coolant hoses in good condition?–Go to Step 12Go to Step 11
11Repair any problem with the coolant hoses.
Is the heater operating?–System OKGo to Step 12
12Check the surge tank cap.
Is the surge tank cap in good condition?–Go to Step 14Go to Step 13
13Repair or replace the surge tank cap as needed.
Is the heater operating?–System OKGo to Step 14
141. Set the A/C switch to OFF.
2. Set the temperature control to 32°C (90°F).
3. Set the blower motor speed to full high (all seg-
ments illuminated on the display).
4. Remove the surge tank cap.
5. Start the vehicle and run the engine at idle.
6. Watch for the flow of the coolant when the ther-
mostat opens.
Does the coolant flow?–Go to Step 16Go to Step 15

Page 2064 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AUTOMATIC TEMPERATURE CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM 7D – 9
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
151. Check for
S A faulty thermostat.
S A failed coolant pump i

AUTOMATIC TEMPERATURE CONTROL HEATING, VENTILATION, AND AIR CONDITIONING SYSTEM 7D – 9
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
151. Check for
S A faulty thermostat.
S A failed coolant pump impeller.
S A restriction in the cooling system.
2. Make repairs as needed.
Is the repair complete?–System OK–
16Check the temperature of the heater inlet and outlet
hoses by feel.
Is the heater inlet hose hot and the outlet hose
warm?–Go to Step 18Go to Step 17
17Back flush or replace the heater core.
Is the repair complete?–System OK–
18Check the vehicle for cold air leaks at the
S Dash.
S Heater cases.
S Vents.
Are any leaks found?–Go to Step 20Go to Step 19
19Repair any cold air leaks.
Is the repair complete?–System OK–
20Check the coolant temperature sensor using the
tests in ”Code 3 – Coolant Temperature Sensor Er-
ror.”
Is there a problem indicated in the sensor, the sensor
wiring, or the controller?–Go to Step 21Go to Step 22
21Repair or replace the sensor, the wiring, or the con-
troller as required.
Is the repair complete?–System OK–
22Check the in–car sensor using the tests in ”Code 1
– In–Car Sensor Error.”
Is there a problem indicated in the sensor, the sensor
wiring, or the controller?–Go to Step 23Go to Step 24
23Repair or replace the sensor, the wiring, or the con-
troller as required.
Is the repair complete?–System OK–
24Check the ambient air temperature sensor using the
tests in ”Code 2 – Ambient Air Temperature Sensor
Error.”
Is there a problem indicated in the sensor, the sensor
wiring, or the controller?–Go to Step 25Go to Step 26
25Repair or replace the sensor, the wiring, or the con-
troller as required.
Is the repair complete?–System OK–
26Check the sun sensor using the tests in ”Code 5 –
Sun Sensor Error.”
Is there a problem indicated in the sensor, the sensor
wiring, or the controller?–Go to Step 27Go to Step 28
27Repair or replace the sensor, the wiring, or the con-
troller as required.
Is the repair complete?–System OK–
28Replace the ATC controller.
Is the repair complete?–System OK–
