DAEWOO NUBIRA 2004 Service Repair Manual 5A1 – 236IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
ELECTRONICAL COMPONENTS
Selector Lever/Program Switch
The driver engages the travel position via the selector le-
ver:
P : Park Position
R

5A1 – 236IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
ELECTRONICAL COMPONENTS
Selector Lever/Program Switch
The driver engages the travel position via the selector le-
ver:
P : Park Position
R : Reverse
N : Neutral
D : Forward Speeds
Park/Neutral Position Switch
The Park/Neutral Position Switch is located on the selec-
tor shaft and informs the TCM of the current selector lever
position P–R–N–D–3–2–1.
The selector lever position is transmitted to the TCM in en-
coded form along 4 lines. The encoding is such that mal-
functions in the connecting lead are identified.
The Park/Neutral Position Switch is located on the selec-
tor shaft, which is connected to the selector lever via a pull
cable. In addition, the Park/Neutral Position Switch con-
trols the starter interlock, the reversing light and the selec-
tor lever position indicator on the instrument panel.
Signal Combination
L1L2L3L4
P00120
R00012
N01200
D1212120
31212012
21201212
10121212
Automatic Transaxle Output Speed Sensor
(A/T OSS)
The vehicle A/T OSS is a magnetic inductive pickup that
relays information relative to vehicle speed to the TCM.
Vehicle speed information is used by the TCM to control
shift timing, line pressure, and TCC (lock–up clutch) apply
and release.
The output speed sensor mounts in the case at the speed
sensor rotor, which is pressed onto the spur gear. An air
gap of 0.1mm~1.3mm(0.004~0.05in) is maintained be-
tween the sensor and the teeth on the spur gear teeth. The
sensor consists of a permanent magnet surrounded by a
coil of wire.
As the differential rotates, an AC signal is generated by the
output speed sensor (OSS).
Automatic Transaxle Input Speed Sensor
(A/T ISS)
The A/T ISS is a magnetic inductive pickup that relays in-
formation relative to transaxle input speed to the TCM.
The TCM uses transaxle input speed information to con-
trol line pressure, TCC apply and release and transaxle
shift patterns. This information is also uses to calculate the
appropriate operating gear ratios and TCC slippage.
The input speed sensor mounts onto piston B that is inside
of valve body.
An air gap of 1.8~2.2mm(0.07~0.086inch) is maintained
between the sensor and the piston B.
The sensor consists of a permanent magnet surrounded
by a coil of wire. As the piston B is driven by the turbine
shaft, an AC signal induced in the input speed sensor.
Higher vehicle speeds induce a higher frequency and volt-
age measurement at the sensor.
Sensor resistance should measure between 825~835
ohms at 20°C (68°F). Sensor can measure from
1,000~8,000HZ.

Page 1586 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 237
DAEWOO V–121 BL4
Shift Solenoid Valve: Solenoid 1,2
The shift solenoids are two identical, normally open elec-
tronic exhaust work that control upshifts a

Page 1587 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A1 – 238IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Transaxle Fluid Temperature (TFT) Sensor
The TFT sensor is a positive temperature coefficient
thermistor (temperature sensitive resistor)

5A1 – 238IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Transaxle Fluid Temperature (TFT) Sensor
The TFT sensor is a positive temperature coefficient
thermistor (temperature sensitive resistor) that provides
information to the TCM regarding transaxle fluid tempera-
ture. The temperature sensor is located in valve body. Cal-
culated temperature is a factor used to determine the shift
time and shift delay time.
The internal electrical resistance of the sensor varies in
relation to the operating temperature of the transaxle fluid
(see chart).
The TCM sends a 5 volt–reference signal to the tempera-
ture sensor and measures the voltage rise in the electrical
circuit. A higher fluid temperature creates a higher resist-
ance in the temperature sensor, thereby measuring a low-
er voltage signal.
The TCM measures this voltage as another input to help
control line pressure, shift schedules and TCC apply.
When transaxle fluid temperature reaches 140°C (284°F)
the TCM enters ”hot mode.” Above this temperature the
TCM modifies transaxle shift schedules and TCC apply in
an attempt to reduce fluid temperature by reducing trans-
axle heat generation. During hot mode the TCM applies
the TCC at all times in fourth gear.
Also, the TCM commands the 2–3 and 3–4 shifts earlier
to help reduce fluid heat generation. Hot mode may not be
available on some applications.
Transaxle Sensor – Temperature To
Resistance To Voltage (approximate)
°C (°F)R high (ohms)R low (ohms)°C (°F)R high (ohms)R low (ohms)
–40 (–40)58655650 (122)1,2061,173
–30 (–22)64161160 (146)1,2951,256
–20 (–4)69967070 (158)1,3881,341
–10 (14)76073280 (176)1,4851,430
0 (32)82579990 (194)1,5851,522
10 (50)893868100 (212)1,6901,617
20 (68)963942110 (230)1,7981,715
25 (77)1,000980120 (248)1,9101,816
30 (86)1,0391,017130 (266)2,0251,920
140 (284)2,1452,027
Transaxle Electrical Connector
The transaxle electrical connector is a very important part
of the transaxle operating system. Any interference with
the electrical connection can cause the transaxle to set
Diagnostic Trouble Codes (DTCs) and/or affect proper op-
eration.
The following items can affect the electrical connections:S Bent pins in the connector from rough handling dur-
ing connection and disconnection.
S Wires backing away from the pins or coming un-
clamped (in either internal or external wiring har-
ness).
S Dirt contamination entering the connector when dis-
connected.
S Pins in the internal wiring connector backing out of
the connector or pushed out during reconnection.

Page 1588 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 239
DAEWOO V–121 BL4
S Excessive transaxle fluid leaking into the connector,
wicking up into the external wiring harness, and
degrading the wire insulation.

Page 1589 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A1 – 240IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Data Link Connector (CAN TYPE) 1.8L DOHC (Delphi 32 bit)
A Connector (Blue)B Connector (Green)C Connector (Gray)
1Solenoid 2Fluid Temperat

Page 1590 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 241
DAEWOO V–121 BL4
TCM INPUTS THAT AFFECT THE 4HP
16 TRANSAXLE
Throttle Position Sensor
S Provides throttle position data to the TCM for deter-
mining shif

Page 1591 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual SECTION : 5A2
AISIN AUTOMATIC TRANSAXLE
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with

SECTION : 5A2
AISIN AUTOMATIC TRANSAXLE
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical erminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS5A2–3 . . . . . . . . . . . . . . . . . . . . . . . . .
