Page 921 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 2C – 4IFRONT SUSPENSION DAEWOO V–121 BL4 J–42468 Front Strut Mount Nut Wrench

Page 922 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual FRONT SUSPENSION 2C – 5 DAEWOO V–121 BL4 DIAGNOSIS STRUT DAMPENER A strut dampener is basically a shock absorber. However, strut dampeners are easier to extend and retract by hand than are shock

Page 923 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 2C – 6IFRONT SUSPENSION DAEWOO V–121 BL4 BALL JOINT AND KNUCKLE Ball Joint Inspection 1. Raise the front of the vehicle to allow the front sus- pension to hang free. 2. Grasp the tire at the top

Page 924 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual FRONT SUSPENSION 2C – 7 DAEWOO V–121 BL4 COMPONENT LOCATOR FRONT SUSPENSION

Page 925 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 2C – 8IFRONT SUSPENSION DAEWOO V–121 BL4 1. Cap 2. Strut Upper Nut 3. Piston Rod Nut 4. Strut Mount 5. Strut Bearing 6. Washer 7. Upper Spring Seat 8. Front Spring Locator 9. Upper Spring Ins

Page 926 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual FRONT SUSPENSION 2C – 9 DAEWOO V–121 BL4 MAINTENANCE AND REPAIR ON–VEHICLE SERVICE STABILIZER SHAFT AND INSULATORS Removal Procedure 1. Raise and suitably support the vehicle. 2. Remove the s

Page 927 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 2C – 10IFRONT SUSPENSION DAEWOO V–121 BL4 3. Install the stabilizer link onto the stabilizer shaft and connect them with the stabilizer shaft–to–stabilizer link nut. Tighten S Tighten the st

Page 928 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual FRONT SUSPENSION 2C – 11 DAEWOO V–121 BL4 4. Remove the brake caliper from the rotor. Support the caliper so it does not hang from the hydraulic brake hose. Refer to Section 4D, Front Disc Brake
