Page 1737 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 147 DAEWOO V–121 BL4 45. Turn the spacer and lever shaft to align the small hole for locating the staking position in the spacer with the staking position mark on

Page 1738 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 148IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 50. Install the parking lock pawl bracket with the 2 bolts. Tighten Tighten the bolts to 7.4 NSm (65 lb–in). 51. Using counter drive gear i

Page 1739 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 149 DAEWOO V–121 BL4 54. Using a small torque wrench, while turning to count- er drive gear 100 turn per minute and measure the preload. Notice : When the preload

Page 1740 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 150IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 59. Check that the planetary gear turns freely counter- clockwise and locks clockwise. 60. Install the anti–rattle clip in the place shown

Page 1741 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 151 DAEWOO V–121 BL4 63. Install the flange, 2 discs and 2 plates. S Install in order : F  D  P  D  P (D = Disc, P = Plate, F = Flange) 64. Install the 2nd

Page 1742 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 152IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 68. Using brake spring compressor bolt / nut DW240–060–01 and 2nd brake adapter DW240–080, compress the 2nd brake piston return spring.

Page 1743 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 153 DAEWOO V–121 BL4 73. Coat the thrust bearing race with petroleum jelly and install it onto the rear planetary sun gear and one–way clutch assembly. S Bearig

Page 1744 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 154IAISIN AUTOMATIC TRANSAXLE DAEWOO V–121 BL4 77. Install the forward clutch hub to the transaxle case. 78. Coat the thrust bearing race with petroleum jelly and install it onto the forwa
