DAEWOO NUBIRA 2004 Service Repair Manual ENGINE EXHAUST 1G – 9
DAEWOO V–121 BL4
GENERAL DESCRIPTION
AND SYSTEM OPERATION
EXHAUST SYSTEM
Notice : When you are inspecting or replacing the exhaust
system components, make sure there is adeq

Page 890 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual SECTION 2
POSITION OF CONNECTORS AND GROUNDS
CONTENTS
1. CONNECTOR, GROUND AND SPLICE PACK INFORMATION 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. WIRING H

Page 891 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 2–2WPOSITION OF CONNECTORS AND GROUNDS
1.CONNECTOR, GROUND AND SPLICE PACK INFORMATION
1) WIRING HARNESS, GROUND & SPLICE PACK LOCATION

Page 892 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual POSITION OF CONNECTORS AND GROUNDSW2–3
2) CONNECTOR INFORMATION
Connector
Number
Te r m i n a l
NumberColorConnecting Wiring
HarnessConnector Position
C10121 PinWhiteBody Engine Fuse BlockEngine F

POSITION OF CONNECTORS AND GROUNDSW2–3
2) CONNECTOR INFORMATION
Connector
Number
Te r m i n a l
NumberColorConnecting Wiring
HarnessConnector Position
C10121 PinWhiteBody Engine Fuse BlockEngine Fuse Block
C10211 P i nWhiteBody Engine Fuse BlockEngine Fuse Block
C10310 PinWhiteEngine Engine Fuse BlockEngine Fuse Block
C10424 PinWhiteFront Engine Fuse BlockEngine Fuse Block
C1054 PinWhiteBody Engine Fuse BlockEngine Fuse Block
C10620 PinWhiteEngine Engine Fuse BlockEngine Fuse Block
C1072 PinWhiteABS Engine Fuse BlockEngine Fuse Block
C10824 PinBlackBody EngineLeft Engine Fuse Block
C1094 PinWhiteEngine FrontUnder Engine Fuse Block
C11012 PinWhiteABS BodyBelow Engine Fuse Block
C 1112 PinBlackABS FrontBelow Engine Fuse Block
C1122 PinBlackFront – HornCenter Cross Member Panel
C11316 PinBlackBody FrontBehind ECM Bracket
C20176 PinBlackI.P I.P Fuse BlockI.P Fuse Block
C20289 PinWhiteI.P BodyLeft CO–Driver Leg Room
C2048 PinWhiteRoof Body (W/O Rain Sensor)Left CO–Driver Leg Room
C20414 PinWhiteRoof Body(W/ Rain Sensor)Left CO–Driver Leg Room
C20622 PinWhiteI.P TCMUpper Driver Leg Room
C2076 PinWhiteAir Bag I.PUpper Left Driver Leg Room
C20815 PinWhiteI.P FAT CBehind Glove Box
C20920 PinBlackFAT C FAT C . A u xBetween Heater Core and
Evaporator Core
C2106 PinWhiteI.P ConsoleBelow Console Box
C3018 PinWhiteAir Bag BodyFront SDM
C3024 PinBlackRR. ABS BodyCenter Rear Cross Member
C35133 PinGrayBody Front Light DoorUnder CO–Driver A Pillar
C36133 PinGrayBody Front Right DoorUnder Driver A Pillar
C37112 PinWhiteBody Rear Light DoorUnder Left B Pillar
C38112 PinWhiteBody Rear Right DoorUnder Right B Pillar
C401 (N/B)8 PinWhiteTrunk BodyInside Right Trunk Side Cover
C401 (H/B)6 PinWhiteTrunk BodyInside Right Trunk Side Cover
C4026 PinWhiteTrunk LID BodyInside Right Trunk Side Cover
C4036 PinWhiteT/Gate. EXT. – BodyInside Left C Pillar
C4048 PinWhiteT/Gate. EXT. – BodyInside Left C Pillar
C4058 PinWhiteT/Gate. EXT. – T/GateBeside Left Rear Wiper Motor
C4066 PinWhiteT/Gate. EXT. – T/GateBeside Left Rear Wiper Motor
3) GROUND INFORMATION
Ground Number
Wiring HarnessGround Position
G101FrontBehind Left Head Lamp
G102FrontBehind Right Head Lamp
G103BatteryLeft Battery
G104EngineUnder Start Motor
G105BatteryUnder Start Motor
G106ABSBelow EBCM
G107Engine(MR–140/HV–240)Under Start Motor
G201I.PLeft I/P Fuse Block
G202Air BagBehind Left Audio Bracket
G203I.PBehind Left Audio Bracket
G205RoofUpper Driver Leg Room
G301BodyBelow Driver Cross Member Floor Panel
G302BodyBelow Left C Pillar
G303BodyBelow Left CO–Driver Leg Room
G401TrunkCenter Trunk Lower Back Panel
G402T/Gate. EXT.Inside Driver C Pillar
4) SPLICE PACK INFORMATION
Splice Pack Number
ColorWiring HarnessGround Position
S101BlackEngine(MR–140/HV–240)Upper Transmission
S202BlackI.PBehind Cluster
S203RedI.PBehind Audio Mounting
S204MagentaI.PBehind Audio Mounting
S205OrangeTCM (MR–140/HV–240)Upper Driver Leg Room
S301BlueBodyLeft CO–Driver Leg Room
S302BrownBodyLeft CO–Driver Leg Room

Page 893 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 2–4WPOSITION OF CONNECTORS AND GROUNDS
2. WIRING HARNESS, CONNECTOR & GROUND LOCATION
1) W/H INSTRUMENT PANEL

Page 894 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual POSITION OF CONNECTORS AND GROUNDSW2–5
2) W/H BODY

Page 895 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 2–6WPOSITION OF CONNECTORS AND GROUNDS
3) W/H FRONT
4) W/H ENGINE
– SIRIUS D4
– MR–140 / HV–240

Page 896 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual POSITION OF CONNECTORS AND GROUNDSW2–7
5) W/H BATTERY
– SIRIUS D4
– MR–140 / HV–240
6) W/H ABS
7) W/H REAR ABS
