Page 1769 of 2643
AISIN AUTOMATIC TRANSAXLE 5A2 – 179
DAEWOO V–121 BL4
Disassembly Procedure
1. Using a screwdriver, remove the snap ring.
2. Remove the planetary ring gear flange from the
planetary ring gear.
Assembly Procedure
1. Install a new planetary ring gear flange to the plan-
etary ring gear.
2. Using a screwdriver, install the snap ring.
Page 1770 of 2643
5A2 – 180IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
ONE–WAY CLUTCH
1. Snap Ring
2. One–Way Clutch3. 2nd Brake Hub
4. Retainer
Page 1771 of 2643
AISIN AUTOMATIC TRANSAXLE 5A2 – 181
DAEWOO V–121 BL4
Disassembly Procedure
1. Install the one–way clutch and thrust washer to the
rear planetary sun gear.
2. Hold the rear planetary sun gear and turn the one–
way clutch. The one–way clutch should turn freely
clockwise and should lock counterclockwise.
3. Using a screwdriver, remove the snap ring from the
2nd brake hub.
4. Remove the one–way clutch from the 2nd brake
hub.
5. Using a small screwdriver, remove the retainer from
the 2nd brake hub.
Page 1772 of 2643
5A2 – 182IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Assembly Procedure
1. Install the retainer to the 2nd brake hub.
2. Install the one–way clutch.
3. Using a screwdriver, install the snap ring.
4. Install the one–way clutch and thrust washer to the
rear planetary sun gear.
5. Hold the rear planetary sun gear and turn the one–
way clutch. The one–way clutch should turn freely
clockwise and should lock counterclockwise.
Page 1773 of 2643
AISIN AUTOMATIC TRANSAXLE 5A2 – 183
DAEWOO V–121 BL4
FORWARD AND REVERSE CLUTCH
1. Seal Ring
2. Flange
3. Disc
4. Plate
5. Flange
6. Snap Ring
7. Flange
8. Disc
9. Plate10. Snap Ring
11. Clutch Balancer
12. Forward Clutch Retrun Spring
13. Forward Clutch Piston
14. O–Ring
15. Forward Clutch Drum
16. O–Ring
17. Intermediate Shaft Sub–assembly
Page 1774 of 2643

5A2 – 184IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Tools Required
DW240–020 Brake/Clutch Spring Compressor
DW240–030 Forward Clutch Adapter
DW240–120 Measuring Terminal
Disassembly Procedure
WARNING : USE CAUTION WHEN CHECKING COM-
PONENTS WITH COMPRESSED AIR OR PERSONAL
INJURY MAY RESULT.
1. Install the forward and reverse clutch and thrust
needle roller bearing on the transaxle rear cover.
2. Using a dial indicator, measure the reverse clutch
pack clearance while applying and releasing 392
kPa (57 psi) of compressed air.
S Pack clearance: 0.40 1.00 mm (0.0157
0.0394 in.)
S If the stroke is non–standard, inspect the discs,
plates and flange.
WARNING : USE CAUTION WHEN CHECKING COM-
PONENTS WITH COMPRESSED AIR OR PERSONAL
INJURY MAY RESULT.
3. Install the forward and reverse clutch and thrust
needle roller bearing on the transaxle rear cover.
4. Using a dial indicator and measuring terminal
DW240–120, measure the forward clutch pack
clearance while applying and releasing 392 kPa (57
psi). of compressed air.
S The forward and reverse clutch will come out as
you apply the compressed air. Therefore, while
the checking is being done, press on the input
shaft of the forward and reverse clutch using
stamping machine or alike so that the pressure
is not applied on the forward and reverse clutch.
S Pack clearance: 1.1–1.5 mm (0.043 0.059 in.)
If the stroke is non–standard, inspect the discs,
plates and flange.
5. Using a screwdriver, remove the reverse clutch
snap ring.
Page 1775 of 2643
AISIN AUTOMATIC TRANSAXLE 5A2 – 185
DAEWOO V–121 BL4
6. Remove the 2 flanges, 2 discs and plate from the
reverse clutch drum.
7. Using a screwdriver, remove the snap ring.
8. Remove the flange, 3 discs and 3 plates from the
forward clutch drum.
9. Using brake/clutch spring compressor DW240–020
and forward clutch adapter DW240–030, compress
the spring.
10. Using a snap ring expander, remove the snap ring.
Notice : Stop the press when the clutch balancer is low-
ered to the place 1–2 mm (0.039–0.078 in.) from the snap
ring groove, preventing the clutch balancer from being de-
formed.
Notice : Do not expand the snap ring excessively.
Page 1776 of 2643

5A2 – 186IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
11. Remove the clutch balancer and forward clutch re-
turn spring.
WARNING : USE CAUTION WHEN REMOVING COM-
PONENTS WITH COMPRESSED AIR OR PERSONAL
INJURY MAY RESULT.
12. Install the forward and reverse multiple disc clutch
on the transaxle rear cover.
13. Apply 392 kPa (57 psi) of compressed air to the
transaxle rear cover to remove the forward clutch
piston.
Notice : Blowing off the air may cause the piston’s jump–
out.When removing the piston, hold it with your hand using
a waste cloth.
Notice : Take care not to splash ATF when air–blowing.
S When the piston can not be removed as it is
slanted, either blow the air again with the pro-
truding side pushed or remove the piston using
a needle nose pliers with vinyl tape on the tip.
WARNING : USE CAUTION WHEN REMOVING COM-
PONENTS WITH COMPRESSED AIR OR PERSONAL
INJURY MAY RESULT.
14. Apply 392 kPa (57 psi) of compressed air to the
transaxle rear cover to remove the forward clutch
drum.
Notice : Blowing off the air may cause the drum’s jump–
out. When removing the drum, hold it with your hand using
a waste cloth.
Notice : Take care not to splash ATF when air–blowing.
S When the drum can not be removed as it is
slanted, either blow the air again with the pro-
truding side pushed or remove the drum using a
needle nose pliers with vinyl tape on the tip.
