6A – 4IPOWER STEERING SYSTEM
DAEWOO V–121 BL4
FLUID RESERVOIR
Removal Procedure
1. Siphon the power steering fluid from the fluid reser-
voir.
2. Loosen the hose clamps and remove both hoses
from the fluid reservoir.
3. Remove the fluid reservoir nuts.
Installation Procedure
1. Attach the fluid reservoir to the fluid reservoir brack-
et.
2. Fix the fluid reservoir with the nuts.
Tighten
Tighten the fluid reservoir nuts to 10 NSm.
3. Connect both hoses to the fluid reservoir and se-
cure the hose clamps.
Notice : When adding fluid or making a complete change,
always use DEXRON®–II or III power steering fluid. Fail-
ure to use the proper fluid will cause hose and seal dam-
age and fluid leaks.
4. Fill the fluid reservoir with power steering fluid.
5. Inspect for leaks. If there are leaks, correct the
cause of the leaks and bleed the system. Refer to
”Bleeding the Power Steering System” in this sec-
tion.
HOSES AND PIPES
Power Steering Pump Hoses and Pipes
(Left–Hand Drive Shown, Right–Hand Drive
Similar)
Removal Procedure
1. Siphon the power steering fluid from the fluid reser-
voir.
2. Disconnect the pressure line pipe and the supply
line hose from the inlet and outlet connections on
the power steering pump.
Page 1906 of 2643
POWER STEERING SYSTEM 6A – 5
DAEWOO V–121 BL4
3. Disconnect the return and supply line from the fluid
reservoir.
4. Loosen the retaining clip located above the alterna-
tor and position it away from the pressure line.
5. Raise and suitably support the vehicle.
6. Disconnect the pressure line from the power steer-
ing gear inlet.
7. Disconnect the return line outlet pipe from the pow-
er steering gear.
8. Remove the return line from the clip on the cross-
member.
Page 1907 of 2643
6A – 6IPOWER STEERING SYSTEM
DAEWOO V–121 BL4
9. Remove the bolts from each of the two clips on the
radiator.
10. Remove all the hoses and pipes from the vehicle.
11. Lower the vehicle.
Installation Procedure
1. Route the pressure line from the power steering
pump to the power steering gear.
2. Raise and suitably support the vehicle.
3. Route the return line from the fluid reservoir to the
power steering gear.
4. Install the two bolts on the radiator.
Tighten
Tighten the return line clip bolts to 8 NSm (71 lb–in).
5. Install the return line into the clip on the crossmem-
ber.
Tighten
Tighten the return line clip bolt to 8 NSm (71 lb–in).
6. Connect the return line to the power steering gear
outlet.
Tighten
Tighten the return line fitting to 28 NSm (21 lb–ft).
7. Connect the pressure line to the power steering
gear inlet.
Tighten
Tighten the pressure line fitting to 28 NSm (21 lb–ft).
Page 1908 of 2643
POWER STEERING SYSTEM 6A – 7
DAEWOO V–121 BL4
8. Lower the vehicle.
9. Secure the pressure line with the retaining clip lo-
cated above the alternator.
Tighten
Tighten the pressure line retaining clip bolt to 8 NSm
(71 lb–in).
10. Connect the return and supply line to the fluid res-
ervoir.
11. Connect the pressure line pipe and the supply line
hose to the outlet and inlet connections on the pow-
er steering pump.
Tighten
Tighten the pressure line fitting to 28 NSm (21 lb–ft).
Notice : When adding fluid or making a complete change,
always use DEXRON®–II or III power steering fluid. Fail-
ure to use the proper fluid will cause hose and seal dam-
age and fluid leaks.
12. Fill the fluid reservoir with power steering fluid.
13. Inspect for leaks. If there are leaks, correct the
cause of the leaks and bleed the system. Refer to
”Bleeding the Power Steering System” in this sec-
tion.
Page 1909 of 2643

6A – 8IPOWER STEERING SYSTEM
DAEWOO V–121 BL4
GENERAL DESCRIPTION
AND SYSTEM OPERATION
POWER STEERING SYSTEM
General Description
The power steering system consists of three components:
the power steering pump, the power steering fluid reser-
voir and the the power steering rack and pinion gear. The
power steering pump is a vane–type pump providing hy-
draulic pressure for the system and is powered by the en-gine. It draws on the power steering fluid reservoir, which
in turn is connected to the power steering gear. A pres-
sure–relief valve inside the flow control valve limits the
pump pressure. The power steering rack and pinion gear
has a rotary control valve which directs hydraulic fluid
coming from the power steering pump to one side or the
other side of the rack piston. The integral rack piston is at-
tached to the rack. The rack piston converts hydraulic
pressure to a linear force which moves the rack to the left
or the right. The force is then transmitted through the inner
and the outer tie rods to the steering knuckles, which turn
the wheels.
Page 1910 of 2643

SECTION : 6B
POWER STEERING PUMP
TABLE OF CONTENTS
SPECIFICATIONS6B–1 . . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications 6B–1. . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 6B–1. . . . . . . . . . .
DIAGNOSIS6B–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Steering Pump Diagnosis 6B–2. . . . . . . . . . . . .
MAINTENANCE AND REPAIR6B–3 . . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 6B–3. . . . . . . . . . . . . . . . . . . . . Serpentine Accessory Drive Belt 6B–3. . . . . . . . . . . . .
Pump Assembly 6B–4. . . . . . . . . . . . . . . . . . . . . . . . . . .
UNIT REPAIR 6B–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pump 6B–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION6B–8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Steering Pump 6B–8. . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS
GENERAL SPECIFICATIONS
ApplicationDescription
LubricantPower Steering Fluid DEXRON®–II or III
Pressure
– without EVO8330 kPa ~ 8820 kPa (1208 psi ~ 1279 psi)
– with EVO8500 kPa ~ 8960 kPa (1233 psi ~ 1299 psi)
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNSmLb–FtLb–In
Air Filter Housing Assembly Bolts6–53
High–Pressure Hose Fitting2821–
Power Steering Pump Bolts2518–
Right Side Power Steering Pump Bracket Bolts3526–
Page 1911 of 2643

6B – 2IPOWER STEERING PUMP
DAEWOO V–121 BL4
DIAGNOSIS
POWER STEERING PUMP DIAGNOSIS
Foaming or Milky Power Steering Fluid (Air in Fluid)
ChecksAction
Check for internal leakage in the power steering pump,
causing an overflow.Repair the internal pump leakage.
Bleed the system.
Check for a low fluid level.Repair the internal pump leakage.
Bleed the system.
Cold temperatures will cause the air bubbles in the system
if the fluid level is low.
Low Pressure Due to Power Steering Pump
ChecksAction
Check for an external leakage of the power steering pump
at the seals.Replace the seals.
Repair the leak.
Bleed the system.
Check for a worn serpentine accessory drive belt.Replace the serpentine accessory drive belt.
Low Pressure Due to Power Steering Gear
ChecksAction
Check for a scored housing bore.Replace the housing bore.
Check for leakage at the valve rings or the seals.Repair the leak.
Bleed the system.
Groaning Noise in the Power Steering Pump
ChecksAction
Check for air in the power steering fluid.Perform the checks listed in ”Foaming or Milky Power
Steering Fluid (Air in Fluid)” above.
Check for a low level of power steering fluid.Repair any internal or external leaks.
Bleed the system.
Check for a loose mounting of the power steering pump.Tighten the pump mounting to specifications.
Page 1912 of 2643
POWER STEERING PUMP 6B – 3
DAEWOO V–121 BL4
MAINTENANCE AND REPAIR
ON–VEHICLE SERVICE
SERPENTINE ACCESSORY DRIVE
BELT
Removal Procedure
1. Remove the air filter housing assembly bolts and
the air intake tube.
2. Remove the air filter housing assembly from the
vehicle.
3. Use a wrench to turn the tensioner bolt clockwise,
compressing the tensioner, and releasing the ten-
sion on the serpentine accessory drive belt.
4. Remove the serpentine accessory drive belt.
