Page 1353 of 2643
5A1 – 4IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
TRANSAXLE COMPONENTS
Page 1354 of 2643

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 5
DAEWOO V–121 BL4
SPECIFICATIONS
GENERAL SPECIFICATIONS
Definition
Transaxle Type4–speed with four–wheel drive and transverse engine
Input Torque240 NSm (177 lb–ft)
Transaxle Weight76kg (168 lb)
Torque Converter Capacity9.72kg (21.4 lb)
Transaxle Fluid Type (manufacture company)ESSO LT 71141 or TOTAL ATF H50235
Transaxle Fluid Capacity7.3qt (6.9L)
TRANSAXLE GEAR RATIO
GearRatio
First2.719
Second1.487
Third1.000
Fourth0.717
Reverse 2.529
Final3.945:1
FLUID CAPACITY
LitresQuarts
Bottom Pan Removal44.2
Complete Overhaul6.97.3
Torque Converter Removal22.1
(Measurements are approximate)
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNSmLb–FtLb–In
Bearing Plate Bolts23.517.5–
Slotted Nut220162–
Rear Cover Attachment Bolts23.517.5–
Baffle Plate Attachment Bolts10–89
Park/Neutral Position Switch10–89
Fluid Pump Connecting Bolts10–89
Fluid Filter Housing Cover Attachment Bolts10–89
Input Speed sensor Attachment Bolts8–71
Output Speed Sensor Attachment Bolts8–71
Valve Body Bolts8–71
Valve Body Upper & Lower Fixing Bolts6–53
Fluid Pan Connecting Bolts6–53
Fluid Pan Drain Plug4533–
Page 1355 of 2643
5A1 – 6IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Application Lb–InLb–Ft NSm
Fluid Level Plug4533–
Line Pleasure Plugs2015–
Valve Housing 1 Cover Attachment Bolts6–53
Solenoid Valve Attachment Bolts6–53
Pressure Control Regulator(EDS) Attachment Bolts6–53
Oil Cooler Inlet Pipe Bolts3526–
Oil Cooler Outlet Pipe Bolts3526–
Shift Control Cable Adjuster Pinch Nut8–71
Shift Control Cable Attachment Nut8–71
Upper Transaxle–to–Engine Bolts7555–
Selector Lever(On Transaxle Case)1511–
Torque Converter Attachment Bolts4533–
Shift Control Assembly Mounting Bolt, Nut8–71
Lower Engine–to–Transaxle Bolts(a)7555–
Lower Engine–to–Transaxle Bolt(b)2115–
Lower Engine–to–Transaxle Bolts(c)3123–
Rear Transaxle Mounting Bracket Bolts6245–
Damping Block Connection Bolt and Nut6850–
Left Transaxle Mount Bracket Cage Bolt(a)11 081–
Left Transaxle Mount Bracket Cage Bolt(b)6548–
Left Transaxle Mount Bracket Cage Nut(c)6548–
Left Transaxle Mounting Bolts4835–
Page 1356 of 2643

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 7
DAEWOO V–121 BL4
RangePark/
Neutr
alRever
seD321
GearNR1st2nd3rd4th1st2nd3rd1st2nd1st
Solenoid Valve
1ONON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFF
Solenoid Valve
2ONONONOFFOFFOFFONOFFOFFONOFFON
Line Pressure
Control Sole-
noid Valve 3
(EDS 3)OFFOFFOFFONON/
OFFON/
OFFOFFONON/
OFFOFFONOFF
Line Pressure
Control Sole-
noid Valve 4
(EDS 4)ONOFFONONONOFFONONONONONON
Line Pressure
Control Sole-
noid Valve 5
(EDS 5)OFFOFFONONOFFOFFONONOFFONONON
Line Pressure
Control Sole-
noid Valve 6
(EDS 6)ONOFFONONONOFFONONONONONON
Brake BAAAAAAAA
Brake CH
Brake DH
Clutch EAAAAAA
Brake FHHHHHHH
Lock–up
ClutchA
A = Applied
H = Holding
ON = The solenoid is energized.
OFF = The solenoid is de–energized.
** = Manual Second–Third gear is only available above approximately 100 km/h (62 mph).
*** = Manual First–Second gear is only available above approximately 60 km/h (37 mph).
Note : Manual First–Third gear is also possible at high vehicle speed as a safety feature.
SHIFT SPEED CHART
Up Shift Speed
MODELFirst–Second gear (±3.0
mph (4.8km/h))Second–Third gear (±4.0
mph (6.4km/h))Third–Fourth gear (±5.0
mph (8km/h))
10%
TPS25%
TPS50%
TPS100%
TPS10%
TPS25%
TPS50%
TPS100%
TPS10%
TPS25%
TPS50%
TPS100%
TPS
1.8 DOHC
mph (km/h)9
(15)11
(18)18
(29)32
(52)18
(29)23
(37)34
(55)62
(99)25
(45)34
(55)47
(76)98
(157)
Page 1357 of 2643
5A1 – 8IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Down Shift Speed
MODELDown Shift (±4.0 mph (6.4km/h))Lock Up Clutch Applied
(Fourth)Lock Up Clutch
Released
(Fourth)
Fourth–Th
ird
(Coast)Third–Sec
ond
(Coast)Second–Fi
rst
(Coast)10%25%10%25%
1.8 DOHC
mph (km/h)25 (41)13 (21)7 (11)48 (77)48 (77)42 (68)42 (68)
LINE PRESSURE
Gear RangeSolenoidLine PressureB PortE Port
Park / NeutralONLOW90~124.7 psi
(6.2~8.6 bar)
OFFHIGH221.9~252.3 psi
(15.3~17.4 bar)
ReverseONLOW89.9~124.7 psi
(6.2~8.6 bar)
OFFHIGH221.9~252.3 psi
(15.3~17.4 bar)
DriveONLOW90~124.7 psi
(6.2~8.6 bar)
OFFHIGH137.7~162.4 psi
(9.5~11.2 bar)
3ONLOW90~124.7 psi
(6.2~8.6 bar)90~124.7 psi
(6.2~8.6 bar)
OFFHIGH221.9~252.3 psi
(15.3~17.4 bar)137.7~162.4 psi
(9.5~11.2 bar)
2ONLOW90~124.7 psi
(6.2~8.6 bar)
OFFHIGH137.7~162.4 psi
(9.5~11.2 bar)
1ONLOW90~124.7 psi
(6.2~8.6 bar)
OFFHIGH221.9~252.3 psi
(15.3~17.4 bar)
Page 1358 of 2643
ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 9
DAEWOO V–121 BL4
SPECIAL TOOLS
SPECIAL TOOLS TABLE
Scan Tool
DW110–060
Engine Support Fixture
DW260–020
Transaxle Holding
Fixture
DW260–010
Transaxle Support
Fixture
DW260–030
Axle Seal Installer
DW260–050
Park/Neutral Position
Switch Installer
DW260–060
Brake F Split Stop Ring
Remover/Installer
DW260–070
Transaxle Fluid Plug
Remover/Installer
Page 1359 of 2643
5A1 – 10IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DW240–010
Universal Pressure
Gauge Set
DW260–150
Clutch E Stop Ring
Remove/Installer
DW260–140
Clutch B Stop Ring
Remover/Installer
DW260–160
Brake C/D Snap Ring
Remover/Installer
DW260–080
Clutch B/E Shim
Setting Gauge
DW260–120
Clutch B
Adjust Ring
DW260–130
Clutch E
Adjust Ring
DW260–100
Clutch B/E
Disc Thickness
Measuring Fixture
DW260–090
Clutch B/E (Snap Ring
Play, Installation
Space) Measuring
Fixture
DW260–110
Brake F Disc Clearance
Measuring Bar
Page 1360 of 2643
ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 11
DAEWOO V–121 BL4
SCHEMATIC AND ROUTING DIAGRAMS
TRANSAXLE CONTROL MODULE (1 OF 2)
