DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 35
DAEWOO V–121 BL4

Page 1626 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 36IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE DIAGNOSIS
DIAGNOSTIC TROUBLE CODE CHART
DTCDESCRIPTIONTYPEIlluminate
MILBlink
Hold
Lamp
P0562System Voltage LowBYe sNo
P

Page 1627 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 37
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0562
SYSTEM VOLTAGE LOW
Conditions for Setting the DTC
S System voltage is too low.
S TCM detects that voltag

Page 1628 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 38IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P0562 System Voltage Low
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. Turn the ignition ON, with the

5A2 – 38IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P0562 System Voltage Low
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. Turn the ignition ON, with the engine OFF.
4. Run the engine to 600 rpm or greater.
5. Record then clear DTC(s).
6. Select system voltage on the scan tool.
7. Drive the vehicle and observe the scan tool for
either of the flowing conditions:
Is the voltage within the values shown?9–16vGo to Step 4Go to Step 2
21. Disconnect the battery cable.
2. Measure the battery voltage.
Is the voltage within the values shown?9–16vGo to Step 4Go to Step 3
31. Replace the battery.
Is the replacement completed?–System OK–
41. Turn the headlamp ON.
2. Turn the air conditioner ON.
3. Run the engine to 600 rpm or greater.
4. Observe the scan tool for system voltage.
Is the voltage within the values shown?9–16vGo to Step 6Go to Step 5
51. Turn the ignition LOCK.
2. Repair the alternator circuit if necessary.
Is the action completed?–System OK–
6Inspect the EF1,F2 fuse for an open.
Was a problem found?–Go to Step 7Go to Step 8
7Inspect the EF1,F2 fuse for short. Replace the fuse
if necessary.
Is the replacement complete?–System OK–
81. Turn the ignition ON.
2. Measure the voltage of EF1, F2.
Is the voltage within the values shown?9–16vGo to Step 10Go to Step 9
9Repair the fuse voltage supply lines for open.
Is the action completed?–System OK–
101. Turn the ignition LOCK.
2. Disconnect the TCM wiring connector.
3. Measure the resistance between EF1 fuse and
terminal A24 of the TCM wiring connector.
Is the resistance within the values shown?0ΩGo to Step 12Go to Step 11
11Repair the circuit (between EF1 and terminal A24)
for short to ground and open.
Is the repair completed?–System OK–
121. Disconnect the C105 connector and TCM con-
nector.
2. Turn the ignition ON.
3. Measure the voltage of the terminal A24.
Is the voltage within the values shown?9–16vGo to Step 13Go to Step 14
13Repair the circuit from EF1 to terminal A24 of the
TCM for short to battery.
Is the repair completed?–System OK–

Page 1629 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 39
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
141. Turn the ignition LOCK.
2. Disconnect the C201 connector.
3. Measure the resistance between F2 fuse and
term

Page 1630 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 40IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0563
SYSTEM VOLTAGE HIGH
Conditions for Setting the DTC
S System voltage is too high.
S TCM detects that volta

Page 1631 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 41
DAEWOO V–121 BL4
DTC P0563 System Voltage High
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. Turn the ignition ON, with th

AISIN AUTOMATIC TRANSAXLE 5A2 – 41
DAEWOO V–121 BL4
DTC P0563 System Voltage High
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. Turn the ignition ON, with the engine OFF.
4. Run the engine to 600 rpm or greater.
5. Record then clear DTC(s).
6. Select system voltage on the scan tool.
7. Drive the vehicle and observe the scan tool for
either of the flowing conditions:
Is the voltage within the values shown?9–16vGo to Step 4Go to Step 2
21. Disconnect the battery cable.
2. Measure the battery voltage.
Is the voltage within the values shown?9–16vGo to Step 4Go to Step 3
31. Replace the battery.
Is the replacement completed?–System OK–
41. Turn the headlamp ON.
2. Turn the air conditioner ON.
3. Run the engine to 600 rpm or greater.
4. Observe the scan tool for system voltage.
Is the voltage within the values shown?9–16vGo to Step 6Go to Step 5
51. Turn the ignition LOCK.
2. Repair the alternator circuit if necessary.
Is the action completed?–System OK–
6Inspect the EF1,F2 fuse for an open.
Was a problem found?–Go to Step 7Go to Step 8
7Inspect the EF1,F2 fuse for short. Replace the fuse
if necessary.
Is the replacement complete?–System OK–
81. Turn the ignition ON.
2. Measure the voltage of EF1,F2.
Is the voltage within the values shown?9–16vGo to Step 10Go to Step 9
9Repair the fuse voltage supply lines for open.
Is the action completed?–System OK–
101. Turn the ignition LOCK.
2. Disconnect the TCM wiring connector.
3. Measure the resistance between EF1 fuse and
terminal A24 of the TCM wiring connector.
Is the resistance within the values shown?0ΩGo to Step 12Go to Step 11
11Repair the circuit (between EF1 and terminal A24)
for short to ground and open.
Is the repair completed?–System OK–
121. Disconnect the C105 connector and TCM con-
nector.
2. Turn the ignition ON.
3. Measure the voltage of the terminal A24.
Is the voltage within the values shown?9–16vGo to Step 13Go to Step 14
13Repair the circuit from EF1 to terminal A24 of the
TCM for short to battery.
Is the repair completed?–System OK–

Page 1632 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 42IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
141. Turn the ignition LOCK.
2. Disconnect the C201 connector.
3. Measure the resistance between F2 fuse and
termi
