Page 1681 of 2643

AISIN AUTOMATIC TRANSAXLE 5A2 – 91
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P1791
THROTTLE POSITION SIGNAL ERROR
Conditions for Setting the DTC
S TCM detects that malfunction of throttle position
signal for 2 seconds continuously.
S No DTC U2105
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects a failure on the first ignition
cycle.
S TCM judges the throttle opening is 0% for shift
point control.
S TCM judges the throttle opening is 100% for line
pressure control.
S No lock–up
S No 4th gear
S No self–learning controlS No timing solenoid control for N–D
Conditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
Cause of Failure
S Wiring harness or connector between ECM and
TCM
S ECM
S TCM
Page 1682 of 2643

5A2 – 92IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC 1791 Throttle Position Signal Error
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With the engine OFF, turn the ignition switch to
the ON position.
4. Select Store Freeze Frame/Failure Records
from the Diagnostic Trouble Codes Information
menu.
5. Store Freeze Frame/Failure Records.
6. Select Clear DTC Information from the Diag-
nostic Trouble Codes Information menu.
7. Clear DTC Information.
8. Perform one vehicle drive cycle.
Is the Malfunction Indicator Lamp (MIL) ON?–Go to Step 2Repair the tem-
porary connec-
tion failure of
connector.
21. Select Request DTC by Status from the Diag-
nostic Trouble Codes Information menu.
2. Request DTC by Status.
Is DTC P1791 displayed?–Go to Step 3Repair the tem-
porary connec-
tion failure of
connector.
31. Turn the ignition OFF.
2. Disconnect the TCM wiring connector and
ECM wiring connector.
3. Measure the resistance between terminal A17
of the TCM wiring connector and terminal 88 of
the ECM wiring connector.
4. Measure the resistance between terminal A7 of
the TCM wiring connector and terminal 57 of
the ECM wiring connector.
Is the resistance within the values shown?0 WGo to Step 5Go to Step 4
4Repair the malfunctioning terminals as necessary.
Is the action complete?–System OK–
51. Turn the ignition ON.
2. Measure the voltage of terminal A17.
3. Measure the voltage of terminal A7.
Is the voltage within the values shown?11–14 vGo to Step 6Go to Step 7
6Repair the malfunctioning terminals as necessary.
Is the action complete?–System OK–
71. Replace the TCM.
2. Turn the ignition OFF.
3. Turn the ignition ON.
4. Check if P1791 DTC is set.
Is the DTC set?–Go to Step 8Go to Step 9
8Replace the ECM.
Is the action complete?–Go to Step 9–
91. After the repair, use a scan tool ”clear info”
function and road test the vehicle.
2. Review the ”DTC info”.
Has the last test failed or is the current DTC dis-
played?–Begin diagno-
sis againRepair verified
exit DTC chart
Page 1683 of 2643
AISIN AUTOMATIC TRANSAXLE 5A2 – 93
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P1792
ENGINE COOLANT TEMPERATURE (ECT) SIGNAL
ERROR
Conditions for Setting the DTC
S TCM detects malfunction of Engine Coolant Tem-
perature (ECT) signal for 2 seconds continuously.
S No DTC U2105
Action Taken When the DTC Sets
S TCM will not request the illumination of MIL, but will
store DTC when TCM detects a failure on the first
ignition cycle.
S TCM judges the engine coolant temperature 90 de-
grees when lapse 15 minutes from ignition ON.Conditions for Clearing the DTC
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
Cause of Failure
S Wiring harness or connector between ECM and
TCM
S ECM
S TCM
Page 1684 of 2643

5A2 – 94IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P1792 Engine Coolant Temperature (ECT) Signal Error
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With the engine OFF, turn the ignition switch to
the ON position.
4. Select Clear DTC Information from the Diag-
nostic Trouble Codes Information menu.
5. Clear DTC Information.
6. Perform one vehicle drive cycle.
7. Select Request DTC by Status from the Diag-
nostic Trouble Codes Information menu.
8. Request DTC by Status.
Is DTC P1792 displayed?–Go to Step 2Repair the tem-
porary connec-
tion failure of
connector.
21. Turn the ignition OFF.
2. Disconnect the TCM wiring connector and
ECM wiring connector.
3. Measure the resistance between terminal A17
of the TCM wiring connector and terminal 88 of
the ECM wiring connector.
4. Measure the resistance between terminal A7 of
the TCM wiring connector and terminal 57 of
the ECM wiring connector.
Is the resistance within the values shown?0 WGo to Step 4Go to Step 3
3Repair the malfunctioning terminals as necessary.
Is the action complete?–System OK–
41. Turn the ignition ON.
2. Measure the voltage of terminal A17.
3. Measure the voltage of terminal A7.
Is the voltage within the values shown?11–14 vGo to Step 5Go to Step 6
5Repair the malfunctioning terminals as necessary.
Is the action complete?–System OK–
61. Replace the TCM.
2. Turn the ignition OFF.
3. Turn the ignition ON.
4. Check if P1792 DTC is set.
Is the DTC set?–Go to Step 7Go to Step 8
7Replace the ECM.
Is the action complete?–Go to Step 8–
81. After the repair, use a scan tool ”clear info”
function and road test the vehicle.
2. Review the ”DTC info”.
Has the last test failed or is the current DTC dis-
played?–Begin diagno-
sis againRepair verified
exit DTC chart
Page 1685 of 2643

AISIN AUTOMATIC TRANSAXLE 5A2 – 95
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) U2105
CAN ERROR
Conditions for Setting the DTC
S TCM detects that the BUS OFF signal. This detec-
tion is continued for 0.2 seconds.
S TCM detects that nothing of ECM signal on CAN
BUS for 0.2 seconds. This detection is continued
for 2.0 seconds.
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects a failure on the first ignition
cycle.
S TCM judges the throttle opening is 0% for shift
point and lock–up point control.
S TCM judges the throttle opening is 100% for line
pressure control.
S No lock–upS No self–learning control
S No 4th gear
S TCM judges the engine revolution is 0 rpm.
Conditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S TCM detects the BUS normal signal for 2 seconds
continuously.
Cause of Failure
S Wiring harness or connector between ECM and
TCM
S ECM
S TCM
Page 1686 of 2643

5A2 – 96IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC U2105 CAN Error
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With the engine OFF, turn the ignition switch to
the ON position.
4. Select Store Freeze Frame/Failure Records
from the Diagnostic Trouble Codes Information
menu.
5. Store Freeze Frame/Failure Records.
6. Select Clear DTC Information from the Diag-
nostic Trouble Codes Information menu.
7. Clear DTC Information.
8. Perform one vehicle drive cycle.
Is the Malfunction Indicator Lamp (MIL) ON?–Go to Step 2Repair the tem-
porary connec-
tion failure of
connector.
21. Select Request DTC by Status from the Diag-
nostic Trouble Codes Information menu.
2. Request DTC by Status.
Is DTC U2105 displayed?–Go to Step 3Repair the tem-
porary connec-
tion failure of
connector.
31. Turn the ignition OFF.
2. Disconnect the TCM wiring connector and
ECM wiring connector.
3. Measure the resistance between terminal A17
of the TCM wiring connector and terminal 88 of
the ECM wiring connector.
4. Measure the resistance between terminal A7 of
the TCM wiring connector and terminal 57 of
the ECM wiring connector.
Is the resistance within the values shown?0 WGo to Step 5Go to Step 4
4Repair the malfunctioning terminals as necessary.
Is the action complete?–System OK–
51. Turn the ignition ON.
2. Measure the voltage of terminal A17.
3. Measure the voltage of terminal A7.
Is the voltage within the values shown?11–14 vGo to Step 6Go to Step 7
6Repair the malfunctioning terminals as necessary.
Is the action complete?–System OK–
71. Replace the TCM.
2. Turn the ignition OFF.
3. Turn the ignition ON.
4. Check if U2105 DTC is set.
Is the DTC set?–Go to Step 8Go to Step 9
8Replace the ECM.
Is the action complete?–Go to Step 9–
91. After the repair, use a scan tool ”clear info”
function and road test the vehicle.
2. Review the ”DTC info”.
Has the last test failed or is the current DTC dis-
played?–Begin diagno-
sis againRepair verified
exit DTC chart
Page 1687 of 2643

AISIN AUTOMATIC TRANSAXLE 5A2 – 97
DAEWOO V–121 BL4
MAINTENANCE AND REPAIR
ON–VEHICLE SERVICE
TRANSAXLE FLUID LEVEL
CHECKING PROCEDURE
Notice : Check the fluid level when the transaxle tempera-
ture is 70°C~80°C (158°F~176°F).
Notice : During the fluid level check, the selector lever
must be in position P.
Notice : When adding fluid or making a complete fluid
change, always use ISU DEXRON III. Failure to use the
proper fluid will cause hose and seal damage and fluid
leaks.
1. Make sure the vehicle is level.
2. Shift into all range from ”P” to ”1” and return to ”P”
with engine idling.
3. Remove the transaxle fluid dipstick and check the
transaxle fluid level.
4. The correct fluid level must be between the HOT
MIN and the HOT MAX notches on the dipstick.
5. If the fluid level is below the MIN notch, add trans-
axle fluid through the fluid filler tube and check for
leaks in the transaxle.
6. If the fluid above the MAX notch, the transaxle is
overfilled. Drain some of the fluid through the fluid
pan drain plug. Check the transaxle fluid level.
FLUID DRAIN PROCEDURE
Draining Procedure
1. Raise and support the vehicle. Refer to ”Vehicle
Lifting Procedures,” Section 0B, General Informa-
tion.
2. Place a suitable fluid drainage container under the
transaxle.
3. Remove the fluid drain plug. allow the fluid to drain
completely.
4. Clean the drain plug threads.
5. Install the fluid drain plug.
Tighten
Torque the fluid drain plug to 17 NSm (13 Ib–ft).
Page 1688 of 2643

5A2 – 98IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
Filling Procedure
1. Remove the drainage container and lower the ve-
hicle.
2. Add three–fourths of the recommended amount of
ISU DEXRON III.
3. Start the engine and allow it to reach normal oper-
ating temperature.
4. Shift the gear selector through all positions.
5. Check the fluid level and add fluid until the dipstick
indicates a safe level.
LOCATING FLUID LEAKS
General Method
1. Verify that the material leaking is transaxle fluid.
2. Thoroughly clean the suspected leak area.
3. Allow the transaxle to reach the normal operating
temperature of 176–194°F (80–90°C).
4. Park the vehicle over a clean paper or a clean card-
board.
5. Turn the engine OFF and look for fluid spots on the
paper.
6. Make the necessary repairs to correct that leak.
Powder Method
1. Thoroughly clean the suspected leak area.
2. Apply an aerosol type powder, such as foot powder,
to the suspected leak area.
3. Allow the transaxle to reach the normal operating
temperature of 176–194°F (80–90°C).
4. Turn the engine OFF.
5. Inspect the suspected leak area and trace the leak
path through the powder to find the source of the
leak.
6. Make the necessary repairs to correct the leak.
Once the leak point is found, the source of the leak must
be determined and repaired.
CASE PORSITY REPAIR
1. Determine the leak area. Refer to ”Locating Fluid
Leaks” in this section.
2. Clean the leak area with the solvent. Air dry.
CAUTION : Epoxy cement may cause skin irritations
and eye damage. Read and follow all information on
the container label as provided by the manufacturer.
3. Mix a sufficient amount of epoxy cement following
the manufacturer’s recommendations.
4. While the transaxle case is hot, apply epoxy ce-
ment with a clean, dry soldering acid brush.
5. Allow the epoxy cement to dry for 3 hours before
starting the engine.
