DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 43
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0601
INTERNAL CONTROL MODULE MEMORY CHECKSUM
ERROR
Conditions for Setting the DTC
S The Transmission Control M

Page 1634 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 44IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P0601 Internal Control Module Memory Checksum Error
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With

Page 1635 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 45
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0604
INTERNAL TRANSMISSION CONTROL MODULE (TCM)
RANDOM ACCESS MEMORY (RAM) ERROR
Conditions for Setting the DTC

Page 1636 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 46IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P0604 Internal Transmission Control Module (TCM) Random
Access Memory (RAM) Error
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. In

Page 1637 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 47
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0705
TRANSMISSION RANGE (TR) SWITCH CIRCUIT
MALFUNCTION
Conditions for Setting the DTC
S TCM detects more than

Page 1638 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 48IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P0705 Transmission Range (TR) Switch Circuit Malfunction
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3.

5A2 – 48IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P0705 Transmission Range (TR) Switch Circuit Malfunction
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With the engine OFF, turn the ignition switch to
the ON position.
4. Select Store Freeze Frame/Failure Records
from the Diagnostic Trouble Codes Information
menu.
5. Store Freeze Frame/Failure Records.
6. Select Clear DTC Information from the Diag-
nostic Trouble Codes Information menu.
7. Clear DTC Information.
8. Perform two vehicle drive cycles.
Is the Malfunction Indicator Lamp (MIL) ON?–Go to Step 2Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section.)
21. Select Request DTC by Status from the Diag-
nostic Trouble Codes Information menu.
2. Request DTC by Status.
Is DTC P0705 displayed?–Go to Step 3Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section.)
31. Turn the ignition OFF.
2. Inspect the continuity between the vehicle har-
ness and the Transmission Range (TR) Switch.
3. Disconnect the TCM connector (X–1) of the
vehicle harness and inspect the continuity for
the each terminal according to the position of
the select lever.
P : B20
R : B1
N : B8
D : B7
2 : B19
1 : B18
Does the inspection OK?–Go to Step 4Go to Step 5
41. Estimate the failure of between the vehicle wir-
ing harness connector and TCM.
2. Inspect the connector. Refer to ”Wiring Har-
ness and Connector Inspection” in this section.
3. Inspect the connection condition between the
TCM connectors (C–1).
Is the connection condition OK?–Go to Step 6Repair the wir-
ing harness
connectors.
51. Estimate the failure of between the vehicle har-
ness and TR switch.
2. Disconnect the connector (X–2) of the vehicle
harness and inspect the continuity between the
terminals. Refer to ”Wiring Harness and Con-
nector Inspection” in this section.
Is the condition of TR switch OK?–Go to Step 7Replace the TR
switch.

Page 1639 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual AISIN AUTOMATIC TRANSAXLE 5A2 – 49
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
61. Replace the master TCM.
2. Perform the reproducing test under user condi-
tion after confirming no DTC.
Is DTC

Page 1640 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 5A2 – 50IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0712
TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR
CIRCUIT LOW INPUT
Conditions for Setting the DTC
S TCM detects
