DAEWOO NUBIRA 2004 Service Repair Manual 9E – 14IINSTRUMENTATION/DRIVER INFORMATION
DAEWOO V–121 BL4
CHIME MODULE
Seat Belt Warning Chime Inoperative
StepActionValue(s)YesNo
1Check the chime module connector to make sure it
is connected

Page 2314 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual INSTRUMENTATION/DRIVER INFORMATION 9E – 15
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
131. Disconnect the seat belt switch.
2. Make sure the driver’s side seat belt is unfas-
tened.
3. Use

Page 2315 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 9E – 16IINSTRUMENTATION/DRIVER INFORMATION
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
9With the chime module disconnected, use an ohm-
meter to check the continuity between terminal 5 of
the chim

9E – 16IINSTRUMENTATION/DRIVER INFORMATION
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
9With the chime module disconnected, use an ohm-
meter to check the continuity between terminal 5 of
the chime module connector and ground.
Does the ohmmeter indicate the specified value? 0 WGo to Step 11Go to Step 10
10Repair the open circuit between terminal 5 of the
chime module connector and ground.
Is the repair complete?–System OK–
111. Disconnect the chime module connector.
2. Make sure the driver’s side door is open.
3. Use an ohmmeter to check the continuity be-
tween terminal 4 of the chime module and
ground.
Does the ohmmeter indicate the specified value? 0 WGo to Step 12Go to Step 13
12Replace the chime module.
Is the repair complete?–System OK–
131. Disconnect the front door contact switch.
2. Use an ohmmeter to check the continuity be-
tween the door contact switch and terminal 4 of
the chime module.
Does the ohmmeter indicate the specified value? 0 WGo to Step 15Go to Step 14
14Repair the open circuit between the door contact
switch and terminal 4 of the chime module.–System OK–
15Replace the door contact switch.
Is the repair complete?–System OK–
Key Reminder Chime Inoperative
StepActionValue(s)YesNo
1Check the chime module connector to make sure it
is connected properly.
Is the connector disconnected or partially discon-
nected?–Go to Step 2Go to Step 3
2Connect the electrical connector for the chime mod-
ule.
Is the repair complete?–System OK–
3Check fuse Ef19.
Is fuse Ef19 blown?–Go to Step 4Go to Step 5
41. Check for a short circuit and repair it, if neces-
sary.
2. Replace the fuse.
Is the repair complete?–System OK–
51. Turn the ignition ON.
2. Check the voltage at fuse Ef19.
Is the specified voltage available at fuse Ef19?11–14 vGo to Step 7Go to Step 6
6Repair the power supply circuit for fuse Ef19.
Is the repair complete?–System OK–
71. Disconnect the chime module.
2. Check the voltage at terminal 2 of the chime
module connector.
Does the voltage equal the specified value?11–14 vGo to Step 13Go to Step 8

Page 2316 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual INSTRUMENTATION/DRIVER INFORMATION 9E – 17
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
81. Disconnect the key reminder switch.
2. Use an ohmmeter to check the continuity be-
tween the key remin

Page 2317 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 9E – 18IINSTRUMENTATION/DRIVER INFORMATION
DAEWOO V–121 BL4
MAINTENANCE AND REPAIR
ON–VEHICLE SERVICE
CENTER MODLING
Removal Procedure
1. Disconnect the mode control cable from the mode
door.
2

Page 2318 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual INSTRUMENTATION/DRIVER INFORMATION 9E – 19
DAEWOO V–121 BL4
Installation Procedure
1. Connect the electrical connectors.
2. Install the instrument cluster trim panel with the
screws.
GARNISH M

Page 2319 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 9E – 20IINSTRUMENTATION/DRIVER INFORMATION
DAEWOO V–121 BL4
Installation Procedure
1. Install the ashtray housing with screws.
2. Install the instrument panel center molding.
CIGAR LIGHTER
Remo

Page 2320 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual INSTRUMENTATION/DRIVER INFORMATION 9E – 21
DAEWOO V–121 BL4
Installation Procedure
1. Install the glove box with the screws.
NOTCHBACK DEPOSIT BOX
Removal Procedure
1. Remove the glove box.
2.
