DAEWOO NUBIRA 2004 Service Repair Manual 2C – 12IFRONT SUSPENSION DAEWOO V–121 BL4 Notice : Do not over extend the axle joints. When either end of the shaft is disconnected, overextension of the joint can result in separation of internal

Page 930 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual FRONT SUSPENSION 2C – 13 DAEWOO V–121 BL4 7. Connect the outer tie rod to the knuckle assembly. Refer to Section 6C, Power Steering Gear. 8. Install the brake caliper onto the rotor. Refer to S

Page 931 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 2C – 14IFRONT SUSPENSION DAEWOO V–121 BL4 6. Remove the wheel bearing with the support bridge J–37105–B–1, the bearing adapter J–37105–B–2, the hex nut 500–20, and the forcing screw

Page 932 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual FRONT SUSPENSION 2C – 15 DAEWOO V–121 BL4 5. Disconnect the ball joint from the knuckle assembly using the ball joint remover KM–507–B. 6. Remove the control arm–to–crossmember bolts. 7

Page 933 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 2C – 16IFRONT SUSPENSION DAEWOO V–121 BL4 5. Install the control arm–to–crossmember bolts. Tighten S Tighten the front control arm–to–crossmember bolt to 125 NSm (92 lb–ft). S Tighten

Page 934 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual FRONT SUSPENSION 2C – 17 DAEWOO V–121 BL4 7. Disconnect the steering knuckle by removing the steering knuckle–to–strut assembly nuts and the bolts. 8. Remove the strut assembly. Installatio

Page 935 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 2C – 18IFRONT SUSPENSION DAEWOO V–121 BL4 3. Connect the stabilizer shaft link to the strut assem- bly by attaching the stabilizer link–to–strut assem- bly nut. Tighten Tighten the stabilizer

Page 936 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual FRONT SUSPENSION 2C – 19 DAEWOO V–121 BL4 10. Remove the rear crossmember–to–body bolts. CAUTION : Two technicians must hold the front crossmember assembly and suitably support the as- sembl
