Page 705 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual ENGINE CONTROLS 1F – 459
DAEWOO V–121 BL4
Test Description
Number(s) below refer to the step number(s) on the Diag-
nostic Table.
1. The On–Board Diagnostic (EOBD) System Check
prompts the tech

ENGINE CONTROLS 1F – 459
DAEWOO V–121 BL4
Test Description
Number(s) below refer to the step number(s) on the Diag-
nostic Table.
1. The On–Board Diagnostic (EOBD) System Check
prompts the technician to complete some basic
checks and store the freeze frame and failure re-
cords data on the scan tool if applicable. This
creates an electronic copy of the data taken when
the malfunction occurred. The information is then
stored on the scan tool for later reference.
2. This step determines if DTC P0341 is the result of
a hard failure or an intermittent condition.
3. The counter should stop incrementing with the sen-sor electrical connector disconnected and set a
DTC P0342 with the sensor disconnected. If it still
increments the ECM is malfunctioning.
4. By moving the CMP sensor electrical connector, the
connections at the sensor are checked. Make sure
the electrical connector remains securely fastened.
5. A poor connection in any of the circuits at the CMP
will cause the CMP Resync Counter to increment.
Anytime a poor connection is present, the CMP
Reference Activity counter will stop incrementing
and the CMP Resync Counter will increment.
8. The replacement ECM must be reprogrammed.
Refer to the latest Techline procedure for ECM re-
programming.
DTC P0341 – Camshaft Position Sensor Rationality
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Was the check performed?–Go to Step 2Go to
”On–Board
Diagnostic Sys-
tem Check”
21. Turn the ignition OFF.
2. Install a scan tool to the Data Link Connector
(DLC).
3. Start the engine and operate the vehicle within
the Freeze Frame Conditions and Conditions
for Setting the DTC as noted.
Is Diagnostic Trouble Code (DTC) P0341 set?–Go to Step 3Go to
”Diagnostic
Aids”
31. Turn the ignition OFF.
2. Disconnect the Camshaft Position (CMP) sen-
sor connector.
3. Turn the ignition ON.
4. Using a voltmeter, check the voltage between
the CMP sensor harness connector (Engine
Control Module [ECM] side) terminal 3 and
ground.
Does the voltage near the specified value?5 VGo to Step 4Go to Step 5
4Using a voltmeter, check the voltage between the
CMP sensor wiring harness connector terminal 1
and ground.
Is the voltage over the specified value?10 voltsGo to Step 6Go to Step 10
5With a test light connected to ground, probe the
CMP harness connector terminal 3.
Does the test light illuminate?–Go to Step 8Go to Step 9
6With a test light connected to B+, probe the CMP
sensor harness connector terminal 2.
Does the test light illuminate?–Go to Step 7Go to Step 11
7Check for poor connections at the CMP sensor elec-
trical connectors and repair as needed.
Is the repair complete?–Go to Step 15Go to Step 13

Page 706 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 1F – 460IENGINE CONTROLS
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
81. Turn the ignition OFF.
2. Disconnect the ECM connector.
3. Repair the short to voltage on the CMP signal
circuit.
Is the

Page 707 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual ENGINE CONTROLS 1F – 461
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0342
CAMSHAFT POSITION SENSOR NO SIGNAL
System Description
The Camshaft Position (CMP) Sensor is used to correlate
cranksh

Page 708 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 1F – 462IENGINE CONTROLS
DAEWOO V–121 BL4
1. The On–Board Diagnostic (EOBD) System Check
prompts the technician to complete some basic
checks and to store the freeze frame and failure
records da

1F – 462IENGINE CONTROLS
DAEWOO V–121 BL4
1. The On–Board Diagnostic (EOBD) System Check
prompts the technician to complete some basic
checks and to store the freeze frame and failure
records data on the scan tool if applicable. This
creates an electronic copy of the data taken when
the malfunction occurred. The information is then
stored on the scan tool for later reference.
2. This step determines if DTC P0342 is the result ofa hard failure or an intermittent condition.
4. Determines if voltage is available to the CMP.
7. This step checks for a voltage supplied by the ECM
to the CMP.
12. The replacement ECM must be reprogrammed.
Refer to the latest Techline procedure for ECM re-
programming.
DTC P0342 – Camshaft Position Sensor No Signal
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Was the check performed?–Go to Step 2Go to
”On–Board
Diagnostic Sys-
tem Check”
21. Turn the ignition OFF.
2. Install a scan tool to the Data Link Connector
(DLC).
3. Idle the engine.
Is the Camshaft Position (CMP) Active Count incre-
menting?–Go to Step 3Go to Step 4
31. Turn the ignition ON.
2. Review the Freeze Frame data and note the
parameters.
3. Start the engine and operate the vehicle within
the Freeze Frame Conditions and Conditions
for Setting the DTC as noted.
Is the CMP Active Counter incrementing?–Go to Step 13Go to Step 4
41. Turn the ignition OFF.
2. Disconnect the CMP sensor connector.
3. Turn the ignition ON.
4. With a test light connected to ground, probe
the CMP sensor harness connector, terminal 1.
Does the test light illuminate?–Go to Step 5Go to Step 6
5With a test light connected to B+, probe the CMP
sensor harness connector, terminal 2.
Does the test light illuminate?–Go to Step 7Go to Step 8
6Check for a poor connection or open in the CMP sen-
sor B+ feed circuit and repair as necessary.
Is the repair complete?–Go to Step 13Go to
”Diagnostic
Aids”
7Using a Digital Voltmeter (DVM), check the voltage
between the CMP sensor harness connector, termi-
nal 3 and ground.
Does the DVM display near the specified values?5 VGo to Step 11Go to Step 9
8Check for a poor connection or open in the CMP sen-
sor ground circuit and repair as necessary.
Is the repair complete?–Go to Step 13–
91. Turn the ignition OFF.
2. Disconnect the engine Control Module (ECM)
connector.
3. Check for the CMP signal circuit for an open or
short to round or short to B+, and repair as
needed.
Is the repair complete?–Go to Step 13Go to Step 10

Page 709 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual ENGINE CONTROLS 1F – 463
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
10Check the CMP signal circuit for an open or short to
ground and repair as needed.
Is the repair complete?–Go to Step 13Go

Page 710 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 1F – 464IENGINE CONTROLS
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0351
IGNITION CONTROL CIRCUIT A FAULT (CYLINDER 1 & 4)
Circuit Description
The Engine Control Module (ECM) provides a groun

Page 711 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual ENGINE CONTROLS 1F – 465
DAEWOO V–121 BL4
S Damaged harness – Inspect the wiring harness for
damage. If the harness appears to be OK, discon-
nect the ECM, turn the ignition on, and observe a

ENGINE CONTROLS 1F – 465
DAEWOO V–121 BL4
S Damaged harness – Inspect the wiring harness for
damage. If the harness appears to be OK, discon-
nect the ECM, turn the ignition on, and observe a
voltmeter connected to the 58X reference circuit at
the ECM harness connector while moving connec-
tors and wiring harnesses related to the ECM. A
change in voltage will indicate the location of thefault.
Reviewing the Failure Records vehicle mileage since the
diagnostic test last failed may help determine how often
the condition that caused the DTC to be set occurs. This
may assist in diagnosing the condition.
DTC P0351 – Ignition Control Circuit A Fault (Cylinder 1 and 4)
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Was the check performed?–Go to Step 2Go to
”On–Board
Diagnostic Sys-
tem Check”
2Check for a faulty connection or damaged terminal
C at the Electronic Ignition (EI) system ignition coil
and repair as needed.
Is the repair complete?–Go to Step 8Go to Step 3
3Check for a faulty connection or damaged terminal
M51/M35 at the Engine Control Module (ECM) and
repair as needed.
Is the repair complete?–Go to Step 8Go to Step 4
41. Ignition OFF.
2. Disconnect the ECM connector.
3. Check the ignition control circuit for a short to
ground and repair as needed.
Is the repair complete?–Go to Step 8Go to Step 5
5Check the ignition control circuit for a short to voltage
and repair as necessary.
Is the repair complete?–Go to Step 8Go to Step 6
6Check an open ignition control circuit and repair as
needed.
Is the repair complete?–Go to Step 8Go to Step 7
71. Turn the ignition OFF.
2. Replace the ECM.
Is the repair complete?–Go to Step 8–
81. Using the scan tool, clear the Diagnostic
Trouble Codes (DTCs).
2. Start the engine and idle at normal operating
temperature.
3. Operate the vehicle within the conditions for
setting this DTC as supported in the text.
Does the scan tool indicate that this diagnostic ran
and passed?–Go to Step 9Go to Step 2
9Check if any additional DTCs are set.
Are any DTCs displayed that have not been diag-
nosed?–Go to applica-
ble DTC tableSystem OK

Page 712 of 2643

DAEWOO NUBIRA 2004 Service Repair Manual 1F – 466IENGINE CONTROLS
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0352
IGNITION CONTROL CIRCUIT B FAULT (CYLINDER 2 & 3)
Circuit Description
The Engine Control Module (ECM) provides a groun
