2004 DAEWOO NUBIRA Service Repair Manual

Page 2345 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual INTERIOR TRIM  9G – 5
DAEWOO V–121 BL4
Installation  Procedure
1.  Install the A–pillar trim panel.
UPPER B–PILLAR TRIM PANEL
Removal Procedure
1.  Remove the lower B–pillar trim panel. Refe

Page 2346 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 9G – 6IINTERIOR TRIM
DAEWOO V–121 BL4
Installation  Procedure
1.  Install the lower B–pillar trim panel.
2.  Install the front rocker trim panel and the rear rock-
er trim panel to their origina

Page 2347 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual INTERIOR TRIM  9G – 7
DAEWOO V–121 BL4
Installation  Procedure
1.  Install the rear deck lid sill plate cover with the plas-
tic retaining clips.
2.  Install the child seat anchorage. Refer to Sec

Page 2348 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 9G – 8IINTERIOR TRIM
DAEWOO V–121 BL4
Installation  Procedure
1.  Install the rear rocker trim panel.
2.  Install the rear seat cushion to its original position.
FRONT WHEELHOUSE TRIM
Removal Proc

Page 2349 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual INTERIOR TRIM  9G – 9
DAEWOO V–121 BL4
Installation  Procedure
1.  Install the rear wheelhouse trim with the screws.
2.  Install the seat belt bolt.
3.  Install the rear seat. Refer to Section 9H,

Page 2350 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 9G – 10IINTERIOR TRIM
DAEWOO V–121 BL4
4.  Install the screws to the rear portion of the floor
console.
5.  Connect the negative battery cable.
6.  Install the glove box, instrument panel lower co

Page 2351 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual INTERIOR TRIM  9G – 11
DAEWOO V–121 BL4
3.  Install the floor console. Refer to ”Floor Console”  in
this section.
4.  Install the left and the right kick panels. Refer to
”Kick Panel”  in

Page 2352 of 2643

DAEWOO NUBIRA 2004  Service Repair Manual 9G – 12IINTERIOR TRIM
DAEWOO V–121 BL4
LUGGAGE COMPARTMENT
WHEELHOUSE TRIM PANEL
Tools Required
KM–475–B Trim Remover
Removal Procedure
1.  Remove the luggage compartment rear panel cov-
er. R
