NUBIRA/LACETTIGENERAL INFORMATION 1–5
9. TECHNICAL ILLUSTRATION
Fig. 4
Page 2514 of 2643
1–6 GENERAL INFORMATIONNUBIRA/LACETTI
NOTCHBACK
Fig. 5
Page 2515 of 2643
NUBIRA/LACETTIGENERAL INFORMATION 1–7
HATCHBACK
Fig. 6
Page 2516 of 2643
1–8 GENERAL INFORMATIONNUBIRA/LACETTI
NOTCHBACK
Fig. 7
Page 2517 of 2643
NUBIRA/LACETTIGENERAL INFORMATION 1–9
HATCHBACK
Fig. 8
Page 2518 of 2643
1–10 GENERAL INFORMATIONNUBIRA/LACETTI
NOTCHBACK
Fig. 9
Page 2519 of 2643
NUBIRA/LACETTIGENERAL INFORMATION 1–11
HATCHBACK
Fig. 10
Page 2520 of 2643

1–12 GENERAL INFORMATIONNUBIRA/LACETTI
10. BODY REPAIR PROCEDURES
No.OperationProcedureRemarks
1InspectionInspect the damaged parts and the extent of damage and make
plans for the repair..
2PreparationPrepare the new parts, special repair tools and others..
3RemovalRemove the related parts for repair..
4Pull outRoughly pull out and straighten the damaged areas..
5Cut and pry offCut off the damaged areas and drills on the spot weld nuggets
and pry off the remaining spot weld flanges..
6Peel offPeel off the undercoat and sealer..
7MoldingMold damaged areas and even out the welding flanges and fill
any holes..
8Set the new partsGrind both sides of the welding section and set the new parts
and tack welds for temporary installation..
9InspectionInspect the dimensions for correct position and preinstall the ex-
terior parts and check the clearances and level differences..
10WeldingPerform a trial welding and the main welding..
11FinishFinish the welding areas and even out the flanges for a close fit..
12SealingApply the sealer to the matching and over lapped surface..
13UndercoatingApply the undercoat to the required areas..
14PaintingApply the paint..
15DeadnerApply the deadner to the designated areas..
16Anti–rust agentsCoating the anti–rust agents to the designated areas..
17InstallationInstall the related parts and rub in grease to the moving parts and
replenish the cooling liquid, oil, aircon gas and others..
18Check and adjustCheck all operations, wheel alignments, leaks, head lamp aim
and others with the specified check sheet..
