Check body ground circuit for auto amp. with ignition switch OFF.
Check for continuity between terminal Nos. 32, 14 and body
ground.
Ohmmeter terminal
Continuity
(+) (þ)
32
Body ground Yes
14 (Canada only)
If OK, check auto amp. ground circuit, see below.
IIf NG, check 7.5A fuses (Nos. 11 and 24, located in the fuse
block) and 15A fuses (Nos. 1 and 2, located in the fuse block).
IIf fuses are OK, check for open circuit in wiring harness.
Repair or replace as necessary.
IIf fuses are NG, replace fuse and check wiring harness for
short circuit. Repair or replace as necessary.
NOTE:
If OK, replace auto amp.
If NG, repair or replace harness.
TROUBLE DIAGNOSES
A/C System (Cont'd)
HA-74
Page 1874 of 2395
Mode Door Motor
TROUBLE DIAGNOSIS PROCEDURE FOR MODE DOOR MOTOR (LAN)=NBHA0090SYMPTOM:
IAir outlet does not change.
IMode door motor does not operate normally.
Inspection FlowNBHA0090S01Without Navigation SystemNBHA0090S0101
SHA245F
*1: HA-25
*2: HA-66
*3: HA-44
*4: HA-45
*5: HA-129*6: HA-132
*7: HA-135
*8: HA-141
*9: STEP-BY-STEP PROCEDURE
(HA-45), see No. 13.*10: HA-78
*11: HA-81
*12: HA-66
*13: HA-65
*14: HA-139
GI
MA
EM
LC
EC
FE
AT
TF
PD
AX
SU
BR
ST
RS
BT
SC
EL
IDX
TROUBLE DIAGNOSES
Mode Door Motor
HA-75
Page 1875 of 2395
With Navigation SystemNBHA0090S0102
RHA869H
*1: HA-25
*2: HA-66
*3: HA-44
*4: HA-45
*5: HA-129*6: HA-132
*7: HA-135
*8: HA-141
*9: STEP-BY-STEP PROCEDURE
(HA-45), see No. 13.*10: HA-78
*11: HA-81
*12: HA-66
*13: HA-65
*14: HA-139
TROUBLE DIAGNOSES
Mode Door Motor (Cont'd)
HA-76
Page 1876 of 2395
SYSTEM DESCRIPTION=NBHA0052Component PartsNBHA0052S01Mode door control system components are:
1) Auto amp.
2) Mode door motor (LCU)
3) In-vehicle sensor
4) Ambient sensor
5) Sunload sensor
6) Intake sensor
System OperationNBHA0052S02The auto amplifier receives data from each of the sensors. The amplifier sends air mix door and mode door
opening angle data to the air mix door motor LCU and mode door motor LCU.
The air mix door motor and mode door motor read their respective signals according to the address signal.
Opening angle indication signals received from the auto amplifier and each of the motor position sensors are
compared by the LCUs in each motor with the existing decision and opening angles. Subsequently, HOT/
COLD or DEFROST/VENT operation is selected. The new selection data is returned to the auto amplifier.
RHA870H
GI
MA
EM
LC
EC
FE
AT
TF
PD
AX
SU
BR
ST
RS
BT
SC
EL
IDX
TROUBLE DIAGNOSES
Mode Door Motor (Cont'd)
HA-77
Page 1877 of 2395
Mode Door Control SpecificationNBHA0052S03
RHA135G
RHA505G
COMPONENT DESCRIPTIONNBHA0053The mode door motor is attached to the heater unit. It rotates so
that air is discharged from the outlet set by the auto amplifier. Motor
rotation is conveyed to a link which activates the mode door.
RHA488GA
DIAGNOSTIC PROCEDURE FOR MODE DOOR MOTOR
AND AIR MIX DOOR MOTOR CIRCUIT
NBHA0104SYMPTOM: Mode door motor and/or air mix door motor does
not operate normally.
TROUBLE DIAGNOSES
Mode Door Motor (Cont'd)
HA-78
Page 1878 of 2395
1 CHECK POWER SUPPLY FOR AUTO AMP. (LCU) SIDE
Do approx. 12 volts exist between auto amp. (LCU) harness terminal No. 21 and body ground?
RHA819H
NOTE:
If the result is NG or No after checking circuit continuity, repair harness or connector.
YesorNo
Ye s©GO TO 2.
No©Replace auto amp. (LCU).
2 CHECK SIGNAL FOR AUTO AMP. (LCU) SIDE
Do approx. 5.5 volts exist between auto amp. (LCU) terminals No. 16 or 14 and body ground?
RHA820H
NOTE:
If the result is NG or No after checking circuit continuity, repair harness or connector.
YesorNo
Ye s©GO TO 3.
No©Replace auto amp. (LCU).
GI
MA
EM
LC
EC
FE
AT
TF
PD
AX
SU
BR
ST
RS
BT
SC
EL
IDX
TROUBLE DIAGNOSES
Mode Door Motor (Cont'd)
HA-79
Page 1879 of 2395
3 CHECK POWER SUPPLY FOR MOTOR SIDE
