Page 1377 of 2395

INFINITI QX4 2001 Factory Service Manual MEL835L AUTOMATIC DRIVE POSITIONER Wiring Diagram Ð AUT/DP Ð (Contd) EL-192

Page 1378 of 2395

INFINITI QX4 2001 Factory Service Manual MEL836L GI MA EM LC EC FE AT TF PD AX SU BR ST RS BT HA SC IDX AUTOMATIC DRIVE POSITIONER Wiring Diagram Ð AUT/DP Ð (Contd) EL-193

Page 1379 of 2395

INFINITI QX4 2001 Factory Service Manual MEL186M AUTOMATIC DRIVE POSITIONER Wiring Diagram Ð AUT/DP Ð (Contd) EL-194

Page 1380 of 2395

INFINITI QX4 2001 Factory Service Manual MEL187M GI MA EM LC EC FE AT TF PD AX SU BR ST RS BT HA SC IDX AUTOMATIC DRIVE POSITIONER Wiring Diagram Ð AUT/DP Ð (Contd) EL-195

Page 1381 of 2395

INFINITI QX4 2001 Factory Service Manual On Board DiagnosisNBEL0213 SEL354X HOW TO PERFORM SELF-DIAGNOSISNBEL0213S01 SEL596W *1: If no malfunction is indicated, self-diagnosis will end after the vehicle speed sensor diagnosis is performed. *

Page 1382 of 2395

INFINITI QX4 2001 Factory Service Manual MALFUNCTION CODE TABLE=NBEL0213S02In this mode, a malfunction code is indicated by the number of flashes from the automatic drive positioner indicator lamps (indicator lamp 1, indicator lamp 2) as sho

Page 1383 of 2395

INFINITI QX4 2001 Factory Service Manual Trouble DiagnosesNBEL0214WORK FLOWNBEL0214S01 SEL599W *1 EL-196 *2 EL-197 AUTOMATIC DRIVE POSITIONER Trouble Diagnoses EL-198

Page 1384 of 2395

INFINITI QX4 2001 Factory Service Manual PRELIMINARY CHECKNBEL0214S02 SEL600W *1: After reconnecting battery cable, perform initialization proce- dure A or B. If initialization has not been performed, automatic drive positioner will not oper
