Page 1521 of 2395

INFINITI QX4 2001 Factory Service Manual SYMPTOM MATRIX CHART 2NBEL0224S03(Non self-diagnosis related item) SYMPTOMDIAGNOSTIC PROCEDURE (Reference page)SYSTEM (Malfunctioning part or mode) Security ind. does not light up.PROCEDURE 6 (EL-344)

Page 1522 of 2395

INFINITI QX4 2001 Factory Service Manual DIAGNOSTIC PROCEDURE 2=NBEL0224S06Self-diagnostic results: ªCHAIN OF ECM-IMMUº displayed on CONSULT-II screen 1 CONFIRM SELF-DIAGNOSTIC RESULTS Confirm SELF-DIAGNOSTIC RESULTS ªCHAIN OF ECM-IMMUº

Page 1523 of 2395

INFINITI QX4 2001 Factory Service Manual 3 CHECK IGN SW. ON SIGNAL 1. Turn ignition switch ON. 2. Check voltage between terminal 7 of IMMU and ground with CONSULT-II or tester. SEL303WF OK or NG OK©GO TO 4. NG©Check the following I10A fuse

Page 1524 of 2395

INFINITI QX4 2001 Factory Service Manual 5 CHECK COMMUNICATION LINE OPEN CIRCUIT 1. Disconnect ECM connector. 2. Check harness continuity between ECM terminal 116 and IMMU terminal 1. SEL305WD OK or NG OK©GO TO 6. NG©Repair harness or conn

Page 1525 of 2395

INFINITI QX4 2001 Factory Service Manual 7 CHECK COMMUNICATION LINE GROUND SHORT CIRCUIT 1. Turn ignition switch OFF. 2. Check continuity between ECM terminal 116 or IMMU terminal 1 and ground. SEL307WD OK or NG OK©GO TO 8. NG©Communicatio

Page 1526 of 2395

INFINITI QX4 2001 Factory Service Manual DIAGNOSTIC PROCEDURE 3=NBEL0224S07Self-diagnostic results: ªDIFFERENCE OF KEYº displayed on CONSULT-II screen 1 CONFIRM SELF-DIAGNOSTIC RESULTS Confirm SELF-DIAGNOSTIC RESULTS ªDIFFERENCE OF KEYº

Page 1527 of 2395

INFINITI QX4 2001 Factory Service Manual DIAGNOSTIC PROCEDURE 4=NBEL0224S08Self-diagnostic results: ªCHAIN OF IMMU-KEYº displayed on CONSULT-II screen 1 CONFIRM SELF-DIAGNOSTIC RESULTS Confirm SELF-DIAGNOSTIC RESULTS ªCHAIN OF IMMU-KEYº

Page 1528 of 2395

INFINITI QX4 2001 Factory Service Manual DIAGNOSTIC PROCEDURE 5=NBEL0224S09Self-diagnostic results: ªID DISCORD, IMM-ECMº displayed on CONSULT-II screen 1 CONFIRM SELF-DIAGNOSTIC RESULTS Confirm SELF-DIAGNOSTIC RESULTS ªID DISCORD, IMM-EC
