Page 1313 of 2395

INFINITI QX4 2001 Factory Service Manual MEL805L WARNING CHIME Wiring Diagram Ð CHIME Ð (Contd) EL-128

Page 1314 of 2395

INFINITI QX4 2001 Factory Service Manual Trouble DiagnosesNBEL0055SYMPTOM CHARTNBEL0055S01 REFERENCE PAGE (EL- ) 129 131 133 134 135 SYMPTOM POWER SUPPLY AND GROUND CIRCUIT CHECK LIGHTING SWITCH INPUT SIGNAL CHECK KEY SWITCH (INSERT) CHECK S

Page 1315 of 2395

INFINITI QX4 2001 Factory Service Manual SEL013W Ground Circuit CheckNBEL0055S0202 Terminals Continuity 16 - Ground Yes WARNING CHIME Trouble Diagnoses (Contd) EL-130

Page 1316 of 2395

INFINITI QX4 2001 Factory Service Manual LIGHTING SWITCH INPUT SIGNAL CHECK=NBEL0055S03 1 CHECK LIGHTING SWITCH INPUT SIGNAL Check voltage between smart entrance control unit terminal 34 and ground. SEL377X OK or NG OK©Lighting switch is OK

Page 1317 of 2395

INFINITI QX4 2001 Factory Service Manual 4 CHECK TAIL LAMP SWITCH GROUND CIRCUIT 1. Disconnect headlamp battery saver control unit connector. 2. Check continuity between headlamp battery saver control unit terminal 5, 13 and ground. SEL379X

Page 1318 of 2395

INFINITI QX4 2001 Factory Service Manual KEY SWITCH (INSERT) CHECK=NBEL0055S04 1 CHECK KEY SWITCH INPUT SIGNAL Check voltage between smart entrance control unit terminal 32 and ground. SEL307X OK or NG OK©Key switch is OK. NG©GO TO 2. 2 CH

Page 1319 of 2395

INFINITI QX4 2001 Factory Service Manual SEAT BELT BUCKLE SWITCH CHECK=NBEL0055S05 1 CHECK SEAT BELT BUCKLE SWITCH INPUT SIGNAL 1. Turn ignition switch ªONº. 2. Check voltage between smart entrance control unit terminal 22 and ground. SEL3

Page 1320 of 2395

INFINITI QX4 2001 Factory Service Manual DRIVER SIDE DOOR SWITCH CHECKNBEL0055S06 1 CHECK DOOR SWITCH INPUT SIGNAL Check voltage between smart entrance control unit terminal 29 and ground. SEL382X OK or NG OK©Front door switch LH is OK. NG
