Page 1 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual D AEW OO M Y_2000
SECTION 0B
GENERAL INFORMATION
TABLE OF CONTENTS
Specifications 0B-- 2.............................
Technical Data 0B-- 2............................
Vehicle Dimensions and Weights 0

Page 2 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual 0B -- 2 GENERAL INFORMATION
D AEW OO M Y_2000
SPECIFICATIONS
TECHNICAL DATA
Transaxle Performance
Application661LA662NA662LA2.0L
DOHC2.3L
DOCH3.2L
DOCH
Maximum Speed (Km/h)140134148154165176
Minimum T

Page 3 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual GENERAL INFORMATION 0B -- 3
D AEW OO M Y_2000
Clutch - Manual Type
Application661LA662NA662LA2.0L
DOHC2.3L
DOCH3.2L
DOCH
Ty p eSingle Dry Diaphram
Outside Diameter (mm)225225240225225240
Inside Diamet

Page 4 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual 0B -- 4 GENERAL INFORMATION
D AEW OO M Y_2000
Tire and Wheel
ApplicationSpecifications
Standard Tire SizeP235/75 R15, 255/70 R15
Standard Wheel Size7JJx15
Inflation Pressure At Full Lode
P235 / 75 : F

Page 5 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual GENERAL INFORMATION 0B -- 5
D AEW OO M Y_2000
Electric System
Application661LA662NA662LA2.0L
DOHC2.3L
DOCH3.2L
DOCH
Battery (MF)12V -- 90AH
Generator75A75A75A75A115 A115A
Starter2.2kw2.2kw2.2kw1.2kw1.

Page 6 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual 0B -- 6 GENERAL INFORMATION
D AEW OO M Y_2000
VEHICLE DIMENSIONS AND WEIGHTS
Vehicle Dimensions
ApplicationSpecifications
Overall Length(mm)4330
Overall Width (mm)1841
Overall Height (mm)1840
Wheel Ba

Page 7 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual GENERAL INFORMATION 0B -- 7
D AEW OO M Y_2000
STANDARD BOLTSSPECIFICATIONS
Torque (NSm/Ib-in)
Bolt*StandardLimit
4T7T9T4T7T9T
M3 x 0.50.5 NSm
(4.5 lb-in)0.9 NSm
(8 lb-in)1.3 NSm
(12 lb-in)0.7 NSm
(6.3

GENERAL INFORMATION 0B -- 7
D AEW OO M Y_2000
STANDARD BOLTSSPECIFICATIONS
Torque (NSm/Ib-in)
Bolt*StandardLimit
4T7T9T4T7T9T
M3 x 0.50.5 NSm
(4.5 lb-in)0.9 NSm
(8 lb-in)1.3 NSm
(12 lb-in)0.7 NSm
(6.3 lb-in)1.2 NSm
(11 lb-in)17 NSm
(15 lb-in)
M4 x 0.71.2 NSm
(11 lb-in)2.0 NSm
(18 lb-in)3.0 NSm
(27 lb-in)1.6 NSm
(14 lb-in)2.6 NSm
(23 lb-in)4.0 NSm
(36 lb-in)
M5 x 0.82.4 NSm
(22 lb-in)4.0 NSm
(36 lb-in)5.6 NSm
(50 lb-in)3.1 NSm
(28 lb-in)5.2 NSm
(47 lb-in)7.6 NSm
(68 lb-in)
M6 x 1.04.0 NSm
(36 lb-in)6.7 NSm
(60 lb-in)9.7 NSm
(87 lb-in)5.4 NSm
(49 lb-in)9.0 NSm
(81 lb-in)12.7 NSm
(114 lb-in)
M8 x 1.258.6 NSm
(77 lb-in)15.7 NSm
(12 lb-in)22.5 NSm
(17 lb-in)12.7 NSm
(9 lb-in)20.6 NSm
(15.2 lb-in)30.4 NSm
(22 lb-in)
M10 x 1.2518.6 NSm
(14 lb-in)32.3 NSm
(24 lb-in)46.0 NSm
(34 lb-in)25.5 NSm
(19 lb-in)42.1 NSm
(31 lb-in)60.8 NSm
(31 lb-in)
M10 x 1.518.6 NSm
(14 lb-in)30.4 NSm
(22 lb-in)44.1 NSm
(33 lb-in)24.5 NSm
(18 lb-in)41.2 NSm
(30 lb-in)58.8 NSm
(44 lb-in)
M12 x 1.2534.3 NSm
(25lb-in)56.8 NSm
(42 lb-in)82.3 NSm
(61 lb-in)45.0 NSm
(33 lb-in)75.5 NSm
(56 lb-in)107.8 NSm
(80 lb-in)
M12 x 1.7532.3 NSm
(24 lb-in)53.9 NSm
(40 lb-in)77.4 NSm
(57 lb-in)43.1 NSm
(32 lb-in)71.5 NSm
(53 lb-in)98.0 NSm
(73 lb-in)
M14 x 1.554.0 NSm
(40 lb-in)89.2 NSm
(66 lb-in)127.4 NSm
(94 lb-in)71.6 NSm
(53 lb-in)117.6 NSm
(87 lb-in)166.6 NSm
(123 lb-in)
M16 x 1.581.3 NSm
(60 lb-in)107.8 NSm
(80 lb-in)196.0 NSm
(145 lb-in)107.8 NSm
(80 lb-in)186.2 NSm
(138 lb-in)264.6 NSm
(196 lb-in)
M18 x 1.5117.6 NSm
(87 lb-in)196.0 NSm
(145 lb-in)284.2 NSm
(210 lb-in)156.8 NSm
(116 lb-in)264.6 NSm
(196 lb-in)372.4 NSm
(276 lb-in)
M20 x 1.5166.6NSm
(123 lb-in)274.4 NSm
(203 lb-in)392.0 NSm
(290 lb-in)215.6 NSm
(160 lb-in)362.6 NSm
(268 lb-in)519.4 NSm
(384 lb-in)
M22 x 0.5225.4NSm
(167 lb-in)372.4 NSm
(276 lb-in)529.2 NSm
(392 lb-in)294.0 NSm
(218 lb-in)490.0 NSm
(362 lb-in)705.6 NSm
(522 lb-in)
M24 x 1.5284.2 NSm
(210 lb-in)480.2 NSm
(355 lb-in)686.0 NSm
(508 lb-in)382.2 NSm
(283 lb-in)637.0 NSm
(471 lb-in)921.2 NSm
(682 lb-in)
M24 x 2.0274.4 NSm
(203 lb-in)460.6 NSm
(341 lb-in)666.4 NSm
(493 lb-in)372.4 NSm
(276 lb-in)617.4 NSm
(457 lb-in)891.8 NSm
(660 lb-in)
* Diameter X pitch in millimeters
YAA5A5K0
YAA0B010

Page 8 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual 0B -- 8 GENERAL INFORMATION
D AEW OO M Y_2000
MAINTENANCE AND REPAIR
MAINTENANCE AND
LUBRICATION
NORMAL VEHICLE USE
The maintenance instructions contained in the mainte-
nance schedule are based on th

0B -- 8 GENERAL INFORMATION
D AEW OO M Y_2000
MAINTENANCE AND REPAIR
MAINTENANCE AND
LUBRICATION
NORMAL VEHICLE USE
The maintenance instructions contained in the mainte-
nance schedule are based on the assumption that the
vehicle will be used for the following reasons:
DTo carry passengers and cargo within the limitation of
the tire inflation prassure. Refer to “Tire and Wheel” in
section 2E.
DTo be driven on reasonable road surfaces and within
legal operating limits.
EXPLANATION OF SCHEDULED
MAINTENANCE SERVICES
The services listed in the maintenance schedule are fur-
ther explained below. When the following maintenance
services are performed, make sure all the parts are re-
placed and all the necessary repairs are done before
driving the vehicle. Always use the proper fluid and lubri-
cants.
Engine Oil and Oil Filter Change
Always use above the API SH grade or recommended
engine oil.
Engine Oil Viscosity
Engine oil viscosity (thickness) has an effect on fuel
economy and cold weather operation. Lower viscosity
engine oils can provide better fuel economy and cold
weather performance; however, higher temperature
weather conditions require higher viscosity engine oils
for satisfactory lubrication. Using oils of any viscosity
other than those viscosities recommended could result
in engine damage.
Cooling System Service
Drain, flush and refill the system with new coolant. Refer
to “Recommended Fluids And Lubricants“ in this sec-
tion.
Air Cleaner Element Replacement
Clean the air cleaner element every.
DGasoline Engine : 15,000km (10,000 miles)
DDiesel Engine : 10,000km (6,000 miles)
Replace the air cleaner element every .
DGasoline Engine : 60,000km (36,000 miles)DDiesel Engine : 30,000km (18,000 miles)
Replace the air cleaner more often under dusty condi-
tions.
Fuel Filter Replacement
Replace the engine fuel filter every.
DGasoline Engine : 60,000km (36,000 miles)
DDiesel Engine : 45,000km (24,000 miles)
Spark Plug Replacement
Replace spark plugs with same type.
DType : BOSCH : F8DC4
BERU : 14F-- 8DU4
Champion : C11YCC
DGap : 0.8±0.1 mm
Spark Plug Wire Replacement
Clean wires and inspect them for burns, cracks or other
damage. Check the wire boot fit at the Distributor and at
the spark plugs. Replace the wires as needed.
Brake System Service
Check the disc brake pads or the drum brake linings.
Check the pad and the lining thickness carefully.
Tire and Wheel Inspection and Rotation
Check the tires for abnormal wear or damage. To equal-
ize wear and obtain maximum tire life, rotate the tires. If
irregular or premature wear exists, check the wheel
alignment and check for damaged wheels. While the
tires and wheels are removed, inspect the brakes.
Tire Rotation (Left-hand Drive Type)

Load next 8 pages
