SSANGYONG KORANDO 1997 Service Repair Manual 5A-122 AUTOMATIC TRANSMISSION
SSANGYONG MY2002
Circuit Description
The solenoid 6 is a normally open ON/OFF type sole-
noid that is used to set the high/ low level of line pres-
sure.
The Solenoid 6

Page 1218 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual AUTOMATIC TRANSMISSION 5A-123
SSANGYONG MY2002
Inspect the wiring for poor electrical connections
at the TCM and at the 10-way transmission
connector. Look for possible bent, backed out,
deformed o

AUTOMATIC TRANSMISSION 5A-123
SSANGYONG MY2002
Inspect the wiring for poor electrical connections
at the TCM and at the 10-way transmission
connector. Look for possible bent, backed out,
deformed or damaged terminals. Check for weak
terminal tension as well. Also check for chafed wires
that could short to bare metal or other wiring.
Inspect for broken wire inside the insulation.
If diagnosing for a possible intermittent short or
open condition, move or massage the wiring
harness while observing test equipment for a
change.Test Description
The number(s) below refer to the step number(s) on
the Diagnostic Table.
3. Checks if the S6 circuit in the transmission is mal-
functioning.
4. Check cable in the transmission for open / short.
6. Check resistance between S6 terminal A and B.
Standard value is 22 - 30 Ω.
9. Check connections of other connectors
DTC P1738 Solenoid 6 Circuit Open
- Go to Step 11 - 1Perform a Transmission Control Module (TCM) System
Check.
Is the check performed?
1. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Record and then clear DTCs.
4. Operate the vehicle within the conditions for
setting this DTC as specified in the text.
Does the scan tool display P1738?
1. Turn the ignition OFF.
2. Disconnect the 10-way transmission connector.
(additional DTCs will set)
3. Connect Solenoid/Thermistor Electrical Tester
(STET) to the 10-way transmission connector of
transmission side and to the good ground.
4. Turn the mode knob of STET to 6 and push the red
button.
Does the bulb of open circuit on the solenoids side of
STET illuminate?
1. Remove the valve cover. Refer to the Transmission
in this section.
2. Check the wiring harness from 10-way transmission
connector to Solenoid 6 (S6) on the valve body for an
open or short to positive and repair as necessary.
Is a repair necessary?
Check the S6 ground circuit for an open and repair as
necessary.
Is a repair necessary?
Using a Digital Volt Meter (DVM), measure the resis-
tance between S6 terminal A and B.
Is the resistance within the specified value?
Replace the S6.
Is the action complete?
1. Disconnect the TCM connector A.
2. Check the wiring harness from 10-way transmission
connector terminal 6 to TCM terminal A12 for an open
and repair as necessary.
Is a repair necessary?
StepAction Value(s) Yes No
2
3
-
Go to Step 2 Go to “TCM
Diagnostic
System Check”
- Go to Step 4 Go to Step 8
5
6 4
- Go to Step 11 Go to Step 5
- Go to Step 11 Go to Step 6
7
8
- Go to Step 11 Go to Step 9
- Go to Step 3Go to
“Diagnostic
Aids”
22 - 30 ΩGo to
“Diagnostic
Aids” Go to Step 7

Page 1219 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual 5A-124 AUTOMATIC TRANSMISSION
SSANGYONG MY2002
DTC P1738 Solenoid 6 Circuit Open (Contd)
Check for a poor connection at the 10-way transmission
connector and TCM connector and repair the malfunc-
t

Page 1220 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual AUTOMATIC TRANSMISSION 5A-125
SSANGYONG MY2002
BLANK

Page 1221 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual 5A-126 AUTOMATIC TRANSMISSION
SSANGYONG MY2002
Circuit Description
The solenoid 7 is a normally open ON/OFF type sole-
noid that is used to control the application of the
Torque Converter Clutch (TC

5A-126 AUTOMATIC TRANSMISSION
SSANGYONG MY2002
Circuit Description
The solenoid 7 is a normally open ON/OFF type sole-
noid that is used to control the application of the
Torque Converter Clutch (TCC).
The Solenoid 7 (S7) ON activates the TCC and the S7
is attached to the pump body within the transmission.
Voltage is supplied directly to the solenoid through
the Transmission Control Module (TCM).
The DTC P1739 sets when the solenoid 7, Torque Con-
verter Clutch Solenoid, circuit is open or the switched
leg of the solenoid 7 is shorted to battery positive.
The solenoid 7's driver Integrated Chip (IC) status
indicates a faulty circuit.
Conditions for Setting the DTC
DTCs P1717 and P1718 are not set.
S7 is OFF.
S3 is OFF.
The solenoid 7's driver Integrated Chip (IC) status
indicates a faulty circuit. This condition must be
continuously present for 60 milliseconds.
Action Taken When the DTC Sets
The solenoid 7 is always disabled (OFF) resulting
in the TCC being unlocked always.
DIAGNOSTIC TROUBLE CODE (DTC) P1739
SOLENOID 7 CIRCUIT OPEN
Conditions for Clearing the DTC
The DTC will clear when the malfunction has not
occurred after ignition cycle.
A history DTC will clear after 40 TCM power-up
cycles with a warm transmission (>50 °C) and
without a fault.
History DTCs can be cleared by using a scan tool.
Diagnostic Aids
During the TCM's testing, solenoid 7 is turned OFF/
ON by a very small (4 millisecond) pulses. This
pulse is too short for the solenoid to react so the
transmission operation is not affected.
The solenoid feedback voltage is measured before
the (4 millisecond) pulse and again during the pulse.
If the difference is outside the acceptable limits
the relevant fault is recorede.
Typical causes would be an open circuit in the wiring
to or within the solenoid, or a short circuit to power
in the wiring to or within the solenoid.
If several faults of solenoids are present, check the
wiring or connectors that are common to the selected
solenoids, especially the earth connections.
Inspect the wiring for poor electrical connections
at the TCM and at the 10-way transmission
connector.
KAC5A030

Page 1222 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual AUTOMATIC TRANSMISSION 5A-127
SSANGYONG MY2002
DTC P1739 Solenoid 7 Circuit Open
Look for possible bent, backed out, deformed or
damaged terminals. Check for weak terminal
tension as well. Also chec

AUTOMATIC TRANSMISSION 5A-127
SSANGYONG MY2002
DTC P1739 Solenoid 7 Circuit Open
Look for possible bent, backed out, deformed or
damaged terminals. Check for weak terminal
tension as well. Also check for chafed wires that
could short to bare metal or other wiring. Inspect
for broken wire inside the insulation.
If diagnosing for a possible intermittent short or
open condition, move or massage the wiring
harness while observing test equipment for a
change.
Test Description
The number(s) below refer to the step number(s) on
the Diagnostic Table.3. Checks if the S7 circuit in the transmission is mal-
functioning.
4. Check cable in the transmission for open / short.
If the problem is found in the wiring harness from
10-way transmission connector to contact point
attached onto the transmission case, repair it with
removing the valve cover. Refer to the
Transmission in this section.
7. Check resistance between S7 terminal A and B.
Standard value is 22 - 30 Ω.
10. Check connections of other connectors.
- Go to Step 12 Go to Step 7 1Perform a Transmission Control Module (TCM) System
Check.
Is the check performed?
1. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Record and then clear DTCs.
4. Operate the vehicle within the conditions for
setting this DTC as specified in the text.
Does the scan tool display P1739?
1. Turn the ignition OFF.
2. Disconnect the 10-way transmission connector.
(additional DTCs will set)
3. Connect Solenoid/Thermistor Electrical Tester
(STET) to the 10-way transmission connector of
transmission side and to the good ground.
4. Turn the mode knob of STET to 7 and push the red
button.
Does the bulb of open circuit on the solenoids side of
STET illuminate?
1. Remove the pump assembly. Refer to the Pump in
this section.
2. Check the wiring harness from 10-way transmission
connector to contact point attached onto the
transmission case for an open or short to positive
and repair as necessary.
Is a repair necessary?
Check the wiring harness from contact point attached
onto the transmission case to S7 for an open or short
to positive and repair as necessary.
Is a repair necessary?
Check the S7 ground circuit for an open and repair as
necessary.
Is a repair necessary?
Using a Digital Volt Meter (DVM), measure the resis-
tance between S7 terminal A and B.
Is the resistance within the specified value?
Replace the S7.
Is the action complete?
StepAction Value(s) Yes No
2
3
-
Go to Step 2 Go to “TCM
Diagnostic
System Check”
- Go to Step 4 Go to Step 9
5
6 4
- Go to Step 12 Go to Step 5
- Go to Step 12 Go to Step 6
7
8
- Go to Step 12 -
- Go to Step 3 Go to
“Diagnostic
Aids”
22 - 30 ΩGo to
“Diagnostic
Aids” Go to Step 8

Page 1223 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual 5A-128 AUTOMATIC TRANSMISSION
SSANGYONG MY2002
DTC P1739 Solenoid 7 Circuit Open (Contd)
1. Disconnect the TCM connector A.
2. Check the wiring harness from 10-way transmission
connector terminal 7

Page 1224 of 2053

SSANGYONG KORANDO 1997 Service Repair Manual AUTOMATIC TRANSMISSION 5A-129
SSANGYONG MY2002
BLANK
