NISSAN LATIO 2011 Service Repair Manual AT-64
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
Move selector lever from “2” to “1” position while driving in 22 .
Read gear position. Refer to AT-77, "
CONSULT-III Function
(TRANSMISSION)"

AT-64
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
Move selector lever from “2” to “1” position while driving in 22 .
Read gear position. Refer to AT-77, "
CONSULT-III Function
(TRANSMISSION)" .
Does A/T shift from 2
2 to 11 position?
YES >> GO TO 6.
NO >> • Mark the box on the “Diagnostic Worksheet Chart”. •Go to AT-199, "
A/T Does Not Shift: 22→ 11, When
Selector Lever "2" → "1" Position" .
• Continue “Road Test”.
6.CHECK ENGINE BRAKE
Check engine brake.
Does vehicle decelerate by engine brake?
YES >> 1. Stop vehicle. 2. Perform self-diagnosis. Refer to AT-77, "
CONSULT-
III Function (TRANSMISSION)" , AT-82, "Diagnosis
Procedure without CONSULT-III" .
NO >> • Mark the box on the “Diagnostic Worksheet Chart”. •Go to AT-201, "
Vehicle Does Not Decelerate by
Engine Brake" .
• Stop “Road Test”.
Vehicle Speed at Which Gear Shifting OccursINFOID:0000000005928101
MR16DE engine models
MR18DE engine models
• At half throttle, the accelerator opening is 4/8 of the full opening.
Vehicle Speed at Which Lock-up Occurs/ReleasesINFOID:0000000005928102
MR16DE engine models
MR18DE engine models
SAT778B
SAT778B
Throttle position Vehicle speed km/h (MPH)
D1→ D2D2→ D3D3→ D4D4→ D3D3→ D2D2→ D1
Full throttle 49 - 57
(31 - 35) 93 - 101
(58 - 62) 148 - 156
(92 - 96) 144 - 152
(90 - 94) 82 - 90
(51 - 55) 39 - 47
(25 - 29)
Half throttle 35 - 43
(22 - 26) 59 - 67
(37 - 41) 117 - 125
(73 - 77) 59 - 67
(37 - 41) 34 - 42
(22 - 26) 15 - 23
(10 - 14)
Throttle position Vehicle speed km/h (MPH)
D
1→ D2D2→ D3D3→ D4D4→ D3D3→ D2D2→ D1
Full throttle 51 - 59
(32 - 37) 97 - 105
(60 - 65) 154 - 162
(96 - 101) 150 - 158
(93 - 98) 87 - 95
(54 - 59) 40 - 48
(25 - 30)
Half throttle 34 - 42
(21 - 26) 62 - 70
(39 - 43) 124 - 132
(77 - 82) 69 - 77
(43 - 48) 36 - 44
(22 - 27) 19 - 27
(12 - 17)
Throttle position Selector lever position Vehicle speed km/h (MPH)
Lock-up ON Lock-up OFF
2.0/8 “D” position
73 - 81 (46 - 50) 49 - 57 (31 - 35)
“D” position (OD OFF) 86 - 94 (53 - 58)82 - 90 (51 - 55)
Throttle position Selector lever position Vehicle speed km/h (MPH)
Lock-up ON Lock-up OFF
2.0/8 “D” position
86 - 94 (53 - 58) 59 - 67 (37 - 42)
“D” position (OD OFF) 86 - 94 (53 - 58)83 - 91 (52 - 57)
Revision: May 2010 2011 Versa

Page 82 of 3787

NISSAN LATIO 2011 Service Repair Manual TROUBLE DIAGNOSISAT-65
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
Symptom ChartINFOID:0000000005928103
Numbers are arranged in order of inspection.
Perform inspections starting with numbe

Page 83 of 3787

NISSAN LATIO 2011 Service Repair Manual AT-66
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
Shift ShockSharp shock in shift-
ing from “N” to “D” po-
sition.
ON vehicle1. Engine idling speed
EC-24

(HR16DE), EC-
578 (MR18DE)
2. Accel

Page 84 of 3787

NISSAN LATIO 2011 Service Repair Manual TROUBLE DIAGNOSISAT-67
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
Improper Shift Timing Too high a gear
change point from D
1
to D
2 , from D2 to D3 ,
from D
3 to D4 . ON vehicle 1.

Page 85 of 3787

NISSAN LATIO 2011 Service Repair Manual AT-68
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
No Down ShiftFailure to change
gear from D
4 to D3 .
ON vehicle 1. A/T fluid level
AT- 1 7
2. Accelerator pedal position sensorEC-415

(HR16DE), EC-

Page 86 of 3787

NISSAN LATIO 2011 Service Repair Manual TROUBLE DIAGNOSISAT-69
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
No Up Shift Failure to change
gear from D
1 to D2 .
ON vehicle 1. Control cable adjustment
AT- 2 1 7
2. Shift solenoid

Page 87 of 3787

NISSAN LATIO 2011 Service Repair Manual AT-70
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
Slips/Will Not EngageVehicle will not run in
“R” position (but runs
in “D”, “2” and “1” po-
sitions). Clutch slips.
Very poor accelera

Page 88 of 3787

NISSAN LATIO 2011 Service Repair Manual TROUBLE DIAGNOSISAT-71
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
Slips/Will Not Engage No creep at all.
AT- 1 8 5
, AT- 1 8 6
ON vehicle
1. A/T fluid level
AT- 1 72. Line pressure testAT
