Page 2441 of 3787
TIMING CHAINEM-51
< ON-VEHICLE REPAIR > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
9. Remove front cover with the following procedure:
a. Loosen bolts in the reverse of the order shown.
b. Cut liquid gasket by prying the position ( ) shown, and then
remove the front cover.
10. Remove front oil seal from front cover. • Remove by lifting it up using a suitable tool.
CAUTION:
Be careful not to damage the front cover.
11. Remove chain tensioner (1) with the following procedure.
a. Fully push down the chain tensioner lever (A), and then push the plunger (C) into the inside of tensioner.
• The tab (B) is released by fully pushing the lever down. As aresult, the plunger can be moved.
b. Pull up the lever to align its hole position with the body hole posi- tion.
• When the lever hole is aligned with the body hole position, theplunger is fixed.
• When the protrusion parts of the plunger ratchet and the tab face each other, both hole positions are not aligned. At that
time, correctly engage them and align these hole positions by
slightly moving the plunger.
c. Insert the stopper pin (D) into the body hole through the lever hole, and then fix the lever at the upper position.
• The example that a hexagonal wrench for 2.5 mm (0.098 in) is used as shown.
d. Remove chain tensioner.
KBIA3429J
PBIC3712E
PBIC3713E
Revision: May 2010 2011 Versa
Page 2442 of 3787
EM-52
< ON-VEHICLE REPAIR >[HR16DE]
TIMING CHAIN
12. Remove the timing chain tension guide (2) and the timing chain
slack guide (1).
13. Remove the timing chain (2). • Pull the looseness of timing chain toward the camshaft
sprocket (EXH) (1), and then remove the timing chain (2) and
start the removal from camshaft sprocket (EXH) (1) side.
CAUTION:
Never rotate crankshaft or camshaft while timing chain is
removed. It causes interferen ce between valve and piston.
14. Remove the crankshaft sprocket and the oil pump drive related parts with the following procedure.
a. Remove chain tensioner (1). • Pull out from the shaft (B) and spring fixing holes (A).
b. Hold the top of the oil pump s haft using the TORX socket (size:
E8), and then loosen the oil pump sprocket nut and remove it.
c. Remove the crankshaft sprocket (1), the oil pump drive chain (2), and the oil pump sprocket (3) at the same time.
INSTALLATION
NOTE:
PBIC3714E
PBIC3715E
PBIC3716E
PBIC3720E
Revision: May 2010 2011 Versa
Page 2443 of 3787
TIMING CHAINEM-53
< ON-VEHICLE REPAIR > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
The illustration shows the relationship between the matching mark
on each timing chain and that on the corresponding sprocket, with
the components installed.
1. Install the crankshaft sprocket and the oil pump drive related parts with the following procedure:
a. Install the crankshaft sprocket (1), the oil pump drive chain (2),
and the oil pump sprocket (3) at the same time.
• Install the crankshaft sprocket (1) so that its invalid gear area(A) is towards the back of the engine.
• Install the oil pump sprocket (3) so that its hexagonal surface
faces (B) the front of engine.
NOTE:
There is no matching mark in the oil pump drive related parts.
b. Hold the top of the oil pump shaft using the TORX socket (size: E8), and then tighten the oil pump sprocket nuts.
1 : Timing chain
2 : Camshaft sprocket (EXH)
3 : Timing chain slack guide
4 : Chain tensioner
5 : Oil pump drive chain
6 : Oil pump sprocket
7 : Crankshaft sprocket
8 : Timing chain tension guide
9 : Camshaft sprocket (INT)
A : Dark blue link
B : Matching mark (stamp)
C : Orange link
D : Matching mark (stamp)
E : Crankshaft key (point straight up)
F : Matching mark (peripheral stamp line)
G : Dark blue link
PBIC3718E
: Engine front
PBIC3719E
1 : Crankshaft sprocket
2 : Oil pump drive chain
3 : Oil pump sprocket
PBIC3720E
Revision: May 2010 2011 Versa
Page 2444 of 3787
EM-54
< ON-VEHICLE REPAIR >[HR16DE]
TIMING CHAIN
c. Install chain tensioner (1).
• Insert the body into the shaft (B) while inserting the spring intothe fixing hole (A) of cylinder block front surface.
• Make sure that the tension is applied to the oil pump drive chain after installing.
2. Install timing chain with the following procedure.
• Install by aligning matching marks on each sprocket and tim-ing chain.
• If these matching marks are not aligned, rotate the camshaft slightly to correct the position.
CAUTION:
• Check matching mark positi on of each sprocket and tim-
ing chain again after instal ling the timing chain, keep
matching marks aligned by holding them with a hand.
• To avoid skipped teeth, never rotate crankshaft and cam-
shaft until front cover is installed.
3. Install timing chain tension guide (2) and timing chain slack guide (1).
4. Install chain tensioner (1). • Secure the plunger at the most compressed position using astopper pin (A), and then install it.
• Pull out the stopper pin after installing the chain tensioner.
PBIC3716E
A : Dark blue link
B : Matching mark (stamp)
C : Orange link
D : Matching mark (stamp)
E : Crankshaft key (point straight up)
F : Matching mark (peripheral stamp line)
G : Dark blue link
PBIC3721E
PBIC3714E
PBIC3722E
Revision: May 2010 2011 Versa
Page 2445 of 3787
TIMING CHAINEM-55
< ON-VEHICLE REPAIR > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
5. Check matching mark position of timing chain and each sprocket again.
6. Pull out the stopper pin (A), and then apply the tension to the
timing chain by rotating the crankshaft pulley clockwise slightly.
7. Return the camshaft sprocket (INT) in the most retarded position with the following procedure.
a. Remove the stopper pin (A) from the camshaft sprocket (INT).
b. Turn the crankshaft slowly clockwise and return t he camshaft sprocket (INT) to the most retarded angle
position.
• When first turning the crankshaft the camshaft sprocket (INT)
will turn. Once it is turned more, and the vane (camshaft) also
turns, then it has reached t he most retarded angle position.
• The most retarded angle position can be checked by seeing if the stopper pin groove (A) is shifted clockwise.
• After spinning the crankshaft slightly in the counterclockwise
direction, you can make sure the lock pin has joined by seeing
if the vane (camshaft) and the sprocket move together.
8. Install the front oil seal to the front cover. Refer to EM-71, "
FRONT OIL SEAL : Removal and Installation"
9. Install front cover with the following procedure:
1 : Plunger
2 : Chain tensioner
B: Lever
C: Lever hole
D : Front cover has been omitted
PBIC3772E
B: Tape
AWBIA0107ZZ
B : Stopper pin hole
C : Most advanced angle
D : Most retarded angle (lock pin engaged)
PBIC3705E
Revision: May 2010 2011 Versa
Page 2446 of 3787
EM-56
< ON-VEHICLE REPAIR >[HR16DE]
TIMING CHAIN
a. Apply a continuous bead of liquid gasket with Tool to front of
engine as shown.
Use Genuine Silicone RTV Sealant or equivalent. Refer to
GI-42, "
Recommended Chemical Product and Sealant".
b. Apply a continuous bead of liquid gasket with Tool to front cover as shown.
Use Genuine Silicone RTV Sealant or equivalent. Refer to
GI-42, "
Recommended Chemical Product and Sealant".
1 : Cylinder head
2 : Cylinder block
3 : Oil pan (upper)
A : Liquid gasket application φ 3.0 - 4.0 mm (0.12 - 0.16 in) dia.
Tool number : WS39930000 ( — )
PBIC3724E
A : Liquid gasket application φ 3.0 - 4.0 mm (0.12 - 0.16 in) dia.
Tool number : WS39930000 ( — )
PBIC3725E
Revision: May 2010 2011 Versa
Page 2447 of 3787
TIMING CHAINEM-57
< ON-VEHICLE REPAIR > [HR16DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
c. Tighten bolts in the numerical order shown.
d. After all bolts are tightened, retighten them to specified torque in
numerical order as shown.
CAUTION:
Be sure to wipe off any excessive liquid gasket leaking to
surface.
10. Insert crankshaft pulley by aligning with crankshaft key. • When inserting crankshaft pulley with a plastic hammer, tap on its center portion (not circumference).
CAUTION:
Never damage front oil seal lip section.
11. Tighten crankshaft pulley bolt with the following procedure: • Secure crankshaft pulley with a suitable tool, and tighten crankshaft pulley bolt.
a. Apply new engine oil to thread and seat surfaces of crankshaft pulley bolt.
b. Tighten crankshaft pulley bolt.
c. Put a paint mark (B) on crankshaft pulley, mating with any one of six easy to recognize angle marks (A) on crankshaft bolt flange
(1).
d. Turn another 60 degrees clockwise (angle tightening). • Check the tightening angle with movement of one angle mark.
12. Make sure that crankshaft turns smoothly by rotating by hand clockwise.
13. Installation of the remaining components is in the reverse order of removal.
InspectionINFOID:0000000005930953
INSPECTION AFTER REMOVAL
Timing Chain
KBIA3429J
Crankshaft pulley bolt : 35.0 N·m (3.6 kg-m, 26 ft-lb)
PBIC3726E
Revision: May 2010 2011 Versa
Page 2448 of 3787
EM-58
< ON-VEHICLE REPAIR >[HR16DE]
TIMING CHAIN
Check for cracks (A) and any excessive wear (B) at link plates and
roller links of timing chain. Replace timing chain as necessary.
INSPECTION AFTER INSTALLATION
• Before starting engine, check oil/fluid levels incl
uding engine coolant and engine oil. If less than required
quantity, fill to the specified level. Refer to MA-14, "
Fluids and Lubricants".
• Use procedure below to check for fuel leakage.
• Turn ignition switch ON (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leak-
age at connection points.
• Start engine. With engine speed increased, che ck again for fuel leakage at connection points.
• Run engine to check for unusual noise and vibration.
• Warm up engine thoroughly to make sure there is no leakage of fuel, exhaust gas, or any oils/fluids including engine oil and engine coolant.
• Bleed air from passages in lines and hoses, such as in cooling system.
• After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to spec- ified level, if necessary.
• Summary of the inspection items:
*Power steering fluid, brake fluid, etc.
JPBIA0091ZZ
Item Before starting engine Engine runningAfter engine stopped
Engine coolant LevelLeakage Level
Engine oil LevelLeakage Level
Transmission/
transaxle fluid A/T and CVT Models
LeakageLevel/Leakage Leakage
M/T Models Level/Leakage LeakageLevel/Leakage
Other oils and fluids* LevelLeakage Level
Fuel LeakageLeakage Leakage
Exhaust gas —Leakage —
Revision: May 2010 2011 Versa
