Page 2657 of 3787

NISSAN LATIO 2011 Service Repair Manual FRONT DRIVE SHAFTFAX-15 < SERVICE INFORMATION > CEF G H I J K L M A B FA X N O P 1. Install new boot and new small boot band on shaft. CAUTION: • Do not reuse boot or boot band. • Cover drive shaf

Page 2658 of 3787

NISSAN LATIO 2011 Service Repair Manual FAX-16 < SERVICE INFORMATION > FRONT DRIVE SHAFT 2. Pull and tighten the boot band using suitable tool until bothpawls of boot band are secured in the boot band grooves. CAUTION: Do not reuse boot ban

Page 2659 of 3787

NISSAN LATIO 2011 Service Repair Manual FRONT DRIVE SHAFTFAX-17 < SERVICE INFORMATION > CEF G H I J K L M A B FA X N O P 4. Attach new circlip to shaft. Thread nut onto end of joint sub- assembly and press fit using suitable tool. CAUTION:

Page 2660 of 3787

NISSAN LATIO 2011 Service Repair Manual FAX-18 < SERVICE INFORMATION > FRONT DRIVE SHAFT Damper 1. Secure damper with new damper bands.CAUTION: Do not reuse damper bands. Disassembly and Asse mbly (Right Side)INFOID:0000000005931074 DISASSE

Page 2661 of 3787

NISSAN LATIO 2011 Service Repair Manual FRONT DRIVE SHAFTFAX-19 < SERVICE INFORMATION > CEF G H I J K L M A B FA X N O P 4. Put matching marks on spider assembly and shaft. 5. Remove snap ring using a suitable tool, then remove spider assem

Page 2662 of 3787

NISSAN LATIO 2011 Service Repair Manual FAX-20 < SERVICE INFORMATION > FRONT DRIVE SHAFT 2. Remove dust shield, then remove snap ring using a suitabletool. 3. Press support bearing assembly off slide joint assembly using a suitable tool. 4.

Page 2663 of 3787

NISSAN LATIO 2011 Service Repair Manual FRONT DRIVE SHAFTFAX-21 < SERVICE INFORMATION > CEF G H I J K L M A B FA X N O P 1. Install new boot and new small boot band on shaft. CAUTION: • Do not reuse boot or boot band. • Cover drive shaf

Page 2664 of 3787

NISSAN LATIO 2011 Service Repair Manual FAX-22 < SERVICE INFORMATION > FRONT DRIVE SHAFT 2. Pull and tighten the boot band using suitable tool until bothpawls of boot band are secured in the boot band grooves. CAUTION: Do not reuse boot ban
