P1760 OVERRUN CLUTCH SOLENOID
• Check resistance between terminal and ground.
Operation Check
• Check solenoid valve by listening for its operating sound whileapplying battery voltage to the terminal and ground.
Solenoid valve Connector Terminal Resistance (Approx.)
Overrun clutch solenoid
valve F30 3 - Ground 20 - 30
Ω
SCIA2059E
SCIA2062E
Revision: May 2010 2011 Versa
Page 170 of 3787
VEHICLE SPEED SIGNALAT-153
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
VEHICLE SPEED SIGNAL
DescriptionINFOID:0000000005928210
The vehicle speed signal is built into the speedometer assembly. The sensor functions as an auxiliary device
to the output speed sensor when it is malfunctioning. The TCM will then use a signal sent from the vehicle
speed signal.
CONSULT-III Reference Val ue in Data Monitor ModeINFOID:0000000005928211
Remarks: Specification data are reference values.
On Board Diagnosis LogicINFOID:0000000005928212
• This is not an OBD-II self-diagnostic item.
• Diagnostic trouble code “VEHECLE SPEED SIGNAL” with CONSULT-III or 2nd judgement flicker without
CONSULT-III is detected when TCM does not rece ive the proper voltage signal from the sensor.
Possible CauseINFOID:0000000005928213
• Harness or connector
(The sensor circuit is open or shorted.)
• Vehicle speed signal
DTC Confirmation ProcedureINFOID:0000000005928214
CAUTION:
• Always drive vehicle at a safe speed.
• If performing this “DTC Confirmation Procedure” again, always turn ignition switch OFF and wait at
least 10 seconds before continuing.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON and select “DATA MO NITOR” mode for “TRANSMISSION” with CONSULT-III.
2. Touch “START”.
3. Start engine and accelerate vehicle from 0 to 25 km/h (0 to 16 MPH).
4. If the check result is NG, go to AT-155, "
Diagnosis Procedure" .
WITHOUT CONSULT-III
1. Start engine.
2. Drive vehicle under the following conditions:
Selector lever posi tion: “D” position
Vehicle speed: Higher than 25 km/h (16 MPH)
3. Perform self-diagnosis. Refer to AT-82, "
Diagnosis Procedure without CONSULT-III" .
4. If the check result is NG, go to AT-155, "
Diagnosis Procedure" .
Item name ConditionDisplay value
VHCL/S SE-MTR During driving Approximately matches the speedometer reading.
Revision: May 2010 2011 Versa
Page 171 of 3787
AT-154
< SERVICE INFORMATION >
VEHICLE SPEED SIGNAL
Wiring Diagram - AT - VSSMTR
INFOID:0000000005928215
TCM TERMINALS AND REFERENCE VALUES
Refer to AT-75, "TCM Terminal and Reference Value".
BCWA0658E
Revision: May 2010 2011 Versa
Page 172 of 3787
VEHICLE SPEED SIGNALAT-155
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
Diagnosis ProcedureINFOID:0000000005928216
1.CHECK INPUT SIGNALWith CONSULT-III
1. Start engine.
2. Select “TCM INPUT SIGNALS” in “DATA MONI TOR” mode for “TRANSMISSION” with CONSULT-III.
3. Read out the value of “VHCL/S SE-MTR” while driv ing. Check the value changes according to driving
speed.
Without CONSULT-III
1. Start engine.
2. Check voltage between TCM connector terminal and ground.
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2.DETECT MALFUNCTIONING ITEM
Check the following items:
• Combination meter. Refer to DI-4
.
• Harness for short or open between TCM and combination meter.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.CHECK DTC
Perform AT-153, "
DTC Confirmation Procedure" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 4.
4.CHECK TCM
1. Check TCM input/output signal. Refer to AT-75, "
TCM Terminal and Reference Value" .
2. If NG, recheck TCM pin terminals for dam age or loose connection with harness connector.
OK or NG
OK >> INSPECTION END
NG >> Repair or replace damaged parts.
Item name ConditionDisplay value
VHCL/S SE-MTR During driving Approximately matches
the speedometer reading.
Item Connec-
tor Terminal Condition Judgement
standard (Ap- prox.)
Vehicle
speed signal E32 40 -
Ground When driving vehicle at
2 to 3 km/h (1 to 2 MPH)
for 1 m (3 ft) or more. Voltage varies
between less
than 0 V and
more than 4.5
V
SCIA3246E
