NISSAN LATIO 2011 Service Repair Manual REFRIGERANT LINESMTC-77 < SERVICE INFORMATION > C DE F G H I K L M A B MTC N O P MR18DE - Type 2 WJIA2202E 1. Evaporator 2. Expansion valve3. Low-pressure service valve 4. High-pressure service valve

Page 3394 of 3787

NISSAN LATIO 2011 Service Repair Manual MTC-78 < SERVICE INFORMATION > REFRIGERANT LINES Idler Pulley - Without A/C Refer to MTC-5, "Precaution for Refrigerant Connection". Removal and Installation of Compressor - HR16DEINFOID:000000000593

Page 3395 of 3787

NISSAN LATIO 2011 Service Repair Manual REFRIGERANT LINESMTC-79 < SERVICE INFORMATION > C DE F G H I K L M A B MTC N O P 1. Use the recovery/recycling equipment to evacuate the refrigerant. Refer to MTC-74, "HFC-134a (R-134a) Service Proce

Page 3396 of 3787

NISSAN LATIO 2011 Service Repair Manual MTC-80 < SERVICE INFORMATION > REFRIGERANT LINES Removal and Installation of Compressor - MR18DE INFOID:0000000005930873 MR18DE REMOVAL 1. Use the recovery/recycling equipment to evacuate the refrige

Page 3397 of 3787

NISSAN LATIO 2011 Service Repair Manual REFRIGERANT LINESMTC-81 < SERVICE INFORMATION > C DE F G H I K L M A B MTC N O P INSPECTION FOR CLUTCH DISC TO PULLEY CLEARANCE 1. Check the clearance (B) around the entire periphery of the clutch dis

Page 3398 of 3787

NISSAN LATIO 2011 Service Repair Manual MTC-82 < SERVICE INFORMATION > REFRIGERANT LINES 6. Remove the magnet coil snap ring (A) using a suitable tool.Then remove the magnet coil (1) from compressor shaft. INSPECTION AFTER REMOVAL Clutch Di

Page 3399 of 3787

NISSAN LATIO 2011 Service Repair Manual REFRIGERANT LINESMTC-83 < SERVICE INFORMATION > C DE F G H I K L M A B MTC N O P 3. Install the pulley assembly using Tool and a wrench, and then install the snap ring using snap ring pliers. 4. Insta

Page 3400 of 3787

NISSAN LATIO 2011 Service Repair Manual MTC-84 < SERVICE INFORMATION > REFRIGERANT LINES 2. Remove the three rubber plugs (1) from the clutch disc (2). Toease removal, apply some light lubricant to the three rubber plugs (1). NOTE: The thre
