Page 641 of 3787

NISSAN LATIO 2011 Service Repair Manual INTELLIGENT KEY SYSTEMBL-131 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P 4.CHECK IGNITION KN OB SWITCH CIRCUIT 1. Disconnect Intelligent Key unit connector. 2. Check continuity between Int

Page 642 of 3787

NISSAN LATIO 2011 Service Repair Manual BL-132 < SERVICE INFORMATION > INTELLIGENT KEY SYSTEM OK or NG OK >> Door switch circuit is OK. NG >> GO TO 2 2.CHECK DOOR SWITCH CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect door switch and BCM

Page 643 of 3787

NISSAN LATIO 2011 Service Repair Manual INTELLIGENT KEY SYSTEMBL-133 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P Check continuity between front door switch terminal 2 or rear door switch terminal 1 and exposed metal of switch wh

Page 644 of 3787

NISSAN LATIO 2011 Service Repair Manual BL-134 < SERVICE INFORMATION > INTELLIGENT KEY SYSTEM Door Switch Check (Sedan) INFOID:0000000006222721 1.CHECK DOOR SWITCHES INPUT SIGNAL With CONSULT-III Check door switches ("DOOR SW-DR", "DOOR SW-

Page 645 of 3787

NISSAN LATIO 2011 Service Repair Manual INTELLIGENT KEY SYSTEMBL-135 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P OK or NG OK >> GO TO 3 NG >> Repair or replace harness. 3.CHECK DOOR SWITCHES Check continuity between door switch

Page 646 of 3787

NISSAN LATIO 2011 Service Repair Manual BL-136 < SERVICE INFORMATION > INTELLIGENT KEY SYSTEM 4. Check continuity between Intelligent Key unit connector andground. OK or NG OK >> GO TO 3 NG >> Repair or replace harness between Intelligent K

Page 647 of 3787

NISSAN LATIO 2011 Service Repair Manual INTELLIGENT KEY SYSTEMBL-137 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P OK or NG OK >> Check the condition of harness and connector. NG >> Replace Intelligent Key unit. Refer to BL-158,

Page 648 of 3787

NISSAN LATIO 2011 Service Repair Manual BL-138 < SERVICE INFORMATION > INTELLIGENT KEY SYSTEM OK or NG OK >> GO TO 3 NG >> Repair or replace harness between Intelligent Key unit and back door request switch. 3.CHECK BACK DOOR REQUEST SWITCH
