Page 1697 of 5127

CHEVROLET AVEO 2002 Service Repair Manual Removing the Spare Tire and Tools The compact spare tire and tools you will need are located in the cargo area. A. Jack B. Wheel WrenchC. Jack Handle D. Screwdriver1. Lift the trim cover. 2. Remove th

Page 1698 of 5127

CHEVROLET AVEO 2002 Service Repair Manual 3. Turn the retainer on the compact spare tire counterclockwise and remove the retainer. 4. Remove the compact spare tire. SeeCompact Spare Tire on page 5-75for more information. Removing the Flat Tir

Page 1699 of 5127

CHEVROLET AVEO 2002 Service Repair Manual 3. Near each wheel is a notch in the frame which the jack head fits in. Position the jack and raise the jack head until it fits firmly into the notch in the vehicle’s frame nearest the flat tire

Page 1700 of 5127

CHEVROLET AVEO 2002 Service Repair Manual 4. Insert the jack handle into the jack and the wheel wrench onto the end of the jack handle.5. Raise the vehicle by turning the wheel wrench clockwise. Raise the vehicle far enough off the ground so

Page 1701 of 5127

CHEVROLET AVEO 2002 Service Repair Manual 8. Remove any rust or dirt from the wheel bolts, mounting surfaces and spare wheel. {CAUTION: Rust or dirt on the wheel, or on the parts to which it is fastened, can make the wheel nuts become loose a

Page 1702 of 5127

CHEVROLET AVEO 2002 Service Repair Manual 12. Tighten the wheel nuts firmly in a crisscross sequence, as shown. {CAUTION: Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to come loose and even come off. This could

Page 1703 of 5127

CHEVROLET AVEO 2002 Service Repair Manual Storing the Flat Tire and Tools {CAUTION: Storing a jack, a tire, or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment coul

Page 1704 of 5127

CHEVROLET AVEO 2002 Service Repair Manual Compact Spare Tire Although the compact spare tire was fully inflated when your vehicle was new, it can lose air after a time. Check the inflation pressure regularly. It should be 60 psi (420 kPa).
