Page 57 of 4171

INFINITI QX56 2009 Factory Service Manual B2126 DETENT SWADP-43 < COMPONENT DIAGNOSIS > C DE F G H I K L M A B ADP N O P 1. Turn ignition switch OFF. 2. Disconnect A/T shift selector and driver seat control unit. 3. Check continuity between

Page 58 of 4171

INFINITI QX56 2009 Factory Service Manual ADP-44 < COMPONENT DIAGNOSIS > B2128 UART COMMUNICATION LINE B2128 UART COMMUNICATION LINE DescriptionINFOID:0000000003775544 Driver seat control unit performs UART communication with the automatic d

Page 59 of 4171

INFINITI QX56 2009 Factory Service Manual B2128 UART COMMUNICATION LINEADP-45 < COMPONENT DIAGNOSIS > C DE F G H I K L M A B ADP N O P Is the inspection result normal? YES >> Check intermittent incident. Refer to GI-38, "Intermittent Incide

Page 60 of 4171

INFINITI QX56 2009 Factory Service Manual ADP-46 < COMPONENT DIAGNOSIS > POWER SUPPLY AND GROUND CIRCUIT POWER SUPPLY AND GROUND CIRCUIT BCM BCM : Diagnosis ProcedureINFOID:0000000004055989 1. CHECK FUSES AND FUSIBLE LINK Check that the foll

Page 61 of 4171

INFINITI QX56 2009 Factory Service Manual POWER SUPPLY AND GROUND CIRCUITADP-47 < COMPONENT DIAGNOSIS > C DE F G H I K L M A B ADP N O P DRIVER SEAT CONTROL UNIT : Diagnosis ProcedureINFOID:0000000003775549 NOTE: Do not disconnect the batter

Page 62 of 4171

INFINITI QX56 2009 Factory Service Manual ADP-48 < COMPONENT DIAGNOSIS > POWER SUPPLY AND GROUND CIRCUIT 1. CHECK POWER SUPPLY CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect automatic drive positioner control unit. 3. Check voltage betwe

Page 63 of 4171

INFINITI QX56 2009 Factory Service Manual SLIDING SWITCHADP-49 < COMPONENT DIAGNOSIS > C DE F G H I K L M A B ADP N O P SLIDING SWITCH DescriptionINFOID:0000000003775553 Sliding switch is equipped to the power seat switch LH on the seat cush

Page 64 of 4171

INFINITI QX56 2009 Factory Service Manual ADP-50 < COMPONENT DIAGNOSIS > SLIDING SWITCH Is the inspection result normal? YES >> GO TO 3 NO >> Repair or replace harness. 3. CHECK DRIVER SEAT CONTROL UNIT OUTPUT 1. Connect the driver seat cont
