PRECAUTIONSDLN-121
< PRECAUTION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
5. When the repair work is completed, return the ignition switch to the ″LOCK ″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of al l control units using CONSULT-III.
Precaution for Transfer Assembly and Transfer Control Unit ReplacementINFOID:0000000004193517
When replacing transfer assembly or transfer control uni t, check the 4WD shift indicator lamp as follows.
1. Turn ignition switch ON.
2. Check 4WD shift indicator lamp is turned ON for approximately 1 second.
If OK, the position between transfer assemb ly and transfer control unit is correct.
If NG, the position is different between transfer assembly and transfer control unit. Adjust the position between transfer assembly and transfer control unit. See METHOD FOR POSITION
ADJUSTMENT that follows.
METHOD FOR POSITION ADJUSTMENT
1. Start engine. Run the engine for at least 10 seconds.
2. Stop vehicle and move A/T selector lever to N position with brake pedal depressed. Stay in N for at least 2
seconds.
3. Turn 4WD shift switch to 2WD position. Stay in 2WD for at least 2 seconds.
4. Turn ignition switch OFF.
5. Start engine.
6. Erase self-diagnosis. Refer to DLN-18, "CONSULT-III Function (ALL MODE AWD/4WD)"
.
7. Check 4WD shift indicator lamp. Refer to DLN-7, "Preliminary Check"
.
If 4WD shift indicator lamp does not indicate 2WD, install new transfer control unit and retry the above
check.
PrecautionINFOID:0000000004193518
Before connecting or disconnect ing the transfer control unit
harness connector, turn ignition switch “OFF” and disconnect
battery cables. Failure to do so may damage the transfer con-
trol unit. Battery voltage is ap plied to transfer control unit
even if ignition swit ch is turned “OFF”.
When connecting or disconnect ing pin connectors into or
from transfer control unit, take care not to damage pin termi-
nals (bend or break).
When connecting pin connectors make sure that there are not
any bends or breaks on transfer control unit pin terminals.
SEF289H
SEF291H
Revision: December 20092009 QX56
Page 1178 of 4171
![INFINITI QX56 2009 Factory Service Manual
DLN-122
< PRECAUTION >[ATX14B]
PRECAUTIONS
Before replacing transfer cont rol unit, perform transfer con-
trol unit input/output signal inspection and make sure transfer
control unit functions pro INFINITI QX56 2009 Factory Service Manual
DLN-122
< PRECAUTION >[ATX14B]
PRECAUTIONS
Before replacing transfer cont rol unit, perform transfer con-
trol unit input/output signal inspection and make sure transfer
control unit functions pro](/manual-img/42/57031/w960_57031-1177.png)
DLN-122
< PRECAUTION >[ATX14B]
PRECAUTIONS
Before replacing transfer cont rol unit, perform transfer con-
trol unit input/output signal inspection and make sure transfer
control unit functions properly. Refer to DLN-81, "Reference
Va lu e ".
Service NoticeINFOID:0000000004193519
After overhaul refill the transfer with new transfer fluid.
Check the fluid level or replace the fluid only with the vehicle parked on level ground.
During removal or installation, keep in side of transfer clear of dust or dirt.
Disassembly should be done in a clean work area.
Before proceeding with disassembly, thoroughly clean the tr ansfer. It is important to prevent the internal
parts from becoming contaminated by dirt or other foreign matter.
Check for the correct installation status prior to removal or disassembly. If matchmarks are required, be cer-
tain they do not interfere with the function of the parts when applied.
All parts should be carefully cleaned with a general purpose, non-flammable solvent before inspection or reassembly.
Check appearance of the disassembled parts for dam age, deformation, and unusual wear. Replace them
with new ones if necessary.
Gaskets, seals and O-rings should be replaced any time the transfer is disassembled.
In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If tight-
ening sequence is specified, use it.
Observe the specified torque when assembling.
Clean and flush the parts sufficiently and blow-dry them.
Be careful not to damage sliding surfaces and mating surfaces.
Use lint-free cloth or towels for wiping parts clean. Common shop rags can leave fibers that could interfere
with the operation of the transfer.
MEF040DB
Revision: December 20092009 QX56
Page 1179 of 4171
![INFINITI QX56 2009 Factory Service Manual
PREPARATIONDLN-123
< PREPARATION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000005874989
The actual shapes of Kent-Moore t ools may differ from INFINITI QX56 2009 Factory Service Manual
PREPARATIONDLN-123
< PREPARATION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000005874989
The actual shapes of Kent-Moore t ools may differ from](/manual-img/42/57031/w960_57031-1178.png)
PREPARATIONDLN-123
< PREPARATION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000005874989
The actual shapes of Kent-Moore t ools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool name Description
KV381054S0
(J-34286)
Puller Removing front oil seal
Removing rear oil seal
Removing metal bushing
KV38100500
(—)
Drift Installing front oil seal
a: 80 mm (3.15 in) dia.
b: 60 mm (2.36 in) dia.
ST30720000
(J-25405)
Drift Installing rear oil seal
Installing mainshaft front bearing and oil
seal
a: 77 mm (3.03 in) dia.
b: 55.5 mm (2.185 in) dia.
KV40105310
(—)
Drift Installing dust cover
a: 89 mm (3.50 in) dia.
b: 80.7 mm (3.17 in) dia.
ST22360002
(J-25679-01)
Drift Installing side oil seal
a: 23 mm (0.91 in) dia.
b: 32 mm (1.26 in) dia.
ST35300000
(—)
Drift Removing sun gear assembly and planetary
carrier assembly
Removing carrier bearing
Installing metal bushing
a: 59 mm (2.32 in) dia.
b: 45 mm (1.77 in) dia.
ZZA0601D
ZZA0811D
ZZA0811D
ZZA1003D
ZZA1091D
NT073
Revision: December 20092009 QX56
Page 1180 of 4171
![INFINITI QX56 2009 Factory Service Manual
DLN-124
< PREPARATION >[ATX14B]
PREPARATION
ST33200000
(J-26082)
Drift Removing mainshaft front bearing
Installing sun gear assembly and planetary
carrier assembly
Installing mainshaft front be INFINITI QX56 2009 Factory Service Manual
DLN-124
< PREPARATION >[ATX14B]
PREPARATION
ST33200000
(J-26082)
Drift Removing mainshaft front bearing
Installing sun gear assembly and planetary
carrier assembly
Installing mainshaft front be](/manual-img/42/57031/w960_57031-1179.png)
DLN-124
< PREPARATION >[ATX14B]
PREPARATION
ST33200000
(J-26082)
Drift Removing mainshaft front bearing
Installing sun gear assembly and planetary
carrier assembly
Installing mainshaft front bearing and oil seal
a: 74.5 mm (2.933 in) dia.
b: 62.5 mm (2.461 in) dia.
ST30031000
(—)
Puller Removing carrier bearing
Removing front drive shaft front bearing
Removing front drive shaft rear bearing
a: 90 mm (3.54 in) dia.
b: 50 mm (1.97 in) dia.
ST33710000
(—)
Drift Removing needle bearing
Removing metal bushing
a: 24 mm (0.94 in) dia.
b: 89 mm (3.5 in)
c: 30 mm (1.18 in) dia.
ST35325000
(—)
Drift bar Removing metal bushing
a: 215 mm (8.46 in)
b: 25 mm (0.98 in) dia.
c: M12
× 1.5P
ST33052000
(—)
Adapter Removing front drive shaft front bearing
Removing front drive shaft rear bearing
Installing mainshaft
a: 28 mm (1.10 in) dia.
b: 22 mm (0.87 in) dia.
ST22452000
(J-34335)
Drift Removing press flange snap ring
Installing press flange snap ring
a: 45 mm (1.77 in) dia.
b: 36 mm (1.42 in) dia.
c: 400 mm (15.76 in) dia.
ST30911000
(—)
Puller Removing press flange snap ring
Installing press flange snap ring
Installing mainshaft
Installing carrier bearing
a: 98 mm (3.86 in) dia.
b: 40.5 mm (1.594 in) dia.
Tool number
(Kent-Moore No.)
Tool name
Description
NT661
NT411
ZZA1057D
NT663
NT431
NT117
NT664
Revision: December 20092009 QX56
Page 1181 of 4171
![INFINITI QX56 2009 Factory Service Manual
PREPARATIONDLN-125
< PREPARATION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
Commercial Service ToolINFOID:0000000004193521
KV31103300
(—)
Drift Removing press flange snap ring
Installing press INFINITI QX56 2009 Factory Service Manual
PREPARATIONDLN-125
< PREPARATION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
Commercial Service ToolINFOID:0000000004193521
KV31103300
(—)
Drift Removing press flange snap ring
Installing press](/manual-img/42/57031/w960_57031-1180.png)
PREPARATIONDLN-125
< PREPARATION > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
Commercial Service ToolINFOID:0000000004193521
KV31103300
(—)
Drift Removing press flange snap ring
Installing press flange snap ring
Installing carrier bearing
a: 76.3 mm (3.004 in) dia.
b: 130 mm (5.12 in)
KV38100300
(J-25523)
Drift Removing mainshaft rear bearing
a: 54 mm (2.13 in) dia.
b: 46 mm (1.81 in) dia.
c: 32 mm (1.26 in) dia.
ST15310000
(J-25640-B)
Drift Installing mainshaft rear bearing
a: 96 mm (3.78 in) dia.
b: 84 mm (3.31 in) dia.
KV40100621
(J-25273)
Drift Installing front drive shaft front bearing
Installing front drive shaft rear bearing
a: 76 mm (2.99 in) dia.
b: 69 mm (2.72 in) dia.
ST30032000
(J-26010-01)
Base Installing front drive shaft front bearing
Installing front drive shaft rear bearing
a: 38 mm (1.50 in) dia.
b: 80 mm (3.15 in) dia.
ST33220000
(—)
Drift Installing needle bearing
a: 37 mm (1.46 in) dia.
b: 31 mm (1.22 in) dia.
c: 22 mm (0.87 in) dia.
Tool number
(Kent-Moore No.)
Tool name
Description
NT668
ZZA1046D
ZZA0908D
NT086
NT660
ZZA1046D
Revision: December 20092009 QX56
Page 1182 of 4171
DLN-126
< PREPARATION >[ATX14B]
PREPARATION
Tool name
Description
Puller Removing companion flange
Pin punch Removing retainer pin
Installing retainer pin
a: 6 mm (0.24 in) dia.
Power tool Removing transfer case assembly
NT077
NT410
PBIC0190E
Revision: December 20092009 QX56
Page 1183 of 4171
TRANSFER OIL FILTERDLN-127
< ON-VEHICLE MAINTENANCE > [ATX14B]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
ON-VEHICLE MAINTENANCE
TRANSFER OIL FILTER
Removal and InstallationINFOID:0000000004193522
REMOVAL
1. Remove the oil filter bolts and oil filter. CAUTION:
Do not damage center case or oil filter.
Loosen bolts and detach oil filter evenly.
2. Remove the O-rings (1) from the oil filter (2).
3. Remove the oil filter stud from the oil filter.
4. Remove the O-ring from the oil filter stud.
INSTALLATION
1. Apply ATF to the new O-ring, and install it on the oil filter stud. CAUTION:
Do not reuse O-ring.
2. Install the oil filter stud to the oil filter.
SMT875C
WDIA0285E
SDIA3180E
SDIA3180E
Revision: December 20092009 QX56
Page 1184 of 4171
DLN-128
< ON-VEHICLE MAINTENANCE >[ATX14B]
TRANSFER OIL FILTER
3. Apply ATF to the two new O-rings (1), and install them on the oil
filter (2).
CAUTION:
Do not reuse O-rings.
4. Install the oil filter to the transfer assembly. Tighten the bolts to the specified torque. Refer to DLN-127, "Removal and Installa-
tion".
CAUTION:
Do not damage oil filter.
Attach oil filter an d tighten bolts evenly.
5. Check the transfer fluid. Refer to DLN-129, "Inspection"
.
6. Start the engine for one minute. Then stop the engine and recheck the transfer fluid. Refer to DLN-129, "Inspection"
.
WDIA0285E
SDIA2136E
Revision: December 20092009 QX56
