INFINITI QX56 2009 Factory Service Manual WW-74 < ON-VEHICLE REPAIR > FRONT WIPER ARM ON-VEHICLE REPAIR FRONT WIPER ARM Front Wiper ArmsINFOID:0000000003776313 REMOVAL AND INSTALLATION Removal 1. Remove wiper arm covers and wiper arm nuts. 2.

Page 4162 of 4171

INFINITI QX56 2009 Factory Service Manual FRONT WIPER DRIVE ASSEMBLYWW-75 < ON-VEHICLE REPAIR > C DE F G H I J K M A B WW N O P FRONT WIPER DRIVE ASSEMBLY Wiper Motor and LinkageINFOID:0000000003776314 REMOVAL AND INSTALLATION Removal 1. Remo

Page 4163 of 4171

INFINITI QX56 2009 Factory Service Manual WW-76 < ON-VEHICLE REPAIR > FRONT WASHER TUBE FRONT WASHER TUBE Washer Tube LayoutINFOID:0000000003776315 WKIA4465E 1. Rear washer nozzle2. Washer nozzles3. Washer fluid reservoir Revision: December

Page 4164 of 4171

INFINITI QX56 2009 Factory Service Manual FRONT WASHER NOZZLEWW-77 < ON-VEHICLE REPAIR > C DE F G H I J K M A B WW N O P FRONT WASHER NOZZLE Washer Nozzle AdjustmentINFOID:0000000003776316 • This vehicle is equipped with non-adjustable wash

Page 4165 of 4171

INFINITI QX56 2009 Factory Service Manual WW-78 < ON-VEHICLE REPAIR > WASHER TANK WASHER TANK Washer Fluid ReservoirINFOID:0000000003776317 REMOVAL AND INSTALLATION Removal 1. Remove side washer fluid reservoir screw (2).• Front and rear wa

Page 4166 of 4171

INFINITI QX56 2009 Factory Service Manual FRONT WASHER PUMPWW-79 < ON-VEHICLE REPAIR > C DE F G H I J K M A B WW N O P FRONT WASHER PUMP Washer MotorINFOID:0000000003776318 REMOVAL AND INSTALLATION Removal 1. Remove washer fluid reservoir. Re

Page 4167 of 4171

INFINITI QX56 2009 Factory Service Manual WW-80 < ON-VEHICLE REPAIR > FRONT WIPER AND WASHER SWITCH FRONT WIPER AND WASHER SWITCH Wiper and Washer SwitchINFOID:0000000003776319 REMOVAL AND INSTALLATION Removal 1. Remove steering column covers

Page 4168 of 4171

INFINITI QX56 2009 Factory Service Manual REAR WIPER AND WASHER SYSTEMWW-81 < ON-VEHICLE REPAIR > C DE F G H I J K M A B WW N O P REAR WIPER AND WASHER SYSTEM Rear Wiper ArmINFOID:0000000003776320 REMOVAL AND INSTALLATION Removal 1. Remove wi
