5. Remove O-ring from input clutch assembly.
6. Remove oil pump assembly to transmission case bolts.
7. Remove the oil pump assembly evenly from the transmission case using Tools.
CAUTION:
Fully tighten the sliding hammer screws.
Make sure that bearing race is installed to the oil pump
assembly edge surface.
8. Remove O-ring from oil pump assembly.
SCIA5011E
SCIA2300E
Tool number : ST25850000 (J-25721-A)
SCIA5474E
SCIA5172E
Revision: December 20092009 QX56
Page 3882 of 4171
TM-234
< DISASSEMBLY AND ASSEMBLY >
DISASSEMBLY
9. Remove bearing race from oil pump assembly.
10. Remove needle bearing from front sun gear.
11. Remove front sun gear assembly from front carrier assembly.NOTE:
Remove front sun gear by rotating it left and right.
12. Remove seal rings from input clutch assembly.
13. Remove front carrier assembly (with input clutch assembly and rear internal gear) from rear carrier assembly.
CAUTION:
Do not remove it with needle bearing.
SCIA6529E
SCIA2808E
SCIA5014E
SCIA2470E
SCIA5015E
Revision: December 20092009 QX56
Page 3883 of 4171
DISASSEMBLYTM-235
< DISASSEMBLY AND ASSEMBLY >
CEF
G H
I
J
K L
M A
B
TM
N
O P
14. Loosen lock nut and remove band servo anchor end pin from transmission case.
15. Remove brake band from transmission case.
CAUTION:
To prevent brake linings from cracking or peeling, do not
stretch the flexible band unnecessarily. When removing
the brake band, always secure it with a clip as shown.
Check brake band facing for damage, cracks, wear or
burns.
16. Remove mid carrier assembly and rear carrier assembly as a unit.
SCIA6512E
SCIA2580E
SAT655
SCIA5017E
Revision: December 20092009 QX56
Page 3884 of 4171
TM-236
< DISASSEMBLY AND ASSEMBLY >
DISASSEMBLY
17. Remove mid carrier assembly from rear carrier assembly.
18. Remove needle bearing (front side) from mid carrier assembly.
19. Remove needle bearing (rear side) from mid carrier assembly.
20. Remove bearing race from rear carrier assembly.
21. Remove needle bearing from rear carrier assembly.
SCIA5697E
SCIA2805E
SCIA2804E
SCIA5175E
SCIA2803E
Revision: December 20092009 QX56
Page 3885 of 4171
DISASSEMBLYTM-237
< DISASSEMBLY AND ASSEMBLY >
CEF
G H
I
J
K L
M A
B
TM
N
O P
22. Remove mid sun gear assembly , rear sun gear assembly and
high and low reverse clutch hub as a unit.
CAUTION:
Remove them with bearing race and needle bearing.
23. Remove high and low reverse clutch assembly from direct clutch assembly.
CAUTION:
Make sure that needle bearing is installed to the high and
low reverse clutch assembly edge surface.
24. Remove needle bearing from drum support.
25. Remove direct clutch assembly from reverse brake.
26. Remove snap ring from A/T assembly harness connector.
SCIA5018E
SCIA2306E
SCIA5198E
SCIA5019E
SCIA5021E
Revision: December 20092009 QX56
Page 3886 of 4171

TM-238
< DISASSEMBLY AND ASSEMBLY >
DISASSEMBLY
27. Push A/T assembly harness connector.CAUTION:
Do not damage connector.
28. Remove oil pan and oil pan gasket. Refer to TM-201, "Oil Pan"
.
29. Check foreign materials in oil pan to help determine causes of malfunction. If the A/T fluid is very dark, smells burned, or con-
tains foreign particles, the frictional material (clutches, band)
may need replacement. A tacky film that will not wipe clean indi-
cates varnish build up. Varnish can cause valves, servo, and
clutches to stick and can inhibit pump pressure.
If frictional material is de tected, perform A/T fluid cooler
cleaning. Refer to TM-183, "A/T Fluid Cooler Cleaning"
.
30. Remove magnets from oil pan.
31. Disconnect A/T fluid temperat ure sensor 2 connector (A).
CAUTION:
Do not damage connector.
32. Straighten terminal clip to free terminal cord assembly and A/ T fluid temperature sensor 2 harness.
33. Disconnect output sensor connector. CAUTION:
Do not damage connector.
34. Straighten terminal clip to free output sensor harness.
SCIA5022E
SCIA5199E
SCIA5200E
SCIA8124E
Revision: December 20092009 QX56
Page 3887 of 4171
DISASSEMBLYTM-239
< DISASSEMBLY AND ASSEMBLY >
CEF
G H
I
J
K L
M A
B
TM
N
O P
35. Remove bolts (A), (B) and (C) from control valve with TCM. : Front
36. Remove control valve with TCM from transmission case. CAUTION:
When removing, be careful with the manual valve notch and
manual plate height. Remove it vertically.
37. Remove A/T fluid temperature sensor 2 with bracket from con- trol valve with TCM.
38. Remove bracket from A/T fluid temperature sensor 2.
39. Remove O-ring from A/T assembly harness connector.
Bolt symbol Length mm (in) Number of bolts A 42 (1.65) 5
B 55 (2.17) 6
C 40 (1.57) 1
SCIA8077E
SCIA5260E
SCIA5253E
SCIA5264E
SCIA5155E
Revision: December 20092009 QX56
Page 3888 of 4171
TM-240
< DISASSEMBLY AND ASSEMBLY >
DISASSEMBLY
40. Disconnect TCM connectors.CAUTION:
Do not damage connectors.
41. Remove A/T assembly harness connector from control valve with TCM using suitable tool.
42. Disconnect TCM connector and transmission range switch con- nector.
CAUTION:
Do not damage connectors.
43. Remove rear extension assembly (2WD models) or adapter case assembly (4WD models) according to the following procedures.
a. 2WD models
i. Remove bolts (1 brackets) for rear extension assembly and transmission case.
Self-sealing bolts (2)
SCIA5447E
SCIA5448E
SCIA5449E
WCIA0562E
