INFINITI QX56 2009 Factory Service Manual WW-18 < COMPONENT DIAGNOSIS > WIPER AND WASHER FUSE COMPONENT DIAGNOSIS WIPER AND WASHER FUSE DescriptionINFOID:0000000003776288 Fuse list Diagnosis ProcedureINFOID:0000000003776289 1. CHECK FUSES Che

Page 4106 of 4171

INFINITI QX56 2009 Factory Service Manual FRONT WIPER MOTOR LO CIRCUITWW-19 < COMPONENT DIAGNOSIS > C DE F G H I J K M A B WW N O P FRONT WIPER MOTOR LO CIRCUIT Component Function CheckINFOID:0000000003776290 1. CHECK FRONT WIPER LO OPERATION

Page 4107 of 4171

INFINITI QX56 2009 Factory Service Manual WW-20 < COMPONENT DIAGNOSIS > FRONT WIPER MOTOR LO CIRCUIT 1. Turn the ignition switch ON. 2. Select "FRONT WIPER" of IPDM E/R active test item. 3. While operating the test item, check voltage between

Page 4108 of 4171

INFINITI QX56 2009 Factory Service Manual FRONT WIPER MOTOR HI CIRCUITWW-21 < COMPONENT DIAGNOSIS > C DE F G H I J K M A B WW N O P FRONT WIPER MOTOR HI CIRCUIT Component Function CheckINFOID:0000000003776292 1. CHECK FRONT WIPER HI OPERATION

Page 4109 of 4171

INFINITI QX56 2009 Factory Service Manual WW-22 < COMPONENT DIAGNOSIS > FRONT WIPER MOTOR HI CIRCUIT 1. Turn the ignition switch ON. 2. Select "FRONT WIPER" of IPDM E/R active test item. 3. While operating the test item, check voltage between

Page 4110 of 4171

INFINITI QX56 2009 Factory Service Manual FRONT WIPER AUTO STOP SIGNAL CIRCUITWW-23 < COMPONENT DIAGNOSIS > C DE F G H I J K M A B WW N O P FRONT WIPER AUTO ST OP SIGNAL CIRCUIT Component Function CheckINFOID:0000000003776294 1. CHECK FRONT W

Page 4111 of 4171

INFINITI QX56 2009 Factory Service Manual WW-24 < COMPONENT DIAGNOSIS > FRONT WIPER AUTO STOP SIGNAL CIRCUIT Check continuity between IPDM E/R harness connector and front wiper motor harness connector. Does continuity exist? YES >> Replace fr

Page 4112 of 4171

INFINITI QX56 2009 Factory Service Manual FRONT WIPER MOTOR GROUND CIRCUITWW-25 < COMPONENT DIAGNOSIS > C DE F G H I J K M A B WW N O P FRONT WIPER MOTOR GROUND CIRCUIT Diagnosis ProcedureINFOID:0000000003776296 1. CHECK FRONT WIPER MOTO R (G
