INFINITI QX56 2009 Factory Service Manual VACUUM LINESBR-11 < BASIC INSPECTION > C DE G H I J K L M A B BR N O P VACUUM LINES InspectionINFOID:0000000004042328 VISUAL INSPECTION Check for improper assembly, damage and de terioration. Replace

Page 442 of 4171

INFINITI QX56 2009 Factory Service Manual BR-12 < BASIC INSPECTION > BRAKE MASTER CYLINDER BRAKE MASTER CYLINDER On Board InspectionINFOID:0000000003772420 LEAK INSPECTION Check for leaks at master cylinder to brake booster attachment point,

Page 443 of 4171

INFINITI QX56 2009 Factory Service Manual BRAKE TUBE AND HOSEBR-13 < BASIC INSPECTION > C DE G H I J K L M A B BR N O P BRAKE TUBE AND HOSE Hydraulic CircuitINFOID:0000000004042327 CAUTION: • All hoses and piping (tubes) must be fr ee from

Page 444 of 4171

INFINITI QX56 2009 Factory Service Manual BR-14 < BASIC INSPECTION > BRAKE TUBE AND HOSE 1. Check brake lines (tubes and hoses) and connections for fluid leaks, damage, twists, deformation, con- tacts with other parts, and loose connections.

Page 445 of 4171

INFINITI QX56 2009 Factory Service Manual BRAKE PEDALBR-15 < ON-VEHICLE MAINTENANCE > C DE G H I J K L M A B BR N O P ON-VEHICLE MAINTENANCE BRAKE PEDAL Inspection and AdjustmentINFOID:0000000004068343 INSPECTION 1. Inspect the brake pedal fr

Page 446 of 4171

INFINITI QX56 2009 Factory Service Manual BR-16 < ON-VEHICLE MAINTENANCE > BRAKE PEDAL 2. Loosen lock nut (A) on the input rod, then turn input rod to adjustthe brake pedal to the specified height. When finished adjusting, tighten the lock nu

Page 447 of 4171

INFINITI QX56 2009 Factory Service Manual BRAKE FLUIDBR-17 < ON-VEHICLE MAINTENANCE > C DE G H I J K L M A B BR N O P BRAKE FLUID On Board InspectionINFOID:0000000003772425 LEVEL CHECK • Make sure the fluid level in reservoir tank is betwee

Page 448 of 4171

INFINITI QX56 2009 Factory Service Manual BR-18 < ON-VEHICLE MAINTENANCE > BRAKE FLUID 3. Fully depress brake pedal 4 to 5 times. 4. With brake pedal depressed, loosen bleed valve to let the air out, and then tighten it immediately. 5. Repeat
