Page 1249 of 4171
PREPARATIONDLN-193
< PREPARATION > [PROPELLER SHAFT: 2S1410]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
PREPARATION
PREPARATION
Commercial Service ToolINFOID:0000000003772210
Tool name Description
Power tool Loosening bolts and nuts
PBIC0190E
Revision: December 20092009 QX56
Page 1250 of 4171
![INFINITI QX56 2009 Factory Service Manual
DLN-194
< SYMPTOM DIAGNOSIS >[PROPELLER SHAFT: 2S1410]
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooti INFINITI QX56 2009 Factory Service Manual
DLN-194
< SYMPTOM DIAGNOSIS >[PROPELLER SHAFT: 2S1410]
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooti](/manual-img/42/57031/w960_57031-1249.png)
DLN-194
< SYMPTOM DIAGNOSIS >[PROPELLER SHAFT: 2S1410]
NOISE, VIBRATION, AND HARSHNESS
(NVH) TROUBLESHOOTING
SYMPTOM DIAGNOSIS
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
NVH Troubleshooting ChartINFOID:0000000003772211
Use the chart below to help you find the cause of the sy mptom. If necessary, repair or replace these parts.
×: ApplicableReference page
DLN-195, "On-Vehicle Service"DLN-195, "On-Vehicle Service"DLN-195, "On-Vehicle Service"
DLN-242, "NVH Troubleshooting Chart"RAX-5, "NVH Troubleshooting Chart"RSU-5, "NVH Troubleshooting Chart"WT-36, "NVH Troubleshooting Chart"WT-36, "NVH Troubleshooting Chart"
RAX-5, "NVH Troubleshooting Chart"
BR-6, "NVH Troubleshooting Chart"ST-12, "NVH Troubleshooting Chart"
Possible cause and suspected parts
Uneven rotation torque
Rotation imbalance
Excessive run out
Differential
Axle
Suspension
Tires
Road wheel
Drive shaft
Brakes
Steering
Symptom Noise
×××××××××××
Shake ×××××××
Vibration ××××××××
Revision: December 20092009 QX56
Page 1251 of 4171
![INFINITI QX56 2009 Factory Service Manual
PROPELLER SHAFTDLN-195
< ON-VEHICLE REPAIR > [PROPELLER SHAFT: 2S1410]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
ON-VEHICLE REPAIR
PROPELLER SHAFT
On-Vehicle ServiceINFOID:0000000003772212
APPEARANCE AND NOIS INFINITI QX56 2009 Factory Service Manual
PROPELLER SHAFTDLN-195
< ON-VEHICLE REPAIR > [PROPELLER SHAFT: 2S1410]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
ON-VEHICLE REPAIR
PROPELLER SHAFT
On-Vehicle ServiceINFOID:0000000003772212
APPEARANCE AND NOIS](/manual-img/42/57031/w960_57031-1250.png)
PROPELLER SHAFTDLN-195
< ON-VEHICLE REPAIR > [PROPELLER SHAFT: 2S1410]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
ON-VEHICLE REPAIR
PROPELLER SHAFT
On-Vehicle ServiceINFOID:0000000003772212
APPEARANCE AND NOISE INSPECTION
Check the propeller shaft tube surface for dents or crac ks. If damaged, replace the propeller shaft assembly.
Check the bearings for noise and damage. Repair or replace the bearings as necessary.
PROPELLER SHAFT VIBRATION
If a vibration is present at high speed, inspect the propeller shaft runout first.
1. Measure the runout of the propeller shaft tube at several points by rotating the final drive companion
flange with your hands.
2. If the runout exceeds specif ications, disconnect the propeller
shaft at the final drive companion flange; then rotate the com-
panion flange 90 °, 180 ° and 270 ° and reconnect the propeller
shaft.
3. Check the runout again. If the r unout still exceeds specifications,
replace the propeller shaft assembly.
4. After installation, check for vibration by driving vehicle. Limit
Propeller shaft run out : Refer to
DLN-201, "Gen-
eral Specification"
SDIA1781E
Revision: December 20092009 QX56
Page 1252 of 4171
DLN-196
< REMOVAL AND INSTALLATION >[PROPELLER SHAFT: 2S1410]
PROPELLER SHAFT
REMOVAL AND INSTALLATION
PROPELLER SHAFT
Removal and InstallationINFOID:0000000005875033
REMOVAL
2WD
AWDIA0698GB
1. Propeller shaft tube 2. Snap ring 3. Journal bearing
4. Sleeve yoke 5. Journal 6. Flange yoke
Front
Revision: December 20092009 QX56
Page 1253 of 4171
PROPELLER SHAFTDLN-197
< REMOVAL AND INSTALLATION > [PROPELLER SHAFT: 2S1410]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
4WD
REMOVAL
1. Move the A/T select lever to the N position and release the parking brake.
2. Put matching marks on the rear propeller shaft flange yoke and the rear final drive companion flange as shown.
CAUTION:
For matching marks, use paint. Never damage the rear pro-
peller shaft flange yoke or the companion flange.
3. Remove the bolts, then remove the propeller shaft from the rear final drive and A/T or transfer.
INSPECTION
Inspect the propeller shaft runout. If runout exceeds the limit, replace the propeller shaft assembly.
AWDIA0699GB
1. Propeller shaft tube 2. Snap ring 3. Journal bearing
4. Sleeve yoke 5. Journal 6. Flange yoke
Front
WDIA0049E
Limit
Propeller shaft run out : Refer to DLN-201, "Gen-
eral Specification"
LDIA0121E
Revision: December 20092009 QX56
Page 1254 of 4171
![INFINITI QX56 2009 Factory Service Manual
DLN-198
< REMOVAL AND INSTALLATION >[PROPELLER SHAFT: 2S1410]
PROPELLER SHAFT
While holding the flange yoke on one side, check axial play of the joint as shown. If the journal axial play
exceeds th INFINITI QX56 2009 Factory Service Manual
DLN-198
< REMOVAL AND INSTALLATION >[PROPELLER SHAFT: 2S1410]
PROPELLER SHAFT
While holding the flange yoke on one side, check axial play of the joint as shown. If the journal axial play
exceeds th](/manual-img/42/57031/w960_57031-1253.png)
DLN-198
< REMOVAL AND INSTALLATION >[PROPELLER SHAFT: 2S1410]
PROPELLER SHAFT
While holding the flange yoke on one side, check axial play of the joint as shown. If the journal axial play
exceeds the specification, repair or replace the journal parts.
Check the propeller shaft tube for dents or cracks. If damage is detected, replace the propeller shaft assembly.
INSTALLATION
Installation is in the reverse order of removal.
After installation, check for vibration by driving the vehicle. Refer to DLN-194, "NVH Troubleshooting Chart"
.
If propeller shaft assembly of final drive assembly has been replaced, connect them as follows:
- Face companion flange mark (A) of the final drive (1) upward. With
the mark (A) faced upward, couple the propeller shaft and the final
drive so that the matching mark (B) of the propeller shaft (2) can be
positioned as close as possible with the matching mark (C) of the
final drive companion flange.
- Tighten propeller shaft and final drive bolts and nuts of the to spec-
ification. Refer to DLN-196, "Removal and Installation"
.
CAUTION:
Do not reuse the bolts and nuts. Always install new ones.
Standard
Propeller shaft journal axi-
al play
: Refer to
DLN-201, "Gen-
eral Specification"
LDIA0117E
PDIA0892J
Revision: December 20092009 QX56
Page 1255 of 4171
![INFINITI QX56 2009 Factory Service Manual
PROPELLER SHAFTDLN-199
< DISASSEMBLY AND ASSEMBLY > [PROPELLER SHAFT: 2S1410]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
DISASSEMBLY AND ASSEMBLY
PROPELLER SHAFT
Disassembly and AssemblyINFOID:0000000003772214 INFINITI QX56 2009 Factory Service Manual
PROPELLER SHAFTDLN-199
< DISASSEMBLY AND ASSEMBLY > [PROPELLER SHAFT: 2S1410]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
DISASSEMBLY AND ASSEMBLY
PROPELLER SHAFT
Disassembly and AssemblyINFOID:0000000003772214](/manual-img/42/57031/w960_57031-1254.png)
PROPELLER SHAFTDLN-199
< DISASSEMBLY AND ASSEMBLY > [PROPELLER SHAFT: 2S1410]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
DISASSEMBLY AND ASSEMBLY
PROPELLER SHAFT
Disassembly and AssemblyINFOID:0000000003772214
DISASSEMBLY
Journal
1. Put matching marks on the rear propeller shaft and flange yoke as shown.
CAUTION:
For matching marks use paint. Never damage the rear pro-
peller shaft or flange yoke.
2. Remove the snap rings.
3. Push out and remove the journal bearings by lightly tapping the flange yoke with a hammer, taking care not to damage the jour-
nal or flange yoke hole.
NOTE:
Put marks on the disassembled parts so that they can be rein-
stalled in their original positions from which they were removed.
4. Push out and remove the remaining journal bearings at the opposite side by lightly tapping the flange yoke with a hammer,
taking care not to damage the journal or flange yoke hole.
NOTE:
Put marks on the disassembled parts so that they can be rein-
stalled in their original positions from which they were removed.
ASSEMBLY
SPD128
APD011
SPD732
SPD131
Revision: December 20092009 QX56
Page 1256 of 4171
DLN-200
< DISASSEMBLY AND ASSEMBLY >[PROPELLER SHAFT: 2S1410]
PROPELLER SHAFT
Journal
1. Assemble the journal bearings. Apply multipurpose grease on
the bearing inner surface.
NOTE:
During assembly, use caution so that the needle bearings do not
fall down.
2. Select new snap rings that will provide the specified play in an axial direction of the journal, and install them. Refer to DLN-201,
"Snap Ring".
CAUTION:
Do not reuse snap rings
NOTE:
Select snap rings with a difference in thickness at both sides
within 0.02 mm (0.0008 in).
3. Adjust the thrust clearance between the bearing and snap ring to zero by tapping the yoke.
4. Make sure that the journal moves smoothly and is bel ow the joint flex effort specification. Refer to DLN-
201, "General Specification".
WPD019
APD012
SPD732
Standard
Propeller shaft joint flex ef-
fort: Refer to
DLN-201, "Gen-
eral Specification"
LDIA0119E
