Page 2641 of 4171
![INFINITI QX56 2009 Factory Service Manual LAN-72
< COMPONENT DIAGNOSIS >[CAN]
LASER BRANCH LINE CIRCUIT
LASER BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776472
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the INFINITI QX56 2009 Factory Service Manual LAN-72
< COMPONENT DIAGNOSIS >[CAN]
LASER BRANCH LINE CIRCUIT
LASER BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776472
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the](/manual-img/42/57031/w960_57031-2640.png)
LAN-72
< COMPONENT DIAGNOSIS >[CAN]
LASER BRANCH LINE CIRCUIT
LASER BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776472
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the ICC s ensor for damage, bend and loose connection (unit side
and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of ICC sensor.
2. Check the resistance between the ICC sensor harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the ICC sensor branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the ICC sensor. Refer to CCS-47, "
Wiring Diagram".
Is the inspection result normal?
YES (Present error)>>Replace the ICC sensor. Refer to CCS-71, "ICC Sensor".
YES (Past error)>>Error was detect ed in the ICC sensor branch line.
NO >> Repair the power supply and the ground circuit.
ICC sensor harness connector Resistance (Ω)
Connector No. Terminal No.
E42 23Approx. 54 – 66
Revision: December 20092009 QX56
Page 2642 of 4171
![INFINITI QX56 2009 Factory Service Manual LAN
ICC BRANCH LINE CIRCUITLAN-73
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
ICC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776473
1.CHECK CONNECTOR
1. Turn the ignition INFINITI QX56 2009 Factory Service Manual LAN
ICC BRANCH LINE CIRCUITLAN-73
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
ICC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776473
1.CHECK CONNECTOR
1. Turn the ignition](/manual-img/42/57031/w960_57031-2641.png)
LAN
ICC BRANCH LINE CIRCUITLAN-73
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
ICC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776473
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the ICC unit for damage, bend and loose connection (unit side and
connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of ICC unit.
2. Check the resistance between the ICC unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the ICC unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the ICC unit. Refer to CCS-47, "
Wiring Diagram".
Is the inspection result normal?
YES (Present error)>>Replace the ICC unit. Refer to CCS-70, "ICC Unit".
YES (Past error)>>Error was detected in the ICC unit branch line.
NO >> Repair the power supply and the ground circuit.
ICC unit harness connector Resistance (Ω)
Connector No. Terminal No.
B13 14 5 Approx. 54 – 66
Revision: December 20092009 QX56
Page 2643 of 4171
![INFINITI QX56 2009 Factory Service Manual LAN-74
< COMPONENT DIAGNOSIS >[CAN]
ADP BRANCH LINE CIRCUIT
ADP BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776474
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the batt INFINITI QX56 2009 Factory Service Manual LAN-74
< COMPONENT DIAGNOSIS >[CAN]
ADP BRANCH LINE CIRCUIT
ADP BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776474
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the batt](/manual-img/42/57031/w960_57031-2642.png)
LAN-74
< COMPONENT DIAGNOSIS >[CAN]
ADP BRANCH LINE CIRCUIT
ADP BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776474
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors fo r damage, bend and loose connection (unit side and con-
nector side).
- Driver seat control unit
- Harness connector B200
- Harness connector B37
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of driver seat control unit.
2. Check the resistance between the driver seat control unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the driver seat control unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the driver seat control unit. Refer to ADP-47, "
DRIVER SEAT
CONTROL UNIT : DiagnosisProcedure".
Is the inspection result normal?
YES (Present error)>>Replace the driv er seat control unit. Refer to ADP-165, "Removal and Installation".
YES (Past error)>>Error was detected in the driver seat control unit branch line.
NO >> Repair the power supply and the ground circuit.
Driver seat control unit harness connector Resistance (Ω)
Connector No. Terminal No.
B202 319Approx. 54 – 66
Revision: December 20092009 QX56
Page 2644 of 4171
![INFINITI QX56 2009 Factory Service Manual LAN
AV BRANCH LINE CIRCUITLAN-75
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776475
1.CHECK CONNECTOR
1. Turn the ignition sw INFINITI QX56 2009 Factory Service Manual LAN
AV BRANCH LINE CIRCUITLAN-75
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776475
1.CHECK CONNECTOR
1. Turn the ignition sw](/manual-img/42/57031/w960_57031-2643.png)
LAN
AV BRANCH LINE CIRCUITLAN-75
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776475
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the AV c ontrol unit for damage, bend and loose connection (unit
side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of AV control unit.
2. Check the resistance between the AV control unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the AV control unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circui t of the AV control unit. Refer to AV-68, "
AV CONTROL UNIT :
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the AV control unit. Refer to AV-168, "Removal and Installation".
YES (Past error)>>Error was detected in the AV control unit branch line.
NO >> Repair the power supply and the ground circuit.
AV control unit harness connector Resistance (Ω)
Connector No. Terminal No.
M45 96 97 Approx. 54 – 66
Revision: December 20092009 QX56
Page 2645 of 4171
![INFINITI QX56 2009 Factory Service Manual LAN-76
< COMPONENT DIAGNOSIS >[CAN]
BCM BRANCH LINE CIRCUIT
BCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776476
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the batt INFINITI QX56 2009 Factory Service Manual LAN-76
< COMPONENT DIAGNOSIS >[CAN]
BCM BRANCH LINE CIRCUIT
BCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776476
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the batt](/manual-img/42/57031/w960_57031-2644.png)
LAN-76
< COMPONENT DIAGNOSIS >[CAN]
BCM BRANCH LINE CIRCUIT
BCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776476
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the BCM for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of BCM.
2. Check the resistance between the BCM harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the BCM branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the BCM. Refer to BCS-32, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the BCM. Refer to BCS-56, "Removal and Installation".
YES (Past error)>>Error was detected in the BCM branch line.
NO >> Repair the power supply and the ground circuit.
BCM harness connector Resistance (Ω)
Connector No. Terminal No.
M18 3940Approx. 54 – 66
Revision: December 20092009 QX56
Page 2646 of 4171
![INFINITI QX56 2009 Factory Service Manual LAN
DLC BRANCH LINE CIRCUITLAN-77
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
DLC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776477
INSPECTION PROCEDURE
1.CHECK CONNECTOR
INFINITI QX56 2009 Factory Service Manual LAN
DLC BRANCH LINE CIRCUITLAN-77
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
DLC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776477
INSPECTION PROCEDURE
1.CHECK CONNECTOR](/manual-img/42/57031/w960_57031-2645.png)
LAN
DLC BRANCH LINE CIRCUITLAN-77
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
DLC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776477
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the data link connector for damage, bend and loose connection (connector side and harness side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
Check the resistance between the data link connector terminals.
Is the measurement value within the specification?
YES (Present error)>>Check the following items again.
• Decision of CAN system type.
• Not received CONSULT-III data [SELF-DIAG RESULTS, CAN DIAG SUPPORT MNTR (“ECU
list” included)].
• Procedure for detecting root cause.
YES (Past error)>>Error was detected in the data link connector branch line circuit.
NO >> Repair the data link connector branch line.
Data link connector Resistance (Ω)
Connector No. Terminal No.
M22 614Approx. 54 – 66
Revision: December 20092009 QX56
Page 2647 of 4171
![INFINITI QX56 2009 Factory Service Manual LAN-78
< COMPONENT DIAGNOSIS >[CAN]
HVAC BRANCH LINE CIRCUIT
HVAC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776478
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the ba INFINITI QX56 2009 Factory Service Manual LAN-78
< COMPONENT DIAGNOSIS >[CAN]
HVAC BRANCH LINE CIRCUIT
HVAC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776478
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the ba](/manual-img/42/57031/w960_57031-2646.png)
LAN-78
< COMPONENT DIAGNOSIS >[CAN]
HVAC BRANCH LINE CIRCUIT
HVAC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776478
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the A/C auto amp. for damage, bend and loose connection (unit
side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of A/C auto amp.
2. Check the resistance between the A/C auto amp. harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the A/C auto amp. branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the A/C auto amp. Refer to HAC-90, "
A/C Auto Amp Power
and Ground Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the A/C auto amp. Refer to VTL-7, "Removal and Installation".
YES (Past error)>>Error was detect ed in the A/C auto amp. branch line.
NO >> Repair the power supply and the ground circuit.
A/C auto amp. harness connector Resistance (Ω)
Connector No. Terminal No.
M50 4140Approx. 54 – 66
Revision: December 20092009 QX56
Page 2648 of 4171
![INFINITI QX56 2009 Factory Service Manual LAN
I-KEY BRANCH LINE CIRCUITLAN-79
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
I-KEY BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776479
1.CHECK CONNECTOR
1. Turn the ignit INFINITI QX56 2009 Factory Service Manual LAN
I-KEY BRANCH LINE CIRCUITLAN-79
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
I-KEY BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776479
1.CHECK CONNECTOR
1. Turn the ignit](/manual-img/42/57031/w960_57031-2647.png)
LAN
I-KEY BRANCH LINE CIRCUITLAN-79
< COMPONENT DIAGNOSIS > [CAN]
C
D
E
F
G H
I
J
K L
B A
O P
N
I-KEY BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003776479
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the Intelligent Key unit for damage, bend and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of Intelligent Key unit.
2. Check the resistance between the Intelli gent Key unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the Intelligent Key unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the Intelligent Key unit. Refer to DLK-68, "
INTELLIGENT
KEY UNIT : Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the Intelligent Key unit. Refer to SEC-111, "Removal and Installation".
YES (Past error)>>Error was detected in the Intelligent Key unit branch line.
NO >> Repair the power supply and the ground circuit.
Intelligent Key unit harness connector Resistance (Ω)
Connector No. Terminal No.
M70 2 3 Approx. 54 – 66
Revision: December 20092009 QX56
