AUTOMATIC DRIVE POSITIONER SYSTEMADP-13
< FUNCTION DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
AUTOMATIC DRIVE POSITIONER SYSTEM : Component DescriptionINFOID:0000000003775497
CONTROL UNITS
INPUT PARTS
Switches
Entry/Exit assist functionExit On exit, the seat moves backward and the steering wheel moves upward.
Entry
On entry, the seat and steering wheel return from exiting position to the previous driv-
ing position.
Function Description
Item Function
Driver seat control unit  Main unit of automatic drive positioner system
 It is connected to the CAN.
 It communicates with the automatic drive positioner control unit via UART com-
munication.
Automatic drive positioner control unit  It communicates with the driver seat control unit via UART communication.
 Perform various controls with the instructions of driver seat control unit.
 Perform the controls of the pedal adjusting, steering wheel, door mirror and the
seat memory switch.
BCM Transmit the following status to the driver seat control unit via CAN communication.
 Front door LH: OPEN/CLOSE
 Ignition switch position: ACC/ON
 Door lock: UNLOCK (with Intelligent Key or remote keyless entry request switch
operation)
 Key ID
 Key switch: Insert/Pull out Intelligent Key
 Starter: CRANKING/OTHER
Combination meter Transmit the vehicle speed signal to the driver seat control unit via CAN communi-
cation.
AV control unit The setting change of auto drive positioner system can be performed on the display.
A/T shift selector (park position switch) Transmit the shift position signal (P range) to the driver seat control unit.
Item Function
Key switch and ignition knob switch The key switch is installed to detect the key inserted/removed status.
Front door switch LH Detect front door (driver side) open/close status.
A/T shift selector (park position switch) Detect the P range position of A/T selector lever.
Set switch The registration and system setting can be performed with its operation.
Seat memory switch 1/2 The registration and operation can be performed with its operation.
Power seat switch The following switch is installed.
 Reclining switch
 Lifting switch (front)
 Lifting switch (rear)
 Sliding switch
The specific parts can be operated with the operation of each switch.
Pedal adjusting switch The following switch is installed.
 Pedal forward
 Pedal backward
The specific parts can be operated with the operation of each switch.
