QUICK REFERENCE INDEX
AGENERAL INFORMATIONGIGeneral Information
BENGINEEMEngine Mechanical
LUEngine Lubrication System
COEngine Cooling System
ECEngine Control System
FLFuel System
EXExhaust System
STRStarting System
ACCAccelerator Control System
CHYBRIDHBCHybrid Control System
HBBHybrid Battery System
HBRHybrid Brake System
DTRANSMISSION & DRIVE-
LINETMTransaxle & Transmission
DLNDriveline
FAXFront Axle
RAXRear Axle
ESUSPENSIONFSUFront Suspension
RSURear Suspension
SCSSuspension Control System
WTRoad Wheels & Tires
FBRAKESBRBrake System
PBParking Brake System
BRCBrake Control System
GSTEERINGSTSteering System
STCSteering Control System
HRESTRAINTSSBSeat Belt
SBCSeat Belt Control System
SRSRS Airbag
SRCSRS Airbag Control System
IVENTILATION, HEATER &
AIR CONDITIONERVTLVentilation System
HAHeater & Air Conditioning System
HACHeater & Air Conditioning Control System
JBODY INTERIORINTInterior
IPInstrument Panel
SESeat
ADPAutomatic Drive Postioner
APAdjustable Pedal
KBODY EXTERIOR,
DOORS, ROOF & VEHICLE
SECURITYDLKDoor & Lock
SECSecurity Control System
GWGlass & Window System
PWCPower Window Control System
RFRoof
EXTExterior
BRMBody Repair Manual
LDRIVER CONTROLSMIRMirrors
EXLExterior Lighting System
INLInterior Lighting System
WWWiper & Washer
DEFDefogger
HRNHorn
MELECTRICAL & POWER
CONTROLPWOPower Outlet
BCSBody Control System
LANLAN System
PCSPower Control System
CHGCharging System
PGPower Supply, Ground & Circuit Elements
NDRIVER INFORMATION &
MULTIMEDIAMWIMeter, Warning Lamp & Indicator
WCSWarning Chime System
SNSonar System
AVAudio, Visual & Navigation System
OCRUISE CONTROLCCSCruise Control System
PMAINTENANCEMAMaintenance
All rights reserved. No part
of this Service Manual may
be reproduced or stored in a
retrieval system, or transmit-
ted in any form, or by any
means, electronic, mechani-
cal, photo-copying, record-
ing or otherwise, without the
prior written permission of
Nissan North America, Inc.
Edition: June 2008
Revision: December 2009
Publication No. SM9
E-1J60U1

AV
AV-1
DRIVER INFORMATION & MULTIMEDIA
C
DE
F
G H
I
J
K L
M B
SECTION AV
A
O P
CONTENTS
AUDIO, VISUAL & NAVIGATION SYSTEM
AUDIO SYSTEM
BASIC INSPECTION ....... .............................
5
DIAGNOSIS AND REPAIR WORKFLOW ..... .....5
Work Flow ........................................................... ......5
INSPECTION AND ADJUSTMENT .....................7
REAR VIEW MONITOR GUIDING LINE ADJUST-
MENT ..................................................................... ......
7
REAR VIEW MONITOR GUIDING LINE ADJUST-
MENT : Description ...................................................
7
REAR VIEW MONITOR GUIDING LINE ADJUST-
MENT : Special Repair Requirement ........................
7
FUNCTION DIAGNOSIS ...............................9
AUDIO SYSTEM ............................................. .....9
System Diagram .................................................. ......9
System Description ...................................................9
Component Parts Location ......................................11
Component Description ...........................................12
NAVIGATION SYSTEM ......................................13
System Diagram .................................................. ....13
System Description .................................................13
Component Parts Location ......................................16
Component Description ...........................................17
REAR VIEW MONITOR SYSTEM ......................18
System Diagram .................................................. ....18
System Description .................................................18
Component Parts Location ......................................19
Component Description ...........................................20
DVD PLAYER .....................................................21
System Diagram .................................................. ....21
System Description .................................................21
Component Parts Location ......................................22
Component Description ...........................................22
HANDS-FREE PHONE SYSTEM ......................24
System Diagram .................................................. ....24
System Description ..................................................24
Component Parts Location ......................................25
Component Description ...........................................26
DIAGNOSIS SYSTEM (AV CONTROL UNIT) ...27
AV CONTROL UNIT .............................................. ....27
AV CONTROL UNIT : Diagnosis Description ..........27
AV CONTROL UNIT : CONS ULT-III Function .........38
A/C AND AV SWITCH ASSEMBLY ...................... ....40
A/C AND AV SWITCH ASSEMBLY : Component
Function Check ........................................................
40
COMPONENT DIAGNOSIS .........................41
U1000 CAN COMM CIRCUIT ...........................41
Description ........................................................... ....41
DTC Logic ................................................................41
Diagnosis Procedure ..............................................41
U1010 CONTROL UNIT (CAN) .........................42
Description ...............................................................42
DTC Logic ................................................................42
Diagnosis Procedure ...............................................42
U1200 AV CONTROL UNIT ..............................43
Description ...............................................................43
DTC Logic ................................................................43
U1201 AV CONTROL UNIT ..............................44
Description ...............................................................44
DTC Logic ................................................................44
U1204 GPS COMM ...........................................45
Description ...............................................................45
DTC Logic ................................................................45
U1205 GPS ROM ..............................................46
Description ...............................................................46
DTC Logic ................................................................46
Revision: December 20092009 QX56

AV-4
STEERING SWITCH ........................................178
Removal and Installation ..................................... ..178
REAR AUDIO REMOTE CONTROL UNIT ......179
Removal and Installation ..................................... ..179
DVD ENTERTAINMENT SYSTEM ..................180
Removal and Installation ..................................... ..180
BOSE SPEAKER AMP ....................................181
Removal and Installation ..................................... ..181
AUDIO ANTENNA ...........................................182
Location of Antennas ........................................... ..182
Window Antenna Repair ........................................182
SATELLITE RADIO ANTENNA .......................184
Removal and Installation .......................................184
GPS ANTENNA .............................................. ..185
Removal and Installation .......................................185
MICROPHONE ............................................... ..186
Removal and Installation .......................................186
REAR VIEW CAMERA .....................................187
Removal and Installation .......................................187
REAR VIEW CAMERA CONTROL UNIT ....... ..188
Removal and Installation .......................................188
Revision: December 20092009 QX56

AV
DIAGNOSIS AND REPAIR WORKFLOWAV-5
< BASIC INSPECTION > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORKFLOW
Work FlowINFOID:0000000003776765
OVERALL SEQUENCE
• Reference 1··· Refer to AV-38, "AV CONTROL UNIT : CONSULT-III Function".
• Reference 2··· Refer to AV-155, "
Symptom Table".
DETAILED FLOW
1.CHECK SYMPTOM
Check the malfunction symptoms by performing the following items.
• Interview the customer to obtain the malfunction information (conditions and environment when the malfunc-
tion occurred).
• Check the symptom.
>> GO TO 2.
2.SELF-DIAGNOSIS (CONSULT-III)
1. Connect CONSULT-III and perform “SELF-DIAGNOSIS” for “MULTI AV”. NOTE:
Skip to step 4 of the diagnosis proc edure if “MULTI AV” is not displayed.
2. Check if any DTC No. is displayed in the self-diagnosis results.
AWNIA0030GB
Revision: December 20092009 QX56

AV-6
< BASIC INSPECTION >[AUDIO SYSTEM]
DIAGNOSIS AND REPAIR WORKFLOW
Is any DTC No. displayed?
YES >> GO TO 3.
NO >> GO TO 4.
3.CHECK SELF-DIAGNOSIS RESULTS (CONSULT-III)
1. Check the DTC No. indicated in the self-diagnosis results.
2. Perform the relevant diagnosis referring to the DTC No. list. Refer to AV-143, "
DTC Index".
NOTE:
Start with the diagnosis for the CAN communication system if “CAN COMM CIRCUIT [U1000] or CONTROL
UNIT (CAN) [U1010]” is displayed.
>> GO TO 5.
4.PERFORM DIAGNOSIS BY SYMPTOM
Perform the relevant diagnosis referring to the diagnosis chart by symptom. Refer to AV-155, "
Symptom
Table".
>> GO TO 5.
5.REPAIR OR REPLACE MALFUNCTIONING PARTS
Repair or replace the identified malfunctioning parts.
NOTE:
Erase the stored self-diagnosis results after repairing or replacing the relevant components if any DTC No. has
been indicated in the self-diagnosis results.
>> GO TO 6.
6.CHECK AFTER REPAIR
1. Perform self-diagnosis for “MULTI AV” with CONSULT- III after repairing or replacing the malfunctioning
parts.
2. Check if any DTC No. is displayed in the self-diagnosis results.
Is any DTC No. displayed?
YES >> GO TO 3.
NO >> GO TO 7.
7.FINAL CHECK
Perform the operation check to confirm that the malf unction symptom is solved or that any other symptoms
are present.
Are any symptoms present?
YES >> GO TO 4.
NO >> Inspection End.
Revision: December 20092009 QX56

AV
INSPECTION AND ADJUSTMENTAV-7
< BASIC INSPECTION > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
INSPECTION AND ADJUSTMENT
REAR VIEW MONITOR GUIDING LINE ADJUSTMENT
REAR VIEW MONITOR GUIDING LI NE ADJUSTMENT : DescriptionINFOID:0000000003776766
This mode is used to modify the side distance guidelines if they are dislocated from the rear view monitor
image, because of variations of body/camera mounting conditions.
REAR VIEW MONITOR GUIDING LINE ADJU STMENT : Special Repair Requirement
INFOID:0000000003776767
1. Create a correction line to modify the screen.
Draw lines on the rearward of the vehicle passing through the
following points: 200 mm (7.87 inch) from both sides of the vehi-
cle, and
• *1: 0.5 m (1.5 feet)
• *2: 1 m (3 feet)
• *3: 2 m (7 feet)
• *4: 3 m (10 feet)and from the rear end of the bumper
2. With the ignition switch OFF, connect CONSULT-III, then turn
ignition switch ON. Select “REARVIEW CAMERA”.
CAUTION:
Stop engine for safety when correcting side distance guide-
line.
3. Shift the A/T selector lever to R position.
4. Touch “SELCT GUIDELINE PATTERN” under “WORK SUPPORT” menu.
5. Touch “UP” or “DOWN”, and select the guide line, “PATTERN NO. 0” or “PATTERN NO. 1”, which is the
closest to the corrected line.
6. Touch “SAVE”, and confirm the guide line.
7. Touch “END”.
8. Touch “ADJ GUIDELINE POSITION” under the “WORK SUPPORT” menu.
9. Adjust the guide line touching “X UP”, “X DOWN”, “Y UP” or “Y DOWN” so that the corrected line can fit the guide line.
10. Touch “SAVE”, and confirm the guide line.
SKIA5637E
SKIA6103E
Revision: December 20092009 QX56

AV-8
< BASIC INSPECTION >[AUDIO SYSTEM]
INSPECTION AND ADJUSTMENT
11. Touch “END” to finish correcting.
Revision: December 20092009 QX56

AV
AUDIO SYSTEMAV-9
< FUNCTION DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
FUNCTION DIAGNOSIS
AUDIO SYSTEM
System DiagramINFOID:0000000003776768
System DescriptionINFOID:0000000003776769
AUDIO SYSTEM
AWNIA1548GB
Revision: December 20092009 QX56
