Page 2097 of 4171

INFINITI QX56 2009 Factory Service Manual AUTO LIGHT SYSTEMEXL-149 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B EXL N O P AUTO LIGHT SYSTEM Removal and InstallationINFOID:0000000003776225 OPTICAL SENSOR Removal 1. Remove defroster gril

Page 2098 of 4171

INFINITI QX56 2009 Factory Service Manual EXL-150 < REMOVAL AND INSTALLATION > FRONT FOG LAMP FRONT FOG LAMP Bulb ReplacementINFOID:0000000003776226 FRONT FOG LAMP Removal 1. Remove the front turn/fog lamp assembly. Refer to EXL-150, "Removal

Page 2099 of 4171

INFINITI QX56 2009 Factory Service Manual FRONT FOG LAMPEXL-151 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B EXL N O P Installation Installation is in the reverse order of removal. Revision: December 20092009 QX56

Page 2100 of 4171

INFINITI QX56 2009 Factory Service Manual EXL-152 < REMOVAL AND INSTALLATION > LIGHTING & TURN SIGNAL SWITCH LIGHTING & TURN SIGNAL SWITCH Removal and InstallationINFOID:0000000003776228 REMOVAL 1. Remove steering column cover. 2. While press

Page 2101 of 4171

INFINITI QX56 2009 Factory Service Manual HAZARD SWITCHEXL-153 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B EXL N O P HAZARD SWITCH Removal and InstallationINFOID:0000000003776229 REMOVAL 1. Remove cluster lid C. Refer to IP-16, "Remo

Page 2102 of 4171

INFINITI QX56 2009 Factory Service Manual EXL-154 < REMOVAL AND INSTALLATION > PUDDLE LAMP PUDDLE LAMP Removal and InstallationINFOID:0000000005864680 REMOVAL 1. Depress tab (1) on outer edge of puddle lamp housing. 2. Lower outer edge and sl

Page 2103 of 4171

INFINITI QX56 2009 Factory Service Manual LICENSE PLATE LAMPEXL-155 < REMOVAL AND INSTALLATION > C DE F G H I J K M A B EXL N O P LICENSE PLATE LAMP Bulb ReplacementINFOID:0000000003776230 LICENSE PLATE LAMP Removal 1. Remove back door lower

Page 2104 of 4171

INFINITI QX56 2009 Factory Service Manual EXL-156 < REMOVAL AND INSTALLATION > STOP LAMP STOP LAMP Bulb ReplacementINFOID:0000000003776232 HIGH-MOUNTED STOP LAMP NOTE: High-mounted stop lamp bulbs are not serviceable. STOP LAMP Refer to EXL-
