Page 3921 of 4171

INFINITI QX56 2009 Factory Service Manual ASSEMBLYTM-273 < DISASSEMBLY AND ASSEMBLY > CEF G H I J K L M A B TM N O P 23. Install needle bearing to transmission case. CAUTION:  Take care with the direction of needle bearing. Refer toTM-229,

Page 3922 of 4171

INFINITI QX56 2009 Factory Service Manual TM-274 < DISASSEMBLY AND ASSEMBLY > ASSEMBLY 27. Install parking pawl (with return spring) and pawl shaft to rearextension (2WD models) or adapter case (4WD models). 28. Install parking actuator supp

Page 3923 of 4171

INFINITI QX56 2009 Factory Service Manual ASSEMBLYTM-275 < DISASSEMBLY AND ASSEMBLY > CEF G H I J K L M A B TM N O P 32. Install output shaft in transmission case. CAUTION: Do not mistake front of shaft for rear because both sides look simil

Page 3924 of 4171

INFINITI QX56 2009 Factory Service Manual TM-276 < DISASSEMBLY AND ASSEMBLY > ASSEMBLY iii. Install brackets (1) and tighten rear extension assembly boltsand (2 self-sealing bolts) to specified torque. CAUTION: Do not reuse self-sealing bol

Page 3925 of 4171

INFINITI QX56 2009 Factory Service Manual ASSEMBLYTM-277 < DISASSEMBLY AND ASSEMBLY > CEF G H I J K L M A B TM N O P 35. Install direct clutch assembly in reverse brake. CAUTION: Make sure that drum support edge surface and direct clutch in

Page 3926 of 4171

INFINITI QX56 2009 Factory Service Manual TM-278 < DISASSEMBLY AND ASSEMBLY > ASSEMBLY CAUTION: Make sure that portion “A” of high and low reverse clutch drum protrudes approximately 2 mm (0.08 in) beyond por- tion “B” of rear sun ge

Page 3927 of 4171

INFINITI QX56 2009 Factory Service Manual ASSEMBLYTM-279 < DISASSEMBLY AND ASSEMBLY > CEF G H I J K L M A B TM N O P 43. Install needle bearing (rear side) to mid carrier assembly. CAUTION: Apply petroleum jelly to needle bearing. 44. Instal

Page 3928 of 4171

INFINITI QX56 2009 Factory Service Manual TM-280 < DISASSEMBLY AND ASSEMBLY > ASSEMBLY 48. Install band servo anchor end pin and lock nut in transmissioncase. CAUTION: Do not reuse band servo anchor end pin. 49. Install brake band in transmi
