INFINITI QX56 2009 Factory Service Manual FRONT SEATSE-49 < ON-VEHICLE REPAIR > C DE F G H I K L M A B SE N O P Passenger Seat WIIA0476E 1. Headrest 2. Headrest holder with multi-position lock 3. Seatback board 4. Armrest assembly 5. Lumba

Page 3282 of 4171

INFINITI QX56 2009 Factory Service Manual SE-50 < ON-VEHICLE REPAIR > FRONT SEAT Removal and Installation INFOID:0000000005880170 REMOVAL CAUTION: • When removing or installing the seat trim, handle it carefully to keep dirt out and avoid d

Page 3283 of 4171

INFINITI QX56 2009 Factory Service Manual SECOND SEATSE-51 < ON-VEHICLE REPAIR > C DE F G H I K L M A B SE N O P SECOND SEAT Exploded ViewINFOID:0000000003775471 Second Row RH WIIA1013E 1. Headrest 2. Seatback pad 3. Seatback frame 4. Rear s

Page 3284 of 4171

INFINITI QX56 2009 Factory Service Manual SE-52 < ON-VEHICLE REPAIR > SECOND SEAT 10. Reclining device inner mid cover 11. Armrest assembly12. Armrest bolt cover 13. Armrest trim cover 14. Latch assembly 15. Seat cushion mat springs 16. Seat

Page 3285 of 4171

INFINITI QX56 2009 Factory Service Manual SECOND SEATSE-53 < ON-VEHICLE REPAIR > C DE F G H I K L M A B SE N O P Second row LH WIIA1015E 1. Seatback panel 2. RH headrest guide (free) 3. LH headrest guide (locking) 4. Rear seat bezel 5. Seatba

Page 3286 of 4171

INFINITI QX56 2009 Factory Service Manual SE-54 < ON-VEHICLE REPAIR > SECOND SEAT Second row center 19. Seat cushion support frame assem-bly 20. Inboard cushion floor latch 21. Lower rear seat cover inner 22. Lower rear seat cover 23. Seat

Page 3287 of 4171

INFINITI QX56 2009 Factory Service Manual SECOND SEATSE-55 < ON-VEHICLE REPAIR > C DE F G H I K L M A B SE N O P Removal and InstallationINFOID:0000000003775472 Second Row Outboard Removal 1. Remove seat base trim cover. 2. Lift handle and ti

Page 3288 of 4171

INFINITI QX56 2009 Factory Service Manual SE-56 < ON-VEHICLE REPAIR > THIRD SEAT THIRD SEAT Exploded ViewINFOID:0000000003775478 Third seat RH ALIIA0070GB 1. Headrest 2. Headrest holder, locking 3. Headrest holder, free 4. Seatback board 5. S
