Page 1713 of 4171

INFINITI QX56 2009 Factory Service Manual EC-386 < COMPONENT DIAGNOSIS >[VK56DE] ASCD BRAKE SWITCH 10.CHECK STOP LAMP SWITCH Refer to EC-386, "Component Inspection" . OK or NG OK >> GO TO 11. NG >> Replace stop lamp switch. 11 .CHECK INTERM

Page 1714 of 4171

INFINITI QX56 2009 Factory Service Manual ASCD INDICATOREC-387 < COMPONENT DIAGNOSIS > [VK56DE] C D E F G H I J K L M A EC NP O ASCD INDICATOR Component DescriptionINFOID:0000000003771706 ASCD indicator lamp illuminates to indicate ASCD oper

Page 1715 of 4171

INFINITI QX56 2009 Factory Service Manual EC-388 < COMPONENT DIAGNOSIS >[VK56DE] COOLING FAN COOLING FAN Diagnosis ProcedureINFOID:0000000003771708 1.CHECK POWER SUPPLY CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect IPDM E/R harness conn

Page 1716 of 4171

INFINITI QX56 2009 Factory Service Manual COOLING FANEC-389 < COMPONENT DIAGNOSIS > [VK56DE] C D E F G H I J K L M A EC NP O 2. Supply cooling fan motor terminals with battery voltage and check operation. Cooling fan motor should operate. If

Page 1717 of 4171

INFINITI QX56 2009 Factory Service Manual EC-390 < COMPONENT DIAGNOSIS >[VK56DE] ELECTRICAL LOAD SIGNAL ELECTRICAL LOAD SIGNAL DescriptionINFOID:0000000003771710 The electrical load signal (Headlamp switch signal, r ear window defogger switc

Page 1718 of 4171

INFINITI QX56 2009 Factory Service Manual ELECTRICAL LOAD SIGNALEC-391 < COMPONENT DIAGNOSIS > [VK56DE] C D E F G H I J K L M A EC NP O >> INSPECTION END Revision: December 20092009 QX56

Page 1719 of 4171

INFINITI QX56 2009 Factory Service Manual EC-392 < COMPONENT DIAGNOSIS >[VK56DE] FUEL INJECTOR FUEL INJECTOR Component DescriptionINFOID:0000000003771712 The fuel injector is a small, precise solenoid valve. When the ECM supplies a ground to

Page 1720 of 4171

INFINITI QX56 2009 Factory Service Manual FUEL INJECTOREC-393 < COMPONENT DIAGNOSIS > [VK56DE] C D E F G H I J K L M A EC NP O 2. Disconnect fuel injector harness connector. 3. Turn ignition switch ON. 4. Check voltage between fuel injector
