Page 1969 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual LEFT DOOR
(1) Remove door. (Refer to 23 - BODY/DOORS -
REAR/DOOR - REMOVAL)
(2) Remove trim panel (20) (Fig. 5). (Refer to 23 -
BODY/DOORS - REAR/TRIM PANEL - REMOVAL)
(3) Disconnect electrical connec

Page 1970 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual ASSEMBLY
RIGHT DOOR
(1) Install the door hinges (4) and bolts (3) (Fig. 6).
(Refer to 23 - BODY/DOORS - REAR/HINGE -
INSTALLATION)
(2) Install the door check (10) and bolts (9). (Refer
to 23 - BODY/DO

Page 1971 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual LEFT DOOR
(1) Install lock rods (2, 13) and install lock rod
guides (1, 16). (Fig. 7)
(2) Using locking pliers, hold upper lock rod (2) in
place.
(3) Install clips (15).
(4) Install the lock rod actua

Page 1972 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual (2) Tighten bolts to 25 N´m (18 ft. lbs.).
(3) Engage check arm into receiver.
(4) Adjust the door as necessary. (Refer to 23 -
BODY/DOORS - REAR/DOOR - ADJUSTMENTS)
ADJUSTMENTS
ADJUSTMENT
NOTE: Door

Page 1973 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual CAUTION: Since the rear doors are components
with static functions it is very important that they
are fastened while driving. This prevents excessive
torsion of the vehicle and leaky rear doors. The r

CAUTION: Since the rear doors are components
with static functions it is very important that they
are fastened while driving. This prevents excessive
torsion of the vehicle and leaky rear doors. The rear
doors are fastened by adjusting the closing
wedges.
(9) Closing wedges at bottom must be resting free
of play on plastic closing plates when rear doors are
closed. To adjust, loosen door hinges and raise or
lower complete doors.
(10) Loosen upper closing wedge screws and move
top closing wedge up against plastic closing plate free
of play with rear door closed and tighten screws to 10
N´m (89 in. lbs.).
(11) Check and adjust the hinges. On rear doors,
the retaining magnets should run up to the middle of
the mating plate at the side wall. If this is not the
case, correct as listed. (Fig. 11)
CAUTION: Adjustment range of screw (3) maximum
1 turn (risk of control cam breaking, 4)
²Retaining magnet is too far forward relative to
mating plate. Turn in adjustment screw (2) at top
and bottom hinge.
²Retaining magnet is too far back relative to mat-
ing plate. Turn out adjustment screw (2) at top and
bottom hinge.
²Retaining magnet is too deep relative to mating
plate. Turn in adjustment screw (2) at top hinge,
turn out adjustment screw (2) at bottom hinge.
²Retaining magnet is too high relative to mating
plate. Turn out adjustment screw (2) at top hinge,
turn in adjustment screw (2) at bottom hinge.²Retaining magnet strikes too hard against mat-
ing plate. Turn in adjustment screw (1) at top and
bottom hinge.
²Retaining magnet does not make contact with
mating plate. Turn out adjustment screw (1) at top
and bottom hinge.
²Door projects at corner paneling when closed.
Turn out adjustment screw (3) at hinge.
²Door is too far recessed at corner paneling when
closed. Turn in adjustment screw (3) at hinge.
DOOR GLASS
REMOVAL
(1) Position an assistant on one side of the door to
receive the glass and weatherstrip seal.
(2) Start at an inside, upper corner. Separate the
seal from the window opening. Push the glass and
seal outward from the window opening. Remove the
glass and seal.
(3) Clean the window opening.
INSTALLATION
(1) Install the weatherstrip seal on the window
glass. Verify that the glass is seated in the groove
around the edge of the seal.
(2) Insert an installation cord in the weatherstrip
seal inner groove.
NOTE: Use mineral spirits as a lubricant to aid seal
installation in the window opening.
(3) Position the glass and seal in the window open-
ing.
(4) Pull the installation cord outward and force the
seal lip over the panel flange around the edge of the
opening.
(5) Seat the seal inner lip on the panel flange.
Press against the lip around the edge of the seal.
Fig. 10 STRIKER ADJUSTMENT
1 - STRIKER
2 - LOCK ROD HANDLE ASSEMBLY
3 - LEFT DOOR
Fig. 11 REAR HINGE ADJUSTMENT
1 - ADJUSTMENT SCREW
2 - ADJUSTMENT SCREW
3 - ADJUSTMENT SCREW
4 - CONTROL ARM
23 - 30 DOORS - REARVA

Page 1974 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual NOTE: Remove any mineral spirits with a clean
cloth after glass installation.
(6) Verify that the seal is seated in the window
opening (Fig. 12).
(7) Test the window for water leaks. (Refer to 23 -
BO

Page 1975 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual (2) Position rear of handle into latch opening and
engage lock and latch actuation levers with the latch
levers. (Fig. 16)
NOTE: Front door shown, rear door similar.
(3) Slide exterior handle towards

Page 1976 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual INSTALLATION
(1) Install hinge and install bolts.
(2) Tighten bolts to 25 N´m (18 ft. lbs.).
(3) Adjust door if necessary. (Refer to 23 - BODY/
DOOR - FRONT/DOOR - ADJUSTMENTS)
INSIDE HANDLE ACTUATOR
