Page 281 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual ENGINE CONTROL MODULE C3 (EXCEPT OBD) - BLACKCAV CIRCUIT FUNCTION 1 18BR/DG INTAKE AIR TEMPERATURE SENSOR GROUND 2- - 3- - 4- - 5 18BL/RD ACCEL PEDAL POSITION SENSOR 5 VOLT SUPPLY 6 18WT/DG BOOST PRES

Page 282 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual EVAPORATOR TEMPERATURE SENSORCAV CIRCUIT FUNCTION 1 18BR/DG EVAPORATOR TEMPERATURE SENSOR SIGNAL 2 18BR/BL SENSOR GROUND FUEL LEVEL SENSORCAV CIRCUIT FUNCTION 2 20BL/BK FUEL LEVEL SENSOR SIGNAL (+) 3

Page 283 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual C O N N E C T O R P I N O U T S 270 CONNECTOR PINOUTS

Page 284 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual FUSES (FUSE BLOCK NO. 1)FUSE NO.AMPS FUSED CIRCUIT FUNCTION 1- - - 2 10A 16WT FUSED HIGH BEAM SWITCH OUTPUT 3 10A 16WT FUSED HIGH BEAM SWITCH OUTPUT 4 10A 16WT/BL/RD FUSED IGNITION SWITCH OUTPUT (RUN-

Page 285 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual FUSE BLOCK NO. 1 C3 - BLACKCAV CIRCUIT FUNCTION 1- - 2 16BK/VT FUSED IGNITION SWITCH OUTPUT (RUN-START) 3 12VT IGNITION SWITCH OUTPUT (START) 4- - 5 12RD FUSED B(+) FUSE BLOCK NO. 1 C4 - BLACKCAV CIRC

Page 286 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual C O N N E C T O R P I N O U T S 273 CONNECTOR PINOUTS

Page 287 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual FUSES (FUSE BLOCK NO. 2)FUSE NO.AMPS FUSED CIRCUIT FUNCTION 1 10A 16RD/GY FUSED B(+) 2 10A 16RD FUSED B(+) 3 15A 16RD FUSED B(+) 4 7.5A 16RD/YL FUSED B(+) 5 25A 14RD/WT FUSED B(+) 6 7.5A 18RD/YL FUSED

Page 288 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual C O N N E C T O R P I N O U T S 275 CONNECTOR PINOUTS
