Page 289 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual FUSES (FUSE BLOCK NO. 3)CAV CIRCUIT FUNCTION 1 16RD FUSED B(+) 2 16RD/DG FUSED B(+) 3 12RD/DG FUSED B(+) 4 14RD FUSED B(+) 5 16RD FUSED B(+) 6 14RD FUSED B(+) 7 16BK OPTIONAL EQUIPMENT RELAY OUTPUT 8

Page 290 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual C O N N E C T O R P I N O U T S 277 CONNECTOR PINOUTS

Page 291 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual FUSES (FUSE/RELAY BLOCK)FUSE NO.AMPS FUSED CIRCUIT FUNCTION 1 30A 14BL/YL FUSED B(+) 2- - - 3- - - 4- - - 5 10A 16RD/YL FUSED B(+) 6 7.5A 18BK/RD FUSED OPTIONAL EQUIPMENT RELAY OUTPUT 7 25A 14RD FUSED

Page 292 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual INSTRUMENT CLUSTER C1CAV CIRCUIT FUNCTION 1 20BR FUEL LEVEL SENSOR SIGNAL RETURN 2 20BR/DG AMBIENT TEMPERATURE SENSOR SIGNAL RETURN 4 20WT/GY K-IC/ATC/HBM/CHM 5 20BR/BK PARK BRAKE INDICATOR SIGNAL 7 2

Page 293 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual INTRUSION SENSOR NO. 3 - BLACKCAV CIRCUIT FUNCTION 1 20BR GROUND 2 20DG/WT/BL INTRUSION SENSOR 3 SIGNAL 3 20DG/YL INTRUSION SENSOR INTERFACE 4 20RD/DG FUSED B(+) MASTER DOOR LOCK SWITCHCAV CIRCUIT FUN

Page 294 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual FUSES (PDC)FUSE NO.AMPS FUSED CIRCUIT FUNCTION 1 200A 4RD FUSED B(+) 2 70A 10RD FUSED B(+) 3 125A 8RD FUSED B(+) 4 80A 8RD FUSED B(+) 5 125A 8RD FUSED B(+) 6 100A 8RD FUSED B(+) C O N N E C T O R P I

Page 295 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual RADIO C1 - BLACKCAV CIRCUIT FUNCTION A1 20BL/RD/WT VEHICLE SPEED SENSOR OUTPUT A2 20YL K-TCM/RADIO A3 18DG/YL/BK CTEL MUTE A4 16RD/YL FUSED B(+) A5 16BK RADIO ANTENNA A6 16GY/DG/RD LAMP DRIVER A7 16BK

Page 296 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual C O N N E C T O R P I N O U T S 283 CONNECTOR PINOUTS
