Page 161 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: CABIN HEATER CONTROL HIGH OR OPEN (ACTIVE) POSSIBLE CAUSES CABIN HEATER OR HEATER BOOSTER CONTROL UNIT CABIN HEATER CONTROL CIRCUIT SHORTED TO VOLTAGE AUTOMATIC TEMPERATURE CONTROL (ATC) CABI

Page 162 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 3 Turn the ignition off. NOTE: Check connectors - Clean/repair as necessary. Disconnect the Automatic Temperature Control (ATC) C1 harness connector. Disconnect the Cabin Hea

Page 163 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: CABIN HEATER CONTROL SHORTED LOW (ACTIVE) POSSIBLE CAUSES CABIN HEATER OR HEATER BOOSTER CONTROL UNIT CABIN HEATER CONTROL CIRCUIT SHORTED TO GROUND CABIN HEATER CONTROL CIRCUIT SHORTED TO GR

Page 164 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 3 Turn the ignition off. Disconnect the Cabin Heater or Heater Booster harness connector. Disconnect the Automatic Temperature Control (ATC) C1 harness connector. Measure the

Page 165 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: CIRC PUMP CONTROL HIGH OR OPEN (ACTIVE) POSSIBLE CAUSES CIRCULATION PUMP CIRCULATION PUMP CONTROL CIRCUIT SHORTED TO VOLTAGE AUTOMATIC TEMPERATURE CONTROL (ATC) CIRCULATION PUMP CONTROL CIRCU

Page 166 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 3 Turn the ignition off. NOTE: Check connectors - Clean/repair as necessary. Disconnect the Automatic Temperature Control (ATC) C1 harness connector. Disconnect the Circulati

Page 167 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual Symptom: CIRC PUMP CONTROL SHORTED LOW (ACTIVE) POSSIBLE CAUSES CIRCULATION PUMP CONTROL CIRCUIT SHORTED TO GROUND CIRCULATION PUMP CONTROL CIRCUIT SHORTED TO GROUND CIRCUIT CIRCULATION PUMP CONTROL C

Page 168 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual TEST ACTION APPLICABILITY 4 Turn the ignition off. Disconnect the Circulation Pump harness connector. Connect a fused jumper wire between the Battery (+) and Circulation Pump cavity 2. Connect a jumpe
