MERCEDES-BENZ SPRINTER 2006 Service Manual 8W-33 VEHICLE SPEED CONTROL
Component Page
Brake Lamp Switch.................. 8W-33-2
Controller Antilock Brake.............. 8W-33-2
Engine Control Module................ 8W-33-3
Fuse 5.............

Page 1251 of 2305

Page 1252 of 2305

Page 1253 of 2305

Page 1254 of 2305

MERCEDES-BENZ SPRINTER 2006 Service Manual 8W-35 ANTILOCK BRAKES
Component Page
Automatic Temperature Control Module . . 8W-35-2
Brake Fluid Level Switch.............. 8W-35-7
Brake Lamp Switch................ 8W-35-3, 4
Brake Lamp Switch 4 Po

8W-35 ANTILOCK BRAKES
Component Page
Automatic Temperature Control Module . . 8W-35-2
Brake Fluid Level Switch.............. 8W-35-7
Brake Lamp Switch................ 8W-35-3, 4
Brake Lamp Switch 4 Pole............ 8W-35-10
Brake Pressure Sensor................ 8W-35-9
Brake Wear Sensor-Left Front.......... 8W-35-8
Brake Wear Sensor-Left Rear........... 8W-35-8
Brake Wear Sensor-Right Front......... 8W-35-8
Brake Wear Sensor-Right Rear......... 8W-35-8
Center High Mounted Stop Lamp..... 8W-35-3, 10
Controller Antilock Brake . 8W-35-2, 3, 4, 5, 6, 9, 10
Data Link Connector................. 8W-35-5
Daytime Running Lamps Relay......... 8W-35-2
Fuse 2............................ 8W-35-5
Fuse 3............................ 8W-35-5
Fuse 5.......................... 8W-35-3, 10
Fuse 6............................ 8W-35-5
Fuse 7............................ 8W-35-5
Fuse 9............................ 8W-35-5
Fuse Block No. 1.................. 8W-35-3, 10
Fuse/Relay Block.................... 8W-35-5
G100.............................. 8W-35-4Component Page
G200.......................... 8W-35-4, 7, 8
G202.............................. 8W-35-7
G203.............................. 8W-35-2
G300.............................. 8W-35-8
G302.............................. 8W-35-4
Instrument Cluster................. 8W-35-7, 8
Lateral Acceleration Sensor............ 8W-35-9
Optional Equipment Relay............. 8W-35-5
Parking Brake Switch................ 8W-35-7
Power Distribution Center............. 8W-35-5
Relay Block........................ 8W-35-5
Shifter Assembly.................... 8W-35-3
Steering Angle Sensor................ 8W-35-4
TCS Switch........................ 8W-35-2
Tail Lamp Assembly-Left........... 8W-35-3, 10
Tail Lamp Assembly-Right.......... 8W-35-3, 10
Trailer Tow Control Module......... 8W-35-3, 10
Wheel Speed Sensor-Left Front......... 8W-35-6
Wheel Speed Sensor-Left Rear.......... 8W-35-6
Wheel Speed Sensor-Right Front........ 8W-35-6
Wheel Speed Sensor-Right Rear......... 8W-35-6
VA8W-35 ANTILOCK BRAKES 8W - 35 - 1
